- Page 1 NT Series Master Development System User's Guide...
- Page 2 Warning: Some customers may want Linx radio frequency (“RF”) products to control machinery or devices remotely, including machinery or devices that can cause death, bodily injuries, and/or property damage if improperly or inadvertently triggered, particularly in industrial settings or other applications implicating life-safety concerns (“Life and Property Safety Situations”).
-
Page 4: Ordering Information
868MHz NT Series Master Development System MDEV-900-NT 900MHz NT Series Master Development System Figure 2: Ordering Information NT Series Transceiver Development Board Figure 3: NT Series Transceiver Development Board Board Objects 1. Prototype Area 10. Channel (Frequency) 2. Break-Out Header Selection Dial 3. - Page 5 • Make sure that the Baud Rate and Channel switches are set the same on both boards • Check that the antennas are connected • Make sure that a jumper is installed on the Module Power Header • Make sure that the batteries are not dead If all of these appear to be in order, please call +1 800 736 6677 or e-mail techsupport@linxtechnologies.com for technical support.
- Page 6 The Power Area The Power Area has two switches that control power to the board and the type of operation (Figure 7). The Master Power switch supplies power from the 9V battery or the power jack to the board. The power jack accepts a 2.5mm plug with the tip ground and the shell 7 to 12VDC.
- Page 7 The Range Test Area The board features an MT Series remote control transcoder with two push buttons, a buzzer and an LED. The two boards in the kit are populated differently so that the button inputs on one board are outputs on the other board.
- Page 8 The left side of the window contains labels that expand to show links to useful information (Figure 12). This includes the Linx Technologies contact information and links to the website for the latest product documentation and software updates. Clicking on these links opens the page in the computer’s default web...
- Page 9 The “Read Active Settings” button at the bottom (Figure 16) reads the existing configuration settings from the module and adjusts the values in the configuration sections based on the Figure 16: Development Kit PC Software module’s current configuration. The right column in the window starts with the Profile section (Figure 17).
-
Page 10: Board Control
Board Control BOARD CONTROL BOARD CONTROL RE3/MCLR/VPP RB7/PGD RE3/MCLR/VPP RB7/PGD RA0/AN0/SS RB6/PGC RA0/AN0/SS RB6/PGC RA1/AN1 RB5/AN13 RA1/AN1 RB5/AN13 DACOUT/AN2/RA2 RB4/AN11 STDBY DACOUT/AN2/RA2 RB4/AN11 STDBY AN3/RA3 RB3/AN9 TX_SEL DATA_CTL1 DATA_CTL1 AN3/RA3 RB3/AN9 TX_SEL DATA_CTL2 RB2/AN8 RNG_SEL DATA_CTL2 RB2/AN8 RNG_SEL CH_BD_CTL SS/AN4/RA5 RB1/AN10 RX_SEL CH_BD_CTL... -
Page 11: Power Area
Range Test Area RANGE TEST AREA 100K RANGE TEST AREA 100K 0.1uF 100K 100K 100K 100K 100K 100K CRT/LRN 0.1uF ENC_SEL LATCH SER_IO SEL_BAUD 100K 100K 100K CONFIRM MODE_IND NS/DNP TR_PDN T/R_SEL_R TR_SEL 100K 100K DATA_MT TR_DATA CRT/LRN 200 ohm ENC_SEL LATCH 0 ohm... -
Page 12: Signal Routing
Single Routing SIGNAL ROUTING 0.1uF R50 NS/DNP BAUD1_P R51 NS/DNP BAUD1_S BAUD1 R52 NS/DNP RSSI_P BAUD0 R54 NS/DNP RSSI BAUD0_P R55 NS/DNP RSSI_B BAUD0_S 5.1M ALL_EN CH_BD_CTL MC74HC4053A 0.1uF R44 NS/DNP CS1_P R45 NS/DNP CS1_S R46 NS/DNP CS2_P R48 NS/DNP CS0_P R47 NS/DNP R49 NS/DNP... - Page 13 Under no circumstances shall any user be conveyed any license or right to the use or ownership of such items. ©2015 Linx Technologies. All rights reserved. The stylized Linx logo, Wireless Made Simple, WiSE, CipherLinx and the stylized CL logo are trademarks of Linx Technologies.
