- Page 1 HumDT Series Master Development System User's Guide...
- Page 2 Some customers may want Linx radio frequency (“RF”) Warning: products to control machinery or devices remotely, including machinery or devices that can cause death, bodily injuries, and/or property damage if improperly or inadvertently triggered, particularly in industrial settings or other applications implicating life-safety concerns (“Life and Property Safety Situations”).
-
Page 4: Ordering Information
Ordering Information Ordering Information Part Number Description MDEV-***-DT HumDT Series Master Development System HUM-***-DT HumDT Series Transceiver EVM-***-DT HumDT Series Carrier Board MDEV-PGDCK Development System Programming Dock MDEV-PROTO Development System Prototype Board CON-SOC-EVM EVM Module Socket Kit *** = Frequency; 868MHz, 900MHz Figure 2: Ordering Information HumDT Series Transceiver Carrier Board... - Page 5 Prototype Board Figure 6: Prototype Board Prototype Board Objects 1. Carrier Board Socket 2. RP-SMA Antenna Connector 3. Micro USB Connector 4. Power Switch 5. Power LED 6. External Battery Connection 7. Prototyping Area 8. 3.3V Supply Bus 9. Ground Bus 10.
- Page 6 Using the Prototype Board Snap a Carrier Board onto the socket on the Prototype Board as shown in Figure 7. Figure 7: Prototype Board with a Carrier Board Set the power switch (SW3) and connect a micro USB cable into the connector at the top of the board.
- Page 7 Using the Programming Dock Snap a Carrier Board onto the socket on the Programming Dock as shown in Figure 9. Figure 9: Programming Dock with a Carrier Board Connect a micro USB cable into the connector at the top of the board. Plug the other end into a PC.
- Page 8 The Development Kit Demonstration Software The development kit includes software that is used to configure and control the module through the Programming Dock. The software defaults to the Advanced Configuration tab when opened (Figure 10). This window configures the module’s settings. Figure 10: The Master Development System Software Advanced Configuration Tab 1.
- Page 9 The 868MHz version of the module operates on one of 68 channels as opposed to being agile among 4 channels. The software automatically detects the frequency band for the active module and adjusts the selection. The 868MHz module changes the channel selection from the check boxes to a drop-down menu in the Radio section (1).
- Page 10 The Wireless Chat tab (Figure 15) offers a demonstration of sending data between two modules. There is a window for each connected module. Figure 15: The Master Development System Software Wireless Chat Tab 1. The top of the window shows the address of the associated module. 2.
- Page 11 Figure 17: The Master Development System Software Command Set Tab Commands Menu Figure 18: The Master Development System Software Command Set Tab Items Menu Figure 19: The Master Development System Software Show Commands Window – –...
- Page 12 Development Kit Demonstration Software Example This example shows how to configure two modules to work with each other. The software defaults to the Advanced Configuration tab when opened (Figure 21). Figure 21: The Master Development System Software Advanced Configuration Tab at Start-up Install Carrier Boards onto the Programming Docks and plug a USB cable between the Programming Docks and the PC.
- Page 13 Figure 25: The Master Development System Software Dragging to Change the Active Module There are several settings that must match in order for the modules to be able to communicate. This example uses the following settings. • The Encryption Key must match on both modules. This can only be read out of an AP.
- Page 14 Figure 28: The Master Development System Software Network Tab A dotted line appears between the modules indicating that they are joining the network. Figure 29: The Master Development System Software Network Tab A solid line appears between the modules when they are joined and ready to communicate.
-
Page 15: Carrier Board Schematic
TPS2552 LM3940IMP 3.3V Vout Carrier Board Schematic ILIM 100uF 0.47uF nPWREN FAULT 53.6k SIGNAL ROUTING CMD_DATA_OUT Buffer Bypass DNP R48 0 ohm CMD_DATA_IN 330 ohm Buffer Bypass DNP R49 0 ohm nCMD 0 ohm LADJ PAIR 0 ohm Figure 31: HumDT Series Transceiver Carrier Board Module Schematic –... - Page 16 MICROCONTROLLER AREA POWER SUPPLY AREA POWER SUPPLY AREA 5VUSB nPDN 5VUSB TPS2552 TPS2552 LM3940IMP 3.3V LM3940IMP 3.3V Vout Vout VCCP ILIM ICSPDAT ILIM GPIO1 ICSPCLK 100uF 0.47uF nPWREN FAULT MCLR 100uF 53.6k 0.47uF nPWREN FAULT 53.6k R42 DNP PIC16F1825-I/ST Figure 33: Programming Dock Board Power Supply Area Schematic SIGNAL ROUTING SIGNAL ROUTING CMD_DATA_OUT...
- Page 17 MICROCONTROLLER AREA nPDN VCCP ICSPDAT GPIO1 ICSPCLK MCLR R42 DNP PIC16F1825-I/ST 0 Ohm LCD1 LED+ VOUT LED- R27 DNP CMD_DATA_IN 2x16 LCD Figure 36: Programming Dock Board Microcontroller Area Schematic CBUS0 CBUS1 CBUS2 CBUS3 BCD Charger R36 DNP FT230X CMD_DATA_OUT –...
- Page 18 Figure 39: Prototype Board USB Area Schematic – –...
- Page 19 Under no circumstances shall any user be conveyed any license or right to the use or ownership of such items. ©2018 Linx Technologies. All rights reserved. The stylized Linx logo, Wireless Made Simple, WiSE, CipherLinx and the stylized CL logo are trademarks of Linx Technologies.
