- Page 1 + m i d s p a n i n j e c t o r s LifeSafety Power, Inc. | PH 888.577.2898 | TechSupport@LifeSafetyPower.com P03-028 Rev A05...
- Page 2 NPM Installation Manual Description Mounting the NPM Series Module The LifeSafety Power NPM line of PoE MidSpan Injec- The NetPower NPM Midspan Injectors mount using two tors are available at 15.5W (IEEE 802.3af) and 30W (IEEE screws in the mounting tabs. The NPM is also available in 802.3at).
- Page 3 NPM115/130 – Module Overview that have become non-responsive. These terminal strips Data accept wire sizes from AWG14 - AWG22. To shut down the This is the non-PoE input from the network switch. This con- PoE Output, apply any DC voltage within the ratings shown under nector is an RJ45 jack and accepts a CAT-5 cable.
- Page 4 NPM Installation Manual Example Wiring - Block Diagrams a) Powering a PoE Reader 24VAC/VDC Input Shutdown PoE/Data Data Network Switch NPM115/130 NetPower MidSpan 24V DC from Power Supply PoE Compliant Reader or 24V AC b) Powering a PoE Camera Power Shutdown 24VAC/VDC Input Input...
- Page 5 Example Wiring - Block Diagrams (continued) d) Power & Data for a non-PoE IP Camera and Illuminator NetPower MidSpan Power Shutdown 24VAC/VDC Input Input Shutdown PoE/Data Data Network Switch NPM115/130 IR Illuminator NetPower MidSpan 24V DC from Power Supply NPE130 or 24V AC NetPower Extractor...
- Page 6 LifeSafety Power’s only ob- www.lifesafetypower.com ligations are those in the LifeSafety Power Standard Terms and Conditions of Sale for this product, and in no case will Tel (888) 577-2898 LifeSafety Power or its distributors be liable for any incidental, indirect, or consequential damages arising from the info@lifesafetypower.com...
