- Page 1 + m i d s p a n i n j e c t o r s LifeSafety Power, Inc. | PH 888.577.2898 | TechSupport@LifeSafetyPower.com P03-028 Rev A06...
- Page 2 NPE Installation Manual Description Mounting the NPE130 Series Module The NetPower NPE130 PoE power extractor is designed to The NPE130 mounts using two screws in the mounting provide 12VDC, up to a maximum of 25W output power, to a tabs. The NPE130 is also available in a DIN Rail mount- non-PoE IP device (e.g.
- Page 3 NPE130 – Module Overview Data Mounting Tab This is the non-PoE network connection to a non-PoE cam- The mounting tab centers are spaced 3.85" on center. Refer to era or other non-PoE device. This connector is an RJ45 jack the mounting guide (page 1) for mounting details.
- Page 4 NPE Installation Manual Example Wiring - Block Diagrams a) Powering a non-PoE IP Camera using a PoE Switch and NPE130 Extractor PoE Switch No Connection Class PoE/Data Select NPE130 12V DC Data 12V@13W Max Power Non POE – Output IP Camera Data b) Powering a non-PoE IP camera using a PoE Switch and NPE130 Extractor...
- Page 5 Example Wiring - Block Diagrams (continued) c) Powering a non-PoE Reader using a non-PoE Switch, NPM115 Injector, and NPE130 Extractor Non-PoE Network Switch PoE/Data Shutdown NPM115 24V DC Input Data – No Connection Class PoE/Data Select NPE130 12V DC 12V@ 13W Max Data –...
- Page 6 LifeSafety Power’s only ob- www.lifesafetypower.com ligations are those in the LifeSafety Power Standard Terms and Conditions of Sale for this product, and in no case will Tel (888) 577-2898 LifeSafety Power or its distributors be liable for any incidental, indirect, or consequential damages arising from the info1@lifesafetypower.com...
