Off-Road Navigation
PRELIMINARY DRAFT
Off-Road Navigation
Great for off-road enthusiasts, the 750
'
Off-Road Navigation option allows
NAV
S
marking of favorite trails, hunting, and fishing spots. With this option the user
can route to points not on roads, set landmarks, create trails, and more.
Off-Road is a navigation mode separate from turn by turn navigation and
provides the user with the feel of being a separate product. Once Off-Road
mode is entered, the unit is functionally transformed into a product, which works
just like Magellan's famous hand held GPS receiver.
Features
Enter navigation points (waypoints) by marking a waypoint by the systems
current position, using the systems cursor, or by entering latitude and longitude
coordinates. The maximum number of waypoints the system is capable of
saving into memory is 100.
Create routes by inserting waypoints into a route list. The 750
, guides the
NAV
user from point to point by visually connecting the waypoints with highlighted
lines in the order of the route lists. The navigation system then provides
directional instruction to the next waypoint in the route. Waypoint to waypoint
navigation continues in this fashion progressively through the list of waypoints
making up the route. Once the final waypoint in the list is navigated to, the you
have arrived voice prompt is heard followed by 3 double chimes. Also a
destination screen will be displayed showing the waypoint name and the
Lat/Long coordinates of the waypoint. The maximum number of routes the
systems can save into memory is 10 with 25 waypoints max. for each route.
Reverse Route - Calculate a route from the last waypoint in the list to the first
waypoint.
Next Waypoint - Navigate to the next waypoint in a route list, allows the user to
step through a route list or skip the next waypoint while driving a route.
The Inclinometer Sensor shows how aggressive the terrain is by
showing graphics with pitch and roll readings of the vehicles current
position.
- 1 -

Advertisement

loading

Related Manuals for Magellan 750NAV

Summary of Contents for Magellan 750NAV

  • Page 1 Once Off-Road mode is entered, the unit is functionally transformed into a product, which works just like Magellan’s famous hand held GPS receiver. Features Enter navigation points (waypoints) by marking a waypoint by the systems current position, using the systems cursor, or by entering latitude and longitude coordinates.
  • Page 2 Step 2: Select the Configuration icon, press ENTER. Step 3: Scroll to Unlock/Lock Features, press ENTER. Step 4: Call Magellan Customer Service, press ENTER. Step 5: Customer Service will ask for the H/W version to acquire an unlock code, press ENTER.
  • Page 3 Step 6: Scroll to Off-Road Navigation, press ENTER. Step 7: Using the QuickSpell screen enter the unlock code into the system, press ENTER. Step 8: After inputting the correct unlock code into the system, power the system off by pressing the POWER button. After proper system shutdown, press the POWER button again to turn the navigation system back on.

  • Page 4: Option Menu Features

    Option Menu Features To access the Off-Road Option menu features, press the OPTION button. Select the Configuration icon, press ENTER. Select Off-Road Navigation, press ENTER. Track On The tracking feature may be used to “backtrack” the vehicle’s route. The “Breadcrumb Trail” left on the map display will be in the form of a blue dashed line.
  • Page 5 The Extended Detail feature will display heading and bearing information on the map screen. To turn this feature on or off simply highlight Ext. Detail in the Off- Road options menu and press ENTER. When the color of the X changes to blue the feature is on.
  • Page 6 The XTE Alarm is the cross track error alarm. While in route guidance mode, the XTE Alarm will chime when you are off track by the selected distance. The distance is adjustable between off and 1 mile. Or from off to 1.5 kilometers, if using the metric system.
  • Page 7 Clear The Clear feature will generate an Off-Road Clear list. From this screen Track History, Routes, or Routes/Waypoints can be cleared from the systems memory. To generate the clear list, press ENTER on Clear. Pressing ENTER on Track History will prompt the user with a yes or no to clear Track History.
  • Page 8 Pressing ENTER on All will prompt the user with a Yes or No to clear All of the Track History, Routes, and Waypoints. Start Using Off-Road Navigation Select the Off-Road Navigation icon from the main menu and press ENTER. Off-Road Selections Menu Setting Waypoints, Creating Routes, Next Waypoint, Reverse Route, and Inclinometer are all accessed in the Off-Road Selections Menu.

  • Page 9: Setting Waypoints

    Setting Waypoints Press ENTER from the Map View screen. To set waypoints from the current position, press ENTER on Mark By Position. After using the Mark By Position function the user may save the position name as WAY001. The next waypoint saved will be WAY002 and the numbers will increment after each waypoint is saved.
  • Page 10 Using the QuickSpell screen, delete the current waypoint name and spell the desired name (6-character max.). The waypoint icons are a good way to identify characteristics of specific trails (the default waypoint icon is a red flag). To select a new waypoint icon, select the waypoint icon box and press ENTER.
  • Page 11 Using the QuickSpell Screen input the desired description (35-character max.) and press ENTER. After making any changes to the waypoint scroll to save and press ENTER. A waypoint may be saved using Lat/Long coordinates. Highlight the Lat/Long coordinates and press ENTER. Using the arrow buttons highlight the value you would like to change then use the + - keys to adjust the values to the desired coordinates.
  • Page 12 After the desired Lat/Long coordinates are entered, scroll to save and press ENTER. Waypoints may also be entered by using the Mark By Cursor feature. While viewing the map, use the arrow keys to pan the map display for the desired location and press ENTER.
  • Page 13 Deleting Waypoints To delete a waypoint from the waypoint list. Press ENTER on Select Route/Waypoint. Press ENTER on Waypoints By Name, Waypoints By Distance, or Waypoints By Time. Select the waypoint and Press ENTER. Select Delete and press ENTER. - 13 -...
  • Page 14 Select Yes and press ENTER. Edit Waypoint To Edit a waypoint from the waypoint list. Press ENTER on Select Route/Waypoint. Press ENTER on Waypoints By Name, Waypoints By Distance, or Waypoints By Time. Select the waypoint and Press ENTER. - 14 -...

  • Page 15: Create A Route

    Select Edit and press ENTER. After making the desired changes, scroll to Save and press ENTER. Create a Route To save waypoints into a route scroll to Select Route/Waypoint and press ENTER. Select All Routes and press ENTER. - 15 -...
  • Page 16 Choose an empty Route and press ENTER. Press ENTER on Edit. Press ENTER on Insert Waypoint. Press ENTER on each waypoint that will make up the route. - 16 -...
  • Page 17 After all the waypoints are inserted for the desired route scroll down to Save and press ENTER. Press ENTER on Route to start Route Guidance. Route guidance screen. Press ENTER from the guidance screen to arrive at the Off-Road Selections menu.
  • Page 18 To bypass a waypoint select Next Waypoint and press ENTER. Select Yes and press ENTER. To reverse the route select Reverse Route and press ENTER. Select Yes and press ENTER. - 18 -...
  • Page 19 Off-Road Navigation Route Guidance After creating a route the 750 guides the user to each waypoint. As the user drives past each waypoint the arrival alarm will chime. The arrival alarm is adjustable between off and 1 mile. Or between off and 1.5 kilometers. See the off-road options section on page 5 to adjust the arrival alarm.
  • Page 20 Once the final waypoint in the list is navigated to, the you have arrived voice prompt is heard followed by 3 double chimes. Also a destination screen will be displayed showing the final waypoint name and the Lat/Long coordinates of the waypoint.
  • Page 21 Now select Route and Press ENTER. Inclinometer The inclinometer can be accessed in the Off-Road Selections menu. Press ENTER on Inclinometer. The pitch and roll readings of the vehicle will be displayed while driving. This feature is useful when driving across or up steep inclines, letting the driver know how aggressive the terrain is.
