Intel® Atom™ N270 processor SBC for Panel PC
Delivery Package Items
HS-8605 Board x 1
Installation Quick Start x 1
Utility CD Disk x 1
Keep all the parts of the delivery package intact and store them in a
safe/dry place for any unforeseen event requiring you to return this
product. If you discover any missing and/or damaged items from the list
of items, please contact your dealer immediately.
Default Jumper Settings
Before turning on the power to the HS-8605, please make sure that all
jumpers are on their default settings.
Jumper
CN12
COM 6 Use RS-232 or RS-422/485 Select: RS-232
JP2
Clear CMOS: Normal Operation
JP3
AT/ATX Power Mode Select: ATX
JP4
LAN1 Enabled/Disabled Select: Enabled
JP5
Panel Voltage Select: +3.3V
JP6
CF Use Master/Slave Select: Slave
JP7
COM 1 Voltage Output Select: RI
JP8
COM 2 Voltage Output Select: RI
JP9
COM 3 Voltage Output Select: RI
JP10
COM 4 Voltage Output Select: RI
©Copyright 2011 BOSER Technology Co., Ltd.
HS-8605
Default Setting
Setting
Open
Open
Open
Open
Short 1-2
Open
Short 1-2
Short 1-2
Short 1-2
Short 1-2
v0.1 July 2011
