- Page 1 Beta INSTRUCTIONS...
- Page 2 AIR RIVETER item 1946C 7,8 (from sn 00900-01099) Part. No. Code Description Part. No. Code Description Nosepiece 5,6 mm 37-1 019460970 019460901 Cylinder Cap Nosepiece 4,8 mm 37-2 019460971 Rubber Bottom 019460902 Nosepiece 7,8 mm 37-3 019460972 Air Cylinder Body...
- Page 4 INSTALLATION SYSTEM Beta 1 AIR COMPRESSOR 2 AIR TANK 3 AUTOMATIC CONDENSATE DRAIN 4 MAIN FILTER 5 MAIN PIPEWORK 6 SUPPLY LINE 7 CONDENSATE DRAIN 8 FILTER-REGULATOR-LUBRICATOR 1/4” 9 COUPLER 1/4” 10 COUPLING 1/4” 11 HOSE 10 mm 12 COUPLER 1/4” 13 COUPLING 1/4”...
- Page 5 AIR RIVETER RISKS RELATED TO WORKING CONDITIONS Mind too long hoses left at the work station; stumbling and item 1946C 7,8 falling is likely to result in severe injury. High noise levels may result in permanent loss of hearing; INSTRUCTION MANUAL FOR AIR RIVETERS wear ear protection, as recommended by the employer and/or the regulations.
- Page 6 A. Preparing air riveter B. Using air riveter Follow the steps below to install the required rivet nozzle: – Open the air inlet (part 65), to let air into the air riveter. – Loosen and remove the screw (part 37). To make it easier While using the air riveter, the air inlet (part 65) must be to replace the nozzle, unscrew the nozzle holder by 2 or 3 open, to allow rivet suction.
-
Page 7: Maintenance
This warranty explicitly excludes any damage to people and/or things, whether direct or consequential. When it comes to quality air tools & compressors, Beta Tools is the brand you can depend on.
