Northern Telecom DMS-100 Series General Description, Installation And Maintenance page 18

PRACTICE 297-2011-201
Chart 5-1
STATION RINGER TEST - KEY SEQUENCES
•
Perform operations in the order as given in this Chart.
• Operate key or switch as given in the "Key or Switch" column. The response must be as given in the
"Response" column. LCD and key numbering are given in Fig. 5-1.
•
The column headed "Messages Used" indicates the messages generated to produce the correct
response.
Note: Key # 9 has no associated, working LCD indicator. In all cases where "All LCDs ....." is
given, the LCD window # 9 remains OFF.
KEY OR SWITCH
STEP OPERATED
1 Handset OFF-HOOK
2 Handset ON-HOOK
3 Handset OFF-HOOK
4 Handset ON-HOOK
Dial Pad key 1
5
6 Dial Pad key 2
7 Dial Pad key 3
8 Dial Pad key 4
9 Dial Pad key 5
Dial Pad key 6
10
11 Dial Pad key 7
12 Dial Pad key 8
13 Dial Pad key 9
14 Dial Pad key 0
Dial Pad key *
15
16
Chart Continued --------------------------------
Page 5-2
Note: The system will not attempt to restore any LCD to its pre-test
state. The LCDs will be OFF at the end of the test, with features in the
same state as before the test. A background audit restores all feature
indicators at its next occurrence (audit intervals are switch and load
related). Any newly activated features after termination of the test
procedure will be indicated normally. No incoming calls can be
received for the duration of a Station Ringer Test. In order to prevent
prolonged line blockages, this test is limited to a 7 minute interval
after which the line will automatically be restored to normal and the
test terminated.
RESPONSE OBSERVED
All LCDs FLASH
All LCDs WINK
All LCDs ON
All LCDs OFF
LCD 1 ON
LCD 2 ON
LCD 3 ON
LCD 4 ON
LCD 5 ON
LCD 6 ON
LCD 7 ON
LCD 8 ON
LCDs 1 & 8 ON
LCDs 2 & 8 ON
All LCDs ON
MESSAGES USED
LCD indicator FLASH
LCD indicator WINK
LCD indicator ON
LCD indicator OFF
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, CLD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Save Indicator Status
