T W I N / T W I N LADDER B U N K B E D
FULL / FULL LADDER B U N K B E D
Use only correct mattress dimensions and Bunkie board:
Twin size - 74" - 75" long and 37-1/2"-38-1/2" wide
Full size - 74" - 75" long and 52-1/2"-53-1/2" wide
MONTANA 2.0 - MONTANA ESPRESSO - PACKAGE#3591480P
RTG SKU#
STYLE#
35414806
MNT2-10-48
35514808
MNT2-11-48
35614800
MNT2-12-48
36214803
MNT2-25-48
MONTANA 2.0 - MONTANA ESPRESSO - PACKAGE# 3601480P
RTG SKU#
STYLE#
35414802
MNT2-13-48
35514804
MNT2-14-48
35614806
MNT2-15-48
36214803
MNT2-25-48
PLEASE CONTACT YOUR RETAIL STORE WITH SERVICE OR PARTS REPLACEMENT REQUEST
Version #1 - 2/10/2021
M O N T A N A 2 . 0
Futon size - 75" long and 53" wide
ITEM DESCRIPTION
UPPER TWIN HB & FB
LOWER TWIN HB & FB
RAILS W/ TWIN SLATS
LADDER
ITEM DESCRIPTION
UPPER FULL HB & FB
LOWER FULL HB & FB
RAILS W/ FULL SLATS
LADDER
MONTANA 2.0 - MONTANA DRIFTWOOD - PACKAGE#3591482P
RTG SKU#
STYLE#
MNT2-10-39N
35414820
35514822
MNT2-11-39N
35614824
MNT2-12-39N
36214827
MNT2-25-39N
MONTANA 2.0 - MONTANA DRIFTWOOD - PACKAGE#3601482P
RTG SKU#
STYLE#
MNT2-13-39N
35414826
35514828
MNT2-14-39N
35614820
MNT2-15-39N
36214827
MNT2-25-39N
ITEM DESCRIPTION
UPPER TWIN HB & FB
LOWER TWIN HB & FB
RAILS W/ TWIN SLATS
LADDER
ITEM DESCRIPTION
UPPER FULL HB & FB
LOWER FULL HB & FB
RAILS W/ FULL SLATS
LADDER
Page #1
