Migatronic AUTOMIG 2 Quick Manual

AUTOMIG II - Factory setting
Setting possibilities Area
Primary parameters:
1 Welding current Area depends on
program
Wire feed speed
Thickness of material
2 Arc length -9.9 - +9.9
Secondary parameters:
1 Inductance -5.0 - +5.0
2 Gas pre flow 0.0 - 10.0
3 Soft start Off / 1.5 - 18.0
4 Hotstart time 0.0 - 10.0
5 Slope down 0.0 - 10.0
6 Burnback 1 - 30
7 Gas post flow 0.0 - 10.0
9 Stop amp 0 - 100
r Remote control 0 = internal
1 = torch control
Step Factory setting Unit
2T
1 Depending on A
program
0.1 m/min
0.1 mm
0.1 0.0 V
0.1 0.0 -
0.1 0.2 s
0.1 1.5 m/min
0.1 0.5 s
0.1 0.2 s
1 5 ms
0.1 3 s
1 50 %
50113773 E
QUICKGUIDE AUTOMIG
Programs
No. Wire Material
P106 Ø 0.6 mm Fe SG2 ER70S6
P101 Ø 0.8 mm Fe SG2 ER70S6
P109 Ø 0.9 mm Fe SG2 ER70S6
P102 Ø 1.0 mm Fe SG2 ER70S6
P116 Ø 0.6 mm Fe SG2 ER70S6
P111 Ø 0.8 mm Fe SG2 ER70S6
P119 Ø 0.9 mm Fe SG2 ER70S6
P112 Ø 1.0 mm Fe SG2 ER70S6
P311 Ø 0.8 mm AlMg5 ER5356
P319 Ø 0.9 mm AlMg5 ER5356
P312 Ø 1.0 mm AlMg ER5356/ER5554
P359 Ø 0.9 mm AlSi5 ER4043
P352 Ø 1.0 mm AlSi5 ER4043
P369 Ø 0.9 mm AlMg3Mn ER5554
P372 Ø 1.0 mm AlSi12 ER4047
P501 Ø 0.8 mm CuAl8 Brazing
P509 Ø 0.9 mm CuAl8 Brazing
P502 Ø 1.0 mm CuAl8 Brazing
P561 Ø 0.8 mm CuSi3 Brazing
P569 Ø 0.9 mm CuSi3 Brazing
P562 Ø 1.0 mm CuSi3 Brazing
2
UK
Gas
CO
2
CO
2
CO
2
CO
2
ArCO (82/18)
2
ArCO (82/18)
2
ArCO (82/18)
2
ArCO (82/18)
2
Ar
Ar
Ar (100)
Ar (100)
Ar
Ar (100)
Ar (100)
ArCO (98/2)
2
ArCO (98/2)
2
ArCO (98/2)
2
ArCO (98/2)
2
Ar (100)
ArCO (98/2)
2
