General safety and design considerations Introduction Safety System information Important safety conditions Maintenance System maintenance Maintenance instructions Introduction to drive units Slip clutch adjustment Inspection – drive units Inspection – conveyor chains Inspection – slide rails, beams, idlers, bends 19 Inspection –...
General safety and design considerations General safety and design considerations Introduction 1.1.1 Critical factor To achieve an operational installation which is reasonably safe for all people involved in its use and maintenance, it is necessary to consider certain as- pects. This is done when designing a conveyor system. The chain is gen- erally the critical factor to consider with guarding.
Page 7
General safety and design considerations 1.1.2.1 Safeguarding can be achieved by: • Location Location of all hazardous areas away from areas occupied by personnel, wherever possible. • Guards Mechanical barriers preventing entry into hazardous areas or protecting against falling objects. •...
Safety Safety The machine has been designed in such a way, that it can be used and maintained in a safe way. This holds for the application, the circumstances and the instructions described in this manual. Any person working with or around this machine should study the manual and follow the instructions.
Page 9
Safety 2.2.1 General • Incorrect use of the equipment can cause personal injury. • Do not stand or climb on the equipment. • Do not wear clothing or other articles that can fasten in the ma- chine. • For coupled drive units, safety protection should be applied to the connecting shaft.
Page 10
Safety 2.2.1.6 Cleated chains • Any application incorporating cleated chains requires careful safe- ty consideration. Pinch and shear points are generated through- out the assembly of the incorporated components. Therefore generous guarding should always be employed to fully protect within user operating areas. •...
Page 11
Safety 2.2.2 Maintenance and Service technicians Service technicians must have: • Sufficient knowledge for reading technical information • Ability to comprehend technical drawings • Basic knowledge of mechanics • Sufficient knowledge in the use of hand tools • Skilled (EN ISO 12100:2010) 2.2.3 Electricians Electricians must have:...
Maintenance Maintenance System maintenance 3.1.1 Introduction The following section is designed to offer assistance for your planned maintenance schedule. It may become evident that the suggested mainte- nance intervals can be shortened or extended to accommodate your local environmental conditions. Maintenance of the FlexLink conveyor systems should only be carried out by competent persons, who are familiar with FlexLink equipment.
Maintenance Maintenance instructions 3.2.1 Introduction This maintenance manual contains directions for the standard components sold through the X85, X180 and X300 chapters of the FlexLink main cata- logue. For non-FlexLink components, such as motors, pneumatic equip- ment, control systems etc., the manufacturer’s maintenance instructions apply.
Maintenance Introduction to drive units 3.3.1 Three types There are three different types of drive units: end drive, intermediate drive and horizontal bend drive units End drive units End drive unit with return chain, located at the ‘pulling’ end of the conveyor.
Maintenance Slip clutch adjustment 3.4.1 Introduction The slip clutch on the drive unit is a safety device which allows the chain to stop if the load becomes excessive. It has two purposes: • Prevent damage to conveyor • Prevent damage to the products on the conveyor Where a slip clutch is fitted, it must be adjusted so that it does not slip whenever the drive unit is started under full load.
Page 16
Maintenance 3.4.2 Clutch adjustment 1 Remove the drive unit protection cover. 2 Use an Allen key, 3 mm, to loosen the screw (1) on the slip clutch so that the adjustment nut (2) can be freely rotated. 3 Turn the adjustment nut (2) clockwise with a hook spanner until the arrow on the nut is aligned with the desired F...
Maintenance Inspection – drive units 3.5.1 Roller chain transmission The roller chain transmission should be checked and lubricated after 50, 250, 500 hours of operation, and then every 500 hours. If the roller chain transmission is not fitted with a chain tensioner the chain tension should be checked on this occasion.
Page 18
Maintenance 3.5.4 General checks on drive unit Carry out a general inspection of the drive unit. • Check particularly that the protective covers for the roller chains are complete and firmly in place. • Replace damaged/worn parts. 5814EN-05...
Maintenance Inspection – conveyor chains 3.6.1 Conveyor chains The most common types of conveyor chains are: • Plain conveyor chains • Chain with flexible cleats for vertical wedge convey- • Chain with friction surface for conveyors with an in- cline up to 30°. The friction surfaces are normally dis- tributed over the chain at a predetermined distance.
Page 20
Maintenance 3.6.2 Checking the tension of conveyor chain The chain is made of elastic material. The chain eventually stretches as the material creeps. The extent of the stretch depends on the traction force in the chain. The stretch shows itself as slack on the return side of the drive unit.
Page 21
Maintenance 3.6.4 Shortening conveyor chains The most suitable place to shorten the chain is at the drive unit. Alternatively: • at a beam section for chain installation which has detachable sec- tions. • by removing the side plates of the drive or idler end unit in closed systems.
Page 22
Maintenance Instructions 1 Make the conveyor chain accessible at some of the overhead positions. 2 Remove the steel pin (1) from the pivot (2). Use the pin insertion tool (see figure). 5814EN-05...
Page 23
Maintenance 3 Remove the necessary number of link NB: With cleated or friction chains, pay attention to the divisions between the links. 4 Join the chain together with a new pivot. NB: The old pivot should not be re- used. When the chain is divided, a new pivot must always be fitted.
Maintenance Inspection – slide rails, beams, idlers, bends 3.7 .1 Checking slide rails The condition of the slide rails is fundamental to the functioning of the in- stallation. It is therefore essential that these are in good condition. 3.7 .1.1 Checking the slide rail with the conveyor chain in place The slide rail must be checked after every 250 hours’...
Page 25
Maintenance 3.7 .1.2 Checking the slide rail, conveyor chain removed At least once a year or after every 2 000 hours’ operation, the chain should be removed from the beam, and the slide rail carefully checked for wear and fastening. Plain bends should be checked after every 500 hours’...
Maintenance Inspection – safety devices Protective and safety devices Safety devices should be checked at regular intervals. • Check the protective cover on the cleated chain conveyor return chain. • Drive units type H, have a slack protection for the conveyor chain. Check that the slack protection plates are in place, and that the chain does not slacken enough to hang below the plates.
Maintenance Replacement of worn parts – conveyor chain 3.9.1 Removal of conveyor chain Ensure that the power to the drive motor is disconnected. Disengage the motor; there are various methods depending on the type of drive unit: – Detach the slip clutch. –...
Maintenance 3.10 Replacement of worn parts – slide rails 3.10.1 General information It is very important to assemble slide rails correctly to ensure smooth sys- tem operation. Follow the illustrated instructions on the following pages carefully. Ob- serve the following points: •...
Page 29
Maintenance When fitting the slide rails with rivets, the instructions on page 25 must be followed. • The joints on the slide rails must have a distance of 100 mm be- tween them. The joints should be laid out as in the picture, se page 19 for reference, with a gap of approx.
Page 30
Maintenance Installation of Slide rails (continued) Method 1: Using aluminium rivets Rivet crimping pliers/rivet crimping clamp Aluminium rivets XLAH 4x7 Insert rivets in the holes, using rivet crimping pliers or a rivet crimping clamp. If working space is limited, the rivet crimping clamp might be easier to use.
Page 31
Maintenance Installation of slide rail (continued) Method 2: Using plastic screws Pliers/screwdriver Knife Hammer Plastic screws XLAG 5 Press or screw the plastic screws into the holes using a pair of pliers or a screwdriver. Cut off the screw heads by using a knife and a hammer.
Troubleshooting Troubleshooting Jerky running Cause Corrective action Damaged or badly Inspect and replace if fitted slide rail necessary. Wrongly adjusted Check and adjust slip slip clutch clutch. Worn transmission Check/replace parts transmission chain, chain drive sprocket. Conveyor chain is Tension conveyor chain too tight/loose correctly.
Page 33
Troubleshooting Noise Cause Corrective action Worn or damaged Check/replace drive unit. bearings in drive unit Damaged/badly Check the free running fitted slide rail of the conveyor chain, especially in slide rail joints. Excessive conveyor Lower speed. speed Check actual load against recommended load.
Troubleshooting Checklist/maintenance schedule General checks Number of operating hours/time interval See page Check roller chain, sprocket, chain Then every 500 page 12 tension and lubrication of drive unit hours Check/adjustment of slip clutch Every 1 000 hours page 10 Check conveyor chain guides in drive Every 1 000 hours page 12 units and idler ends...
System dismantling and disposal System dismantling and disposal Important safety precautions 5.1.1 Dismantling Dismantling of the FlexLink conveyor system should be carried out by com- petent persons, who are familiar with the equipment being decommis- sioned. In the absence of detailed information, every care should be taken to en- sure that all items are securely retained during the decommissioning pro- cess.
System dismantling and disposal Dismantling end drive units with suspended motor The locking effect of the slip clutch can be removed by removing the trans- mission chain or by releasing the slip clutch (section in maintenance and service refers to slip clutch adjustment). Remove the motor gear unit from the conveyor drive assembly.
Page 37
System dismantling and disposal 5814EN-05...
System dismantling and disposal Dismantling end drive units, no slip clutch Remove the motor gear unit from the conveyor drive assembly. The motor gear unit may be fitted with an oil breather. Ensure that the oil from the gearbox cannot leak into the surrounding area when decommissioned. Oil should be drained from the gearbox and disposed of in accordance with lo- cal environmental regulations.
System dismantling and disposal Remove the conveyor chain Split the conveyor chain using the pin insertion tool and remove the con- veyor chain. If removing conveyor chain from over head conveyor special attention should be given when removing the last few metres. The weight of the removed chain accelerates the removal from the conveyor beams and can cause injury when the last links exit the extrusion.
System dismantling and disposal Dismantling end drive units Unscrew the inner grub screws from the drive unit connector strips and re- move drive end from the conveyor. Repeat for idler end unit. 5814EN-05...
System dismantling and disposal Remove slide rails Remove the slide rail on all sides of the conveyor extrusion. Remove the slide rail retaining fixings by drilling away the rivets or plastic screws and pulling away the slide rail from the aluminium extrusion profile. 5814EN-05...
System dismantling and disposal Dismantle the conveyor extrusions from the support brackets. Dismantle the conveyor extrusions from the support brackets. This should be done in a systematic manner, removing conveyor section by section. 5814EN-05...
System dismantling and disposal 5.11 Recycle Sort different materials ready for disposal. Recycle components in accordance with local regulations. Material categories Aluminium Beams, bends, support legs etc. • Extruded aluminium Brackets, feet etc. • Die cast aluminium Electronics Motors and all other electronics Plastics Chains •...
Page 47
System dismantling and disposal 5814EN-05...
