MAXI200 Installation Manual
Phase 7 / 650,000 Btu/hr with Tilting Options
WARNING: For your safety the information
in this manual must be followed to
minimize the risk of fire or explosion and
to prevent property damage, personal
injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Clear the room, building or area of
all occupants.
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
Maxidry
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou
la mort.
—Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
—QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareils.
Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
Évacuez la pièce, le bâtiment ou la
zone.
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
—L'installation et l'entretien doivent être
assurés par un installateur ou un
service d'entretien qualifié ou par le
fournisseur de gaz.
Part No. 113261-1
Advertisement
Table of Contents
Related Manuals for MAXIDRY MAXI200
Summary of Contents for MAXIDRY MAXI200
- Page 1 MAXI200 Installation Manual Phase 7 / 650,000 Btu/hr with Tilting Options AVERTISSEMENT: Assurez-vous de bien WARNING: For your safety the information suivre les instructions données dans cette in this manual must be followed to notice pour réduire au minimum le risque minimize the risk of fire or explosion and d’incendie ou d’explosion ou pour éviter...
- Page 2 The illustrations included in this manual may not depict your particular dryer exactly. IMPORTANT For your convenience, log the following information: MAXI200 PH7 Tilting DATE OF PURCHASE _____________________________________________ MODEL NO. __________________________ RESELLER’S NAME __________________________________________________________________________________ SERIAL NUMBER(S) __________________________________________________________________________________...
- Page 3 WARNING Proposition 65 Use of this product could expose you to substances from fuel combustion that contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. In the State of Massachusetts, the following installation instructions apply: Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by the State of Massachusetts.
- Page 4 FOR YOUR SAFETY DO NOT DRY MOP HEADS IN THE DRYER. DO NOT USE DRYER IN THE PRESENCE OF DRY CLEANING FUMES. WARNING UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices ever be disabled. WARNING The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
-
Page 5: Table Of Contents
Table of Contents SECTION I IMPORTANT INFORMATION ...................... 3 A. Receiving and Handling ....................3 B. Safety Precautions ......................4 SECTION II SPECIFICATIONS AND TILTING DIMENSIONS ................ 6 A. Specifications ........................6 B. Dimensions and Location ....................7 SECTION III INSTALLATION PROCEDURES .................... - Page 6 SECTION VI ROUTINE MAINTENANCE ....................... 59 A. Cleaning ......................... 59 B. Adjustments ........................61 C. Lubrication ........................61 SECTION VII COMPONENT SYSTEM DESCRIPTIONS ................62 A. Tumbler Drive System ..................... 62 B. Tumbler ........................... 63 C. Air Blower Drive System ....................63 D.
-
Page 7: Important Information
SECTION I IMPORTANT INFORMATION A. RECEIVING AND HANDLING The dryer is shipped in a protective stretch wrap cover with protective cardboard corners as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and wooden skid should be visually inspected for shipping damage. -
Page 8: Safety Precautions
B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the base panels, tilt guards, or side access doors removed. - Page 9 WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubber materials. Drying in a heated tumbler may damage plastics or rubber and may be a fire hazard. 7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork, and inside the dryer.
-
Page 10: Specifications And Tilting Dimensions
SECTION II SPECIFICATIONS AND TILTING DIMENSIONS A. SPECIFICATIONS 90.9 kg MAXIMUM CAPACITY (DRY WEIGHT) 200 lb TUMBLER DIAMETER 62-1/2” 158.75 cm 106.7 cm TUMBLER DEPTH 42” 2,109.60 L TUMBLER VOLUME 74.5 cu ft TUMBLER / DRIVE MOTOR 3 hp 2.24 kW 93.3 cm x 109.2 cm DOOR OPENING (DIAMETER) 36-3/4”... -
Page 11: Dimensions And Location
B. DIMENSIONS AND LOCATION NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1... - Page 12 NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
- Page 13 NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
-
Page 14: Installation Procedures
SECTION III INSTALLATION PROCEDURES Installation in a proper location should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable American National Standards: National Fuel Gas Code ANSI.Z223.1-LATEST EDITION and/or National Electrical Code ANSI/NFPA NO. 70- LATEST EDITION, or in Canada, the Canadian Electrical Codes Parts 1 &... - Page 15 1. Reassembly Instructions For Gas Dryer Shipped In Two Pieces 1 DOOR/2-WAY TILT NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
- Page 16 1 DOOR/2-WAY TILT 113261 - 1...
- Page 17 a. Reassembly For 1 Door/2-Way Tilt Gas Dryers Lift the tumbler section onto the base. 1) 2-way tilt dryers have four (4) tilting pistons in the base, one (1) on each corner. On the top of each piston is a clevis block. Use the four (4) 1/2” x 1-1/8” hex head bolts with lock washers to secure each piston clevis block to the bottom of the tumbler section.
- Page 18 2. Reassembly Instructions For Gas Dryer Shipped In Two Pieces 1 DOOR/FORWARD TILT NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
- Page 19 1 DOOR/FORWARD TILT 113261 - 1...
- Page 20 a. Reassembly For 1 Door/Forward Tilt Gas Dryers Lift the tumbler section onto the base. 1) Forward tilt dryers have two (2) tilting pistons in the rear of the base. On the top of each piston is a clevis block. Use the two (2) 1/2” x 1-1/2” hex head bolts with lock washers to secure each piston clevis block to the bottom of the tumbler section.
- Page 21 3. Reassembly Instructions For Gas Dryer Shipped In Two Pieces 2 DOOR/REAR TILT (PASS THRU) NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
- Page 22 2 DOOR/REAR TILT (PASS THRU) 113261 - 1...
- Page 23 a. Reassembly For 2 Door/Rear Tilt (Pass Thru) Gas Dryers Lift the tumbler section onto the base. 1) Rear tilt dryers have two (2) tilting pistons in the rear of the base. On the top of each piston is a clevis block.
- Page 24 4. Reassembly Instructions For Steam Dryer Shipped In Two Pieces 1 DOOR/2-WAY TILT NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
- Page 25 1 DOOR/2-WAY TILT 113261 - 1...
- Page 26 a. Reassembly For 1 Door/2-Way Tilt Steam Dryers Lift the tumbler section onto the base. 1) 2-way tilt dryers have four (4) tilting pistons in the base, one (1) on each corner. On the top of each piston is a clevis block. Use the four (4) 1/2” x 1-1/8” hex head bolts with lock washers to secure each piston clevis block to the bottom of the tumbler section.
- Page 27 5. Reassembly Instructions For Steam Dryer Shipped In Two Pieces 1 DOOR/FORWARD TILT NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
- Page 28 1 DOOR/FORWARD TILT 113261 - 1...
- Page 29 a. Reassembly For 1 Door/Forward Tilt Steam Dryers Lift the tumbler section onto the base. 1) Forward tilt dryers have two (2) tilting pistons in the base, one (1) on each corner. On the top of each piston is a clevis block. Use the two (2) 1/2” x 1-1/2” hex head bolts with lock washers to secure each piston clevis block to the bottom of the tumbler section.
- Page 30 6. Reassembly Instructions For Steam Dryer Shipped In Two Pieces 2 DOOR/REAR TILT (PASS THRU) NOTE: The manufacturer reserves the right to make changes in specifications at any time, without notice or obligation. 113261 - 1...
- Page 31 2 DOOR/REAR TILT (PASS THRU) 113261 - 1...
- Page 32 a. Reassembly For 2 Door/Rear Tilt Steam Dryers Lift the tumbler section onto the base. 1) Rear tilt dryers have two (2) tilting pistons in the base. On the top of each piston is a clevis block. Use the two (2) 1/2” x 1-1/2” hex head bolts with lock washers to secure each piston clevis block to the bottom of the tumbler section.
-
Page 33: Location Requirements
B. LOCATION REQUIREMENTS Before installing the dryer, be sure the location conforms to local codes and ordinances. In the absence of such codes or ordinances the location must conform with the National Fuel Gas Code ANSI.Z223.1 LATEST EDITION, or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General Installation and Gas Plumbing). -
Page 34: Fresh Air Supply Requirements
C. FRESH AIR SUPPLY REQUIREMENTS When the dryer is operating, it draws in room air, heats it, passes this air through the tumbler, and exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If the make-up air is inadequate, drying time and efficiency will be adversely affected. -
Page 35: Exhaust Requirements
D. EXHAUST REQUIREMENTS NOTE: For 1 door dryers, the 20-inch (50.8 cm) diameter exhaust duct exits from the rear of the base. For 2 door dryers, the 20-inch (50.8 cm) diameter exhaust duct exits from the left side of the base. - Page 36 The internal dimensions of the dryer’s rectangular exhaust vent ductwork are 8-inches x 20-inches (20.3 cm x 50.8 cm). A transition piece 20-inches (50.8 cm) in diameter round is supplied. The location’s exhaust duct must be the minimum exhaust size requirement of the ductwork (20-inches [50.8 cm] round duct or 315 square inches [2,032 square centimeters] square duct) from the dryer to the outside exhaust outlet for a horizontal run, with no more than one (1) elbow must not exceed 30 feet (9.14 meters) for gas and 20 feet (6.09 meters) for steam dryers.
- Page 37 113261 - 1...
- Page 38 113261 - 1...
- Page 39 113261 - 1...
- Page 40 a. Outside Ductwork Protection 1) To protect the outside end of the horizontal ductwork from the weather, a 90° elbow bent downward should be installed where the exhaust exits the building. If the exhaust ductwork travels vertically up through the roof, it should be protected from the weather by using a 180° turn to point the opening downward.
-
Page 41: Compressed Air Supply System
E. COMPRESSED AIR SUPPLY SYSTEM The compressed air system of the tilting dryer consists of a number of pneumatic pistons located throughout the dryer. The pistons are actuated by solenoid and flow control valves that are under computer control. The pneumatic pistons are used to: •... - Page 42 3. Internal/External Pilot Air Supply On 2-way tilt dryers, a pneumatic safety circuit is incorporated to prevent both front and rear tilting pistons from extending their rods at the same time. When 24 volts is supplied to the “12” side of the front tilting piston solenoid valve coil, the round internal spool in the core of the solenoid will move, allowing 80 psi (5.51 bar) air to flow into the bottom ports of the front tilting pistons, while the top ports are bled to the atmosphere.
-
Page 43: Electrical Information
F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL electric connections, materials, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO. - Page 44 2. Electrical Service Specifications MAXI200G with Tilting Options / Rear Exhaust 7.5 HP Blower / 3 HP Drive Motor ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER) IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: When fuses are used they must be dual element, time delay, current limiting, class RK1 or RK5 ONLY .
- Page 45 MAXI200S with Tilting Options / Gas - Side Exhaust 15 HP Blower / 3 HP Drive Motor ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER) IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: When fuses are used they must be dual element, time delay, current limiting, class RK1 or RK5 ONLY . Calculate/determine correct fuse value, by applying either local and/or National Electrical Codes to listed appliance amp draw data.
- Page 46 3. Electrical Connections NOTE: A wiring diagram is included with each dryer and is located in the blueprint pocket inside the left side control cabinet. The main electrical input connections to the dryer are the 3-phase (3ø) power leads (L1, L2, and L3), GROUND, and in the case of 4 wire service, the Neutral.
-
Page 47: Gas Information
G. GAS INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Code ANSI Z223.1-LATEST EDITION or in Canada, CAN/CGA-B149.1-M91 (Natural Gas) or CAN.CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General Installation and Gas Plumbing),... - Page 48 2. Technical Gas Data a. Gas Specifications Shaded areas are stated in metric equivalents * Measured at gas valve pressure taps when the gas valves are on. b. Gas Connections: Run a 1-1/2” (3.81 cm) pipe from the main gas header to the dryer. There is a 1-1/2” (3.81 cm) gas pipe connection at the bottom right side of the dryer’s base.
- Page 49 3. Piping/Connections ALL components/materials must conform to National Fuel Gas Code specifications. It is important that gas pressure regulators meet applicable pressure requirements and that gas meters be rated for the total amount of ALL the appliance Btu being supplied. The dryer is provided with a 1-1/4”...
- Page 50 Consistent gas pressure is essential at ALL gas connections. It is recommended that a 2-inch (5.08 cm) pipe gas loop be installed in the supply line servicing a bank of dryers. An in-line pressure regulator must be installed in the gas supply line (header) if the (natural) gas pressure exceeds 12.0 inches (29.8 mb) of water column (W.C.) pressure.
-
Page 51: Steam Information
H. STEAM INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. IMPORTANT: Failure to comply with the requirements stipulated in this manual can result in component failure, which will VOID THE WARRANTY. - Page 52 d. Shutoff valves for each dryer should be installed in the supply line, return line, and drip trap return lines. This will allow the dryer to be isolated from the supply main and the return main if the dryer needs maintenance work.
- Page 53 3. Steam Damper Air System Connections The dryer is manufactured with a pneumatic (piston) damper system, which requires an external supply of compressed air. The air connection is made at the left hand side on top of the dryer. a. Air Requirements Compressed Air Pressure Air Supply...
- Page 54 4. Steam Damper System Operation The dryer’s steam damper in the Heating Mode as shown in Diagram 1, allows the coil to stay constantly charged eliminating repeated expansion and contraction. When the damper is opened, the air immediately passes through the already hot coil, providing instant heat to start the drying process. When the damper is closed, ambient air is drawn directly into the tumbler, allowing a rapid cool down.
-
Page 55: Steam Damper Actuator System
I. STEAM DAMPER ACTUATOR SYSTEM The system consists of a hinged damper plate, pneumatic piston, and a 24 volt solenoid valve with a needle valve to control the speed of the piston actuation. On a call for heat, a 24 volt signal is applied to the 3-way/2-position solenoid valve. This signal switches the valve so that compressed air is sent to the piston. -
Page 56: Preoperational Test
K. PREOPERATIONAL TEST ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. - Page 57 NOTE: Dryer can be stopped at any time by opening the main door or by pressing the “CLEAR/ STOP” key. To restart the dryer, press the “ENTER/START” key or a preprogrammed cycle key (i.e., “E”). NOTE: Pressing touchpad key “A,” “B,” “C,” “D,” or “F” will also start the dryer. The six preprogrammed drying cycles (“A”...
-
Page 58: Preparation For Operation/Start-Up
2) Make a complete operational check of ALL safety-related circuits (i.e., lint drawer switch and sail switches on gas models). 3) Reversing tumbler dryers should never be operated with less than a 100 lb (45.4 kg) load (dry weight), since the load’s weight affects tumbler coast time during a direction reversal command. It is important that the tumbler come to a complete stop prior to starting in opposite direction. -
Page 59: Shutdown Instructions
9. Rotate the tumbler (drum) by hand to be sure it moves freely. 10. Check bolts, nuts, screws, terminals, and fittings for security. 11. Check to ensure air supply (80 psi [5.51 bar]) is connected to the dryer. 12. STEAM MODELS – check to ensure ALL steam shutoff valves are open. M. -
Page 60: Service/Parts Information
SECTION IV SERVICE/PARTS INFORMATION A. SERVICE 1. Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the reseller from whom the equipment was purchased. If the reseller cannot be contacted or is unknown, contact the Service Department for a reseller in your area. -
Page 61: Warranty Information
SECTION V WARRANTY INFORMATION A. RETURNING WARRANTY CARDS 1. Before any dryer leaves the factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim. - Page 62 2. Each part must be tagged with the following information: a. Model number and serial number of the dryer from which part was removed. b. Nature of failure (be specific). c. Date of dryer installation. d. Date of part failure. e.
-
Page 63: Routine Maintenance
SECTION VI ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the ductwork system. The frequency of cleaning can best be determined from experience at each location. - Page 64 MONTHLY Empty the compressed air filter bowl. EVERY 3 MONTHS Clean lint accumulation from the gas valve/burner area at the top of the dryer, the fan (impellor) motor, and the fan/impellor bearings located in the dryer base. NOTE: To prevent damage, avoid cleaning and/or touching ignitor/flame-probe assembly. EVERY 6 MONTHS Check fan (impellor) and drive motor V-belts for tightness and wear.
-
Page 65: Adjustments
B. ADJUSTMENTS 7 DAYS AFTER INSTALLATION AND EVERY 6 MONTHS THEREAFTER Inspect bolts, nuts, screws (bearing setscrews), non-permanent gas connections (unions, shutoff valves, orifices, and grounding connections). Motor and drive belts should be examined. Cracked or seriously frayed belts should be replaced. -
Page 66: Component System Descriptions
SECTION VII COMPONENT SYSTEM DESCRIPTIONS A. TUMBLER DRIVE SYSTEM The tumbler is supported and driven by four (4) 11-inch (27.94 cm) diameter drive wheels. Two (2) of these wheels are attached to a 1-1/2” (3.81 cm) diameter idler shaft, while the other two (2) are attached to a 1-1/2” (3.81 cm) diameter drive shaft. -
Page 67: Tumbler
B. TUMBLER The tumbler is made of 14-gauge stainless steel perforated panels, four (4) stainless steel ribs, and two (2) outer tumbler rings made of rolled steel angle iron that has been turned on a lathe for smoothness. The tumbler is a completely welded assembly so the perforated panels are not removable. - Page 68 4. Burner Box Hi-Limit Safety Thermostats (for Gas Dryers Only) These disk temperature switches have a setting of 330° F (166° C). They are located on the right side of each burner box, and they are a manual reset type of switch. These switches ensure that there is a proper airflow through the burner box.
-
Page 69: Steam Damper Actuator System
E. STEAM DAMPER ACTUATOR SYSTEM The system consists of a hinged damper plate, pneumatic piston, and a 24 volt solenoid valve with a needle valve to control the speed of the piston actuation. On a call for heat, a 24 volt signal is applied to the 3-way/2-position solenoid valve. This signal switches the valve so that compressed air is sent to the piston. -
Page 70: Manual Reset Burner Hi-Limit Instructions
SECTION VIII MANUAL RESET BURNER HI-LIMIT INSTRUCTIONS I M P O R T A N T MANUAL RESET HI-LIMIT INSTRUCTIONS FOR PHASE 7 MODELS This dryer was manufactured with a manual reset burner hi-limit, which is monitored by the Phase 7 computer. If the burner is open prior to start of the drying cycle, the dryer will start momentarily and then shutdown, the Phase 7 computer will display “BURNER HIGH LIMIT FAULT”... -
Page 71: Data Label Information
When contacting Maxidry, certain information is required to ensure proper service/parts information from Maxidry. This information is on the data label that is affixed to the right electrical control panel. When contacting Maxidry, please have the model number and serial number available. -
Page 72: Procedure For Functional Check Of Replacement Components
SECTION X PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. For Models with Direct Spark Ignition (DSI) Module (Type I) Theory of Operation: Start the drying cycle. When the gas burner ignites within the chosen trial for ignition time (6-seconds), the flame sensor detects gas burner flame and signals the DSI module to keep the gas valve open as long as there is a call for heat. -
Page 73: Optional Sensor Activated Fire Extinguishing (S.a.f.e.) System
SECTION XI OPTIONAL SENSOR ACTIVATED FIRE EXTINGUISHING (S.A.F.E.) SYSTEM S.A.F.E. System In Action The exclusive Sensor Activated Fire Extinguishing (S.A.F.E.) System will extinguish fires that may start in the drying tumbler. A series of sensors positioned throughout the tumbler and interfaced with the microprocessor will trigger the S.A.F.E. - Page 74 If the rear area of the dryer, or the water supply is located in an area where it will be exposed to cold/freezing temperatures, provisions must be made to protect these water lines from freezing. WARNING: If the water in the supply line or water solenoid valve freezes, the S.A.F.E. system will be INOPERATIVE!! IMPORTANT: Appliance is to be connected to the water mains using a new hose set and the old hose set should not be reused.
-
Page 75: Optional Manual Bypass
OPTIONAL MANUAL BYPASS Provisions are made in the dryer’s S.A.F.E. system for the installation of an optional manual bypass. Depending on the model dryer, the connections for the manual bypass are made at the “T” or “four way” fitting located in the outlet supply side of the water solenoid valve. -
Page 76: System Theory Of Operation
S.A.F.E. SYSTEM THEORY OF OPERATION While the dryer is in an idle state or 20-seconds after the heat turns off, the Phase 7 control monitors the S.A.F.E. system probe located in the top of the tumbler chamber and records the minimum temperature. If the minimum recorded S.A.F.E. - Page 77 Notes ____________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ 113261 - 1...
- Page 78 Part No. 113261 1 - 09/20/10 - 0...
