MAXIDRY MAXIMD115 Installation Manual

Phase 7/dual timer/phase 5/s.a.f.e. system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MAXIMD115 Installation Manual
Phase 7 / Dual Timer / Phase 5 / S.A.F.E. System
WARNING: For your safety the information
in this manual must be followed to
minimize the risk of fire or explosion and
to prevent property damage, personal
injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Clear the room, building or area of
all occupants.
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
Maxidry
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou
la mort.
—Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
—QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareils.
Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
Évacuez la pièce, le bâtiment ou la
zone.
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
—L'installation et l'entretien doivent être
assurés par un installateur ou un
service d'entretien qualifié ou par le
fournisseur de gaz.
Part No. 113267 - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAXIMD115 and is the answer not in the manual?

Questions and answers

Related Manuals for MAXIDRY MAXIMD115

Summary of Contents for MAXIDRY MAXIMD115

  • Page 1 MAXIMD115 Installation Manual Phase 7 / Dual Timer / Phase 5 / S.A.F.E. System AVERTISSEMENT: Assurez-vous de bien WARNING: For your safety the information suivre les instructions données dans cette in this manual must be followed to notice pour réduire au minimum le risque minimize the risk of fire or explosion and d’incendie ou d’explosion ou pour éviter...
  • Page 2 Retain This Manual In A Safe Place For Future Reference This product embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of efficient, trouble free and, most importantly, safe operation. ONLY qualified technicians should service this equipment.
  • Page 3 WARNING Proposition 65 Use of this product could expose you to substances from fuel combustion that contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. In the State of Massachusetts, the following installation instructions apply: Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by the State of Massachusetts.
  • Page 4 FOR YOUR SAFETY DO NOT DRY MOP HEADS IN THE DRYER. DO NOT USE DRYER IN THE PRESENCE OF DRY CLEANING FUMES. WARNING UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch, or heat safety circuit ever be disabled. The dryer must never be operated with any of the back guards, outer tops, or service panels removed.

  • Page 5: Table Of Contents

    Table of Contents SECTION I SAFETY PRECAUTIONS ..........................2 SECTION II SPECIFICATIONS/COMPONENT IDENTIFICATION ................. 4 A. Specifications ............................4 B. Component Identification ........................6 SECTION III INSTALLATION PROCEDURES ........................ 8 A. Location Requirements ........................... 8 B. Unpacking and Setting Up ........................9 C.

  • Page 6: Safety Precautions

    SECTION I SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
  • Page 7 7. A program should be established for the inspection and cleaning of lint in the heating unit area, exhaust ductwork, and inside the dryer. The frequency of inspection and cleaning can best be determined from experience at each location. WARNING: The collection of lint in the burner area and exhaust ductwork could create a fire hazard. 8.

  • Page 8: Specifications/Component Identification

    SECTION II SPECIFICATIONS/COMPONENT IDENTIFICATION A. SPECIFICATIONS 52.16 kg MAXIMUM CAPACITY (DRY WEIGHT) 115 lb TUMBLER DIAMETER 42” 106.68 cm TUMBLER DEPTH 41-1/4” 104.78 cm 937.29 L TUMBLER VOLUME 33.10 cu ft TUMBLER/DRIVE MOTOR 3/4 hp 0.56 kW 2.24 kW BLOWER/FAN MOTOR 3 hp 79.69 cm DOOR OPENING (DIAMETER)
  • Page 9 Specifications – Gas, Electric, and Steam NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation. 113267 - 1...

  • Page 10: Component Identification

    B. COMPONENT IDENTIFICATION 1. Dryer Front View Illus. No. Description Microprocessor Control and Keypad Panel Assembly (controls) Control (top access) Door Assembly Main Door Assembly Lint Door Assembly Lint Drawer Wire Diagram (located behind control door) Top Console (module) Assembly 113267 - 1...
  • Page 11 2. Dryer Rear View Illus. No. Description Basket (tumbler) Drive Motor Assembly Blower Motor Mount Assembly Impellor (fan/blower) Assembly Idler Bearing Mount Assembly Basket (tumbler) Bearing Mount Assembly Electric Service Relay Box Heating Unit Data Label and Installation Label Electric service connections are made in this box. 113267 - 1...

  • Page 12: Installation Procedures

    SECTION III INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1- LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General Installation and Gas Plumbing) or Canadian Electrical Codes Parts 1 &...

  • Page 13: Unpacking And Setting Up

    IMPORTANT: Dryer must be installed in a location/environment in which the ambient temperature remains between 40° F (4.44° C) and 130° F (54.44° C). B. UNPACKING AND SETTING UP Remove protective shipping material (i.e., plastic wrap and optional shipping box) from dryer. IMPORTANT: Dryer must be transported and handled in an upright position at ALL times.
  • Page 14 2. The V-belts are disconnected from the basket drive motor for shipping. Reconnect V-belts, using the following instructions, before starting the dryer. a. Remove hardware holding back (belt) guard and remove guard from dryer. b. Lay one (1) belt into motor sheave (pulley) groove and wind belt into corresponding groove of the idler pulley by rotating the idler pulley by hand.
  • Page 15 4. Exhaust Transition Piece WARNING An exhaust duct transition piece is shipped inside of the dryer’s tumbler and MUST be installed on the dryer’s exhaust duct, with the hardware provided, BEFORE location venting is connected to the dryer. THIS EXHAUST DUCT TRANSITION PIECE MUST BE INSTALLED FIRST! Failure to observe this installation requirement may result in damage to the dryer, create a FIRE HAZARD and will VOID...

  • Page 16: Dryer Enclosure Requirements

    C. DRYER ENCLOSURE REQUIREMENTS Even though a 12-inch (30.48 cm) clearance is acceptable, it is recommended that the rear of the dryer be positioned approximately 3 feet (0.91 meters) from the nearest obstruction (i.e., wall) for ease of installation, maintenance, and service. Bulkheads and partitions should be made from noncombustible materials. The clearance between the bulkhead header and the dryer must be a minimum of 4-inches (10.16 cm) and must not extend more than 4-inches (10.16 cm) to the rear of the dryer front.

  • Page 17: Exhaust Requirements

    Air supply (make-up air) must be given careful consideration to ensure proper performance of each dryer. An unrestricted source of air is necessary for each dryer. An airflow of 2,100 cfm (cubic feet per minute) (59.5 cmm [cubic meters per minute]) must be supplied to each dryer. As a general rule, an unrestricted air entrance from the outdoors (atmosphere) of a minimum of 3 square feet (0.28 square meters) is required for each dryer.
  • Page 18 CAUTION: This dryer produces combustible lint and must be exhausted to the outdoors. CAUTION: IMPROPERLY SIZED OR INSTALLED EXHAUST DUCTWORK COULD CREATE A FIRE HAZARD. NOTE: When a dryer is exhausted separately, it is recommended that a back draft damper be installed.
  • Page 19 Outside Ductwork Protection To protect the outside end of the horizontal ductwork from the weather, a 90° elbow bent downward should be installed where the exhaust exits the building. If the exhaust ductwork travels vertically up through the roof, it should be protected from the weather by using a 180° turn to point the opening downward. In either case, allow at least twice the diameter of the duct between the duct opening and the nearest obstruction.
  • Page 20 IMPORTANT: For extended ductwork runs, the cross section area of the duct can only be increased to an extent. Maximum proportional ductwork runs cannot exceed 20 feet (6.09 meters) more than the original limitations of 20 feet (6.09 meters) with two (2) elbows. When the ductwork approaches the maximum limits as noted in this manual, a professional heating, ventilating, and air-conditioning (HVAC) firm should be consulted for proper venting information.

  • Page 21: Electrical Information

    MULTIPLE DRYER VENTING (GAS, ELECTRIC, AND STEAM) WITH 14” (35.56 CM) DIAMETER 2100 CFM (59.5 CMM) EXHAUST CONNECTIONS AT COMMON DUCT If it is not feasible to provide separate exhaust ducts for each dryer, ducts from individual dryers may be channeled into a “common main duct.”...
  • Page 22 IMPORTANT: Failure to comply with these codes or ordinances, and the requirements stipulated in this manual, can result in personal injury or component failure. NOTE: Component failure due to improper installation will VOID THE WARRANTY. Each dryer should be connected to an independently protected branch circuit. The dryer must be connected with copper wire only.
  • Page 23 Reversing, 3ø Motor (Electric) ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER) IMPORTANT: 208 VAC AND 240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTES: When fuses are used they must be dual element, time delay, current limiting, class RK1 or RK5 ONLY . Calculate/determine correct fuse value, by applying either local and/or National Electrical Codes to listed appliance amp draw data.
  • Page 24 WARNING: 208 VAC AND 230/240 VAC ARE NOT THE SAME. Any damage done to dryer components due to improper voltage connections will automatically VOID THE WARRANTY. IMPORTANT: 380, 400, and 416 volt dryers are built 4-wire only. Customer must contact the factory to special order 3-wire systems.

  • Page 25: Gas Information

    b. Electric Models ONLY For electric models made to operate at 208 VAC, 230/240 VAC, the electrical input connection is made into the terminal block located at the upper rear area of the dryer. For electric models made to operate at 380 VAC, 416 VAC, 440 VAC, or 480 VAC, the electrical input connection is made to the oven relay located at the upper rear area of the dryer.
  • Page 26 IMPORTANT: Failure to isolate or disconnect the dryer from supply as noted can cause irreparable damage to the gas valve and will VOID THE WARRANTY. WARNING: FIRE OR EXPLOSION COULD RESULT DUE TO FAILURE OF ISOLATING OR DISCONNECTING THE GAS SUPPLY AS NOTED. 1.
  • Page 27 1) Natural Gas Regulation is controlled by the dryer’s gas valve’s internal regulator. Incoming supply pressure must be consistent between a minimum of 6.0 inches (14.92 mb) and a maximum of 12.0 inches (29.9 mb) water column (W.C.) pressure. 2) Liquid Propane (L.P.) Gas Dryers made for use with L.P.
  • Page 28 A 1/8” N.P.T. plugged tap, accessible for a test gauge connection, must be installed in the main gas supply line immediately upstream of each dryer. IMPORTANT: Pipe joint compounds that resist the action of natural and liquid propane (L.P.) gases must be used.

  • Page 29: Steam Information

    H. STEAM INFORMATION It is your responsibility to have ALL steam plumbing connections made by a qualified professional to ensure that the installation is adequate and conforms to local and state regulations or codes. IMPORTANT: Failure to comply with the requirements stipulated in this manual can result in component failure, which will VOID THE WARRANTY.
  • Page 30 d. Shutoff valves for each dryer should be installed in the supply, return, and drip trap return lines. This will allow the dryer to be isolated from the supply and return mains if the dryer needs maintenance work. e. Install an inverted bucket steam trap and check valve at least 12-inches (30.48 cm) below each steam coil return manifold as close to the coil as possible.
  • Page 31 a. Air Requirements Compressed Air Supply Air Pressure Normal 80 psi 5.51 bar Minimum Supply 70 psi 4.82 bar Maximum Supply 90 psi 6.21 bar Shaded areas are stated in metric equivalents b. Air Connections Air connections to system – 1/4” Quick Connection c.

  • Page 32: Water Information

    6. Steam Damper Air Piston (Air Control) Operation Adjustment Although the damper operation was tested and adjusted prior to shipping at 80 psi (5.51 bar), steam damper operation must be checked before the dryer is put into operation. Refer to page 33 for instructions to check steam damper system operation.
  • Page 33 Flexible 1/2 feeds must be provided to avoid damage to electric water solenoid valve by vibration. IMPORTANT: Flexible supply line/coupling must be used. Solenoid valve failure due to hard plumbing connections WILL VOID WARRANTY. If the rear area of the dryer, or the water supply is located in an area where it will be exposed to cold/ freezing temperatures, provisions must be made to protect these water lines from freezing.
  • Page 34 Typical Water Supply OPTIONAL MANUAL BYPASS Provisions are made in the dryer’s fire suppression system for the installation of an optional manual bypass. Depending on the model dryer, the connections for the manual bypass are made at the “T” or “three way” fitting located in the outlet supply side of the water solenoid valve.

  • Page 35: Preparation For Operation And Start-Up

    3. Electrical Requirements No independent external power source or supply connection is necessary. The 24 volt power to operate the fire suppression system is accomplished internally in the dryer (from the dryer controls). WARNING: Electrical power must be provided to the dryer at ALL times. If the main electrical power supply to the dryer is disconnected, the fire suppression system is INOPERATIVE!! J.

  • Page 36: Preoperational Test

    K. PREOPERATIONAL TEST ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. 1.
  • Page 37 b. Steam Models Check to ensure that the (standard) steam damper or (optional) steam solenoid valve is functioning properly. The steam damper should not “slam” (open or closed) when it reaches the end of (piston) travel. Additionally, the steam damper should not bind and/or stop during travel. If either of these conditions occur, the flow control must be adjusted.

  • Page 38: Preoperational Instructions

    L. PREOPERATIONAL INSTRUCTIONS PHASE 7 DRYERS 1. The light emitting diode (L.E.D.) display reads “READY” (no cycle in progress). 2. Press the letter on the keypad corresponding to the cycle desired (i.e., key “D”). NOTE: “0-40” WILL REQUIRE THE “START/ENTER” KEY TO BE PRESSED AFTER THE NUMBER IS SELECTED IN ORDER TO ACCEPT THE SELECTION AND START DRYING.

  • Page 39: Shutdown Instructions

    3. L.E.D. display will quickly read: “Ld30,” “Lc04,” and “F180” (unless special programs requested). These codes mean that the dryer is in the timed mode and will operate with heat of 180º F (82º C) for 30 minutes drying time and have a 4 minute cool down period. 4.

  • Page 40: Service/Parts Information

    SECTION IV SERVICE/PARTS INFORMATION A. SERVICE Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the reseller from whom the equipment was purchased. If the reseller cannot be contacted or is unknown, contact the Service Department for a reseller in your area.

  • Page 41: Warranty Information

    SECTION V WARRANTY INFORMATION A. RETURNING WARRANTY CARDS Before any dryer leaves the factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer; we record the individual installation date and warranty information to better assist you should you file a warranty claim.
  • Page 42 2. Each part must be tagged with the following information: a. Model number and serial number of the dryer from which part was removed. b. Nature of failure. (Be specific). c. Date of dryer installation. d. Date of part failure. e.

  • Page 43: Routine Maintenance

    SECTION VI ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the ductwork system. The frequency of cleaning can best be determined from experience at each location.

  • Page 44: Adjustments

    90 DAYS Remove lint from around basket (tumbler), drive motors, and surrounding areas. Remove lint from gas valve burner area with a dusting brush or vacuum cleaner attachment. Clean any lint that may have collected in and around the blower motor casing openings. IMPORTANT: To prevent damage, avoid cleaning or touching ignitor and flame-probe assembly.

  • Page 45: Data Label Information

    SECTION VII DATA LABEL INFORMATION When contacting Maxidry, certain information is required to ensure proper service/parts information from Maxidry. This information is on the data label located on the left side panel behind top/access control door. When contacting Maxidry, please have the model number and serial number available.

  • Page 46: Procedure For Functional Check Of Replacement Components

    SECTION VIII PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Phase 7 Microprocessor Controller (Computer) Models a. Upon completing installation of the replacement microprocessor controller (computer) board, reestablish power to the dryer. b. Start the drying cycle by pressing any of the preset cycles in letters A-F. c.
  • Page 47 2. Phase 5 Microprocessor Controller (Computer) Board a. Upon completing installation of the replacement microprocessor controller (computer) board, reestablish power to the dryer. b. Start the drying cycle. c. Verify that the motors and the heat indicator dots, in the microprocessor controller (computer) light emitting diode (L.E.D.) display are on.
  • Page 48 3. For Models with Direct Spark Ignition (DSI) Module (Type I) Theory of Operation: Start the drying cycle. When the gas burner ignites within the chosen trial for ignition time (6-seconds), the flame sensor detects gas burner flame and signals the DSI module to keep the gas valve open as long as there is a call for heat.

  • Page 49: Manual Reset Burner Hi-Limit Instructions

    SECTION IX MANUAL RESET BURNER HI-LIMIT INSTRUCTIONS A. PHASE 7 This dryer was manufactured with a manual reset burner hi-limit thermostat, which is monitored by the Phase 7 computer. If the burner hi-limit is open prior to the start of the drying cycle, the dryer will start momentarily and then shut down, the Phase 7 computer will display “burner HIGH LIMIT fault”...
  • Page 50 Part No. 113267 1 - 12/02/10...
