Summary of Contents for Russell Hobbs Atlas RHCV3511
- Page 1 Atlas Pet Single Cyclonic Cylinder Vacuum Cleaner Model Number: RHCV3511 220-240V~, 50/60Hz, 800W For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm Or visit us at www.productcare.co.uk PLEASE RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Spare parts Connection to the mains supply Disposal information Thank you for purchasing your Russell Hobbs Atlas Pet Bagless Cylinder Vacuum Cleaner. To get the best from your new cleaner, take a few moments to read these instructions and keep them in a safe place for future reference. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to electrical parts. - Page 4 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE • Do not direct at people, animals, electrical outlets, or equipment containing electrical components. • Unplug from outlet when not in use. Do not leave the cleaner unattended while plugged in. •...
- Page 5 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • Do not let the cord hang over the edge of the worktop, or touch hot surfaces. • Do not use this vacuum to pick up water or any other liquids, combustible substances or hot/burning objects.
- Page 6 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE • Important: This cleaner has a thermal safety device which automatically cuts off the power supply in case of over heating. If the safety device has switched the cleaner off, unplug from the mains, allow the cleaner to cool down and check for any blockages.
-
Page 7: Energy Performance Label
ENERGY PERFORMANCE LABEL The purpose of the energy label is to help you understand a vacuum cleaner’s energy efficiency performance. 1. Energy rating – based primarily on energy consumption and pick-up. 2. Annual energy usage – the amount of energy used over a year. -
Page 8: Technical Data
TECHNICAL DATA (PRODUCT FICHE) Trade mark Russell Hobbs Model RHCV3511 Energy efficiency class Annual energy consumption 26.6 (kWh/year) Carpet cleaning performance class Hard floor cleaning performance class Dust re-emission class Sound power level 78 dB Rated input power 800W... -
Page 9: Vacuum Feature Diagram
VACUUM FEATURE DIAGRAM (Not visible on diagram) 9 10 Hose suction control Hose connector Wheel Extension lock Dust container Brush tool Extension tube Carry handle Crevice tool Hose Container release On board tool button holder Floor head Cord release button Turbo Pet Tool Floor surface selector Power button... -
Page 10: Vacuum Cleaner Assembly
VACUUM CLEANER ASSEMBLY Before using your vacuum cleaner Remove all packaging and lay out the separate components. Check the unit after unpacking for any visual damage such as: • Misaligned or damaged parts • Damage to the main body and separate components •... - Page 11 VACUUM CLEANER ASSEMBLY Ensure the unit is unplugged before assembling. 1. Place the dust container onto the unit, base first, then tilt forward to engage the top. 2. Insert the hose connector into the hose outlet, aligning the grooves in the outlet and rotate clockwise to secure the hose connector.
-
Page 12: Using Your Vacuum Cleaner
USING YOUR VACUUM CLEANER Once assembled: 1. The cord is stored inside the unit. Pull the power cord out of the machine to as long as you require and stop when you see the yellow tab. Do not over-extend. If the red tab is visible, then wind the cord back until only the yellow tab is visible. - Page 13 USING YOUR VACUUM CLEANER 5. You can adjust the extension tube length to a comfortable cleaning height. To alter the length of the telescopic handle, a) Press and hold the extension lock in the direction indicated. b) Slide the steel pole, up or down, to the correct length. 6.
- Page 14 USING YOUR VACUUM CLEANER Emptying the dust container When the dust container starts to fill it will need to be emptied. 1. To remove the dust container, press the release button located at the top of the lid handle. 2. Lift the container away from the unit base. 3.
- Page 15 USING YOUR VACUUM CLEANER Turbo Brush Your vacuum comes with an air driven turbo brush for upholstery, stairs and pet fur. To attach your turbo brush, remove the floorhead from the metal telescopic tube, and push into the brush attachment. Alternatively the Telescopic tube can also be removed and the brush attached to the hose.
-
Page 16: Cleaning And Care
CLEANING AND CARE: CLEANING THE FILTER Before you clean the appliance, disconnect the mains plug from the wall socket. Remove the wheel filter cover, located on the wheel the same side as the power button, by turning the cover to the left to unlock and pulling the cover away. - Page 17 CLEANING AND CARE: CLEANING THE FILTER 1. To clean the dust container filter, remove the dust container from the main vacuum cleaner unit and unclip the bottom of the container empting the contents over a bin. 2. Remove the HEPA filter by twisting anti clockwise. 3.
- Page 18 CLEANING AND CARE Before you clean the appliance, disconnect the mains plug from the wall socket. Disassembly 1. Press the cord rewind button to automatically bring the cord back inside the unit for storage. 2. To remove the extension hose, manoeuvre it away from the hose connector.
-
Page 19: Problem Solving
PROBLEM SOLVING PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION Power cord/plug damage Check the power cord and plug for signs of damage. The vacuum cleaner is plugged in but does not work Fuse is damaged Check and replace the fuse in the plug. Dust container Check if the dust container is full, if so, empty it. -
Page 20: Guarantee And Customer Services
GUARANTEE AND CUSTOMER SERVICES At Russell Hobbs, we take all our customer feedback seriously. Feel free to contact our Product Care Team, on 0345 209 7461 Monday – Friday: 8am-8pm & Saturday: 9am – 1pm, who will be more than happy to assist you. -
Page 21: Spare Parts
SPARE PARTS To check the availability of the following spare parts, simply contact our friendly Customer Services team using the details provided at the bottom of this page. 1. Hose 2. Extension tube 3. Air driven floor head 4. Crevice tool 5. -
Page 22: Connection To The Mains Supply
CONNECTION TO THE MAINS SUPPLY This appliance is designed to operate from a mains supply of 220-240V~ 50/60Hz. Check that the voltage marked on the product corresponds with your supply voltage. How to change the fuse 1. Slot the end of a screwdriver into the recess in the fuse holder of the plug. - Page 23 NOTES...
- Page 24 Model: RHCV3511 Made by G2S Ltd under license. G2S Limited, Wigan, WN2 4AY Russell Hobbs is the registered trademark of Spectrum Brands (UK) Ltd. This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
