iGaging AngleCube 35-222-6 Manual

Please read through this owner's manual carefully before using the gauge. Use tool properly and only for it's intended use.
• The iGAGING® AngleCube
of its our surfaces may be utilized.
• Zero can be set at any angle so that the relative angle between two surfaces can be measured.
• The AngleCube can also measure absolute level, yuu can utilize it as a portable pocket level.
®

Operation

1. To power on and read absolute level, push the " /...LEVEL" button; "LEVEL" will
appear on the upper-left corner of the display.
2. To measure relative bevel, place the AngleCube
"ZERO" button. Then move the AngleCube
accurately measure and display the bevel angle between the two surfaces.
3. To switch back to absolute level measuring again, push and hold the " /...LEVEL"
button for 3 seconds.
4. To hold the reading, push the "HOLD" button, "H" will display at the upper-center of the
display. To disable the HOLD function, push "HOLD" button again.
5. If " " signal appears on the LCD display, or the gauge will not power on, then it is
time to change the battery. Remove the back plate with the screwdriver supplied
and insert a new standard 9 volt battery.
6. To power off, push the " /...LEVEL" button. Unit will autmatically shut-off within
3 - 5 minutes when not in use.
CALIFORNIA PROP 65 WARNING: Products may contain chemicals known to the State of California to cause
cancer and/or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Manufacture supplied information. Information may change without notice. Visit iGAGING.com for more information.

Specifications:

Resolution:
Repeatability:
Accuracy:
Battery:
ENJOY ACCURACY
AngleCube
Angle Gauge
®
is a precision instrument used for measuring angles in which any
®
