- Page 1 SINGLE DISHDRAWER™ DISHWASHER INTEGRATED DD24SI9, DD24STI9, DD24SHI9 DD24SHTI9 INSTALLATION GUIDE US CA...
-
Page 3: Safety And Warnings
SAFETY AND WARNINGS WARNING! WARNING! Electric Shock Hazard Electric Shock Hazard Failure to follow this advice may result in Failure to follow this advice may result in electrical shock or death. electrical shock or death. • Fitting an integrated panel requires access to •... - Page 4 SAFETY AND WARNINGS WARNING! To reduce the risk of fire, injury to persons or damage when using the appliance, follow the important safety instructions listed below. Read all the guidance before using the appliance. Servicing Do not repair or replace any part of the appliance unless specifically recommended in this guide.
-
Page 5: Tools And Components
TOOLS AND COMPONENTS PARTS SUPPLIED TOOLS REQUIRED Keep all packing materials until the unit has been inspected. Not supplied Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. Fisher &... -
Page 6: Product Dimensions
PRODUCT DIMENSIONS DD24SI DD24STI PRODUCT DIMENSIONS INCHES INCHES A Overall height 16 1/8 17 7/8 B Overall width 23 9/16 23 9/16 C Overall depth* 22 1/2 22 1/2 D Depth of chassis 21 3/4 21 3/4 PLAN ISOMETRIC E Front panel depth** 5/8 – 13/16 16 – 20 5/8 – 13/16... -
Page 7: Custom Panel Dimensions
CUSTOM PANEL DIMENSIONS Material specifications Maximum weight of door panels must not exceed 20lbs (9kg) (including handle). The panel should be adequately sealed to withstand moisture 122°F (50°C) @ 80% RH). The back and sides of the panel should be completely sealed with a waterproof vapour barrier, such as polyurethane, to prevent damage. - Page 8 CABINETRY DIMENSIONS CLEARANCES Connections can be located in an adjacent cabinet on either side of the DishDrawer™ Dishwasher*** PLAN ISOMETRIC STD MODELS TALL MODELS CABINETRY CLEARANCES INCHES CABINETRY DIMENSIONS INCHES INCHES A Minimum clearance to adjacent cupboard door 1/16 A Minimum inside height min.
-
Page 9: Left Side
PLUMBING & ELECTRICAL CONSIDERATIONS Hose and cord lengths Your services can be installed to either the left-hand or right-hand side of the product in an adjacent cabinet. Refer to 'Cabinetry preparation' for service access requirements. If the drain hoses supplied are not long enough to reach your services, you may purchase a Fisher &... - Page 10 HARD-WIRING (OPTIONAL) You have the option to hard-wire your DishDrawer™ Dishwasher. To do this, we recommend to remove the supplied power cord and do the hardwiring installation as close to the cavity as possible. Ensure only copper conductors are used. Slide the terminal block cover sideways to unlock and hinge open to access the terminal block.
- Page 11 HARD WIRING (OPTIONAL) Screw down the Live, Neutral and Earth wires correctly. Refit module cover before sliding the access cover back into place, ensuring the 2 clips shown are fully locked. Before refitting the drawer, ensure the hoses are not twisted. Refit the drawer to the runners and clip into place via both locking tabs.
- Page 12 CABINETRY PREPARATION SERVICE ACCESS MOISTURE PROTECTION Service holes can be created on either side of the DishDrawer™ Dishwasher cavity as shown below. If the hole is created through wood, ensure the edges are smooth and rounded. If the hole is created through metal, ensure the edge protector is fitted. Align the supplied moisture protection tape to the cabinetry as illustrated Ensure this area is free of debris...
- Page 13 EXTERNAL VENTING PREPARATION To prevent the build up of condensation produced by your DishDrawer™ Dishwasher, the external venting kit must be installed via one of the following options: THROUGH SAME CABINET THROUGH ADJACENT CABINET THROUGH FLOOR FRAMELESS FRAMED FRAMELESS FRAMED FRAMED &...
- Page 14 FIT THE TRIM BRACKET PREPARE EXTERNAL VENTING FIT THE VENTING HOSE TO THE DISHDRAWER™ DISHWASHER We recommend fitting the trim bracket when installing your DishDrawer™ Dishwasher into a 480mm cavity to conceal any visible gap left between the countertop and chassis. Rotate the elbow at the rear of the product to either the left or right Align the bracket to the chassis ensuring...
- Page 15 PUSH THE PRODUCT INTO THE CAVITY SECURE THE VENTING HOSE TO CABINETRY VENTING THROUGH CABINETRY If securing via bracket method: Secure all four side brackets to the DishDrawer™ Dishwasher, aligning bracket A with slot A and bracket B with slot B. Unframed cabinetry Ensure the ends of the brackets are not Route the venting hose to the cutout...
- Page 16 FIT THE CUSTOM PANEL Attach the Knock-to-Pause module to the panel as shown. Remove both side pins. Ensure the Knock-to-Pause module is oriented correctly and is not in contact with the bracket before securing. Electric shock hazard: To earth the panel bracket, connect the earth wire from the product to one of Carefully pull the bracket down and the tabs.
- Page 17 SECURE TO CABINETRY VIA BRACKETS (METHOD A) SECURE TO CABINETRY VIA DRAWER REMOVAL (METHOD B) Open the drawer and press both locking tabs back to release. Partially open the drawer and remove the first screw cover from the trim moulding. Lift the drawer off the runners and carefully set aside on a protected surface.
- Page 18 PLUMBING & ELECTRICAL CONNECTION Ø38MM STANDPIPE INSTALLATION SINK TRAP/WASTE TEE INSTALLATION Install the drain hose support to the Install the drain hose support to the back wall, as close to the underside of back wall, as close to the underside of the countertop as possible.
- Page 19 PLUMBING & ELECTRICAL CONNECTION AIR GAP INSTALLATION Install your Air Gap Kit to the benchtop. We recommend using a Dual Air Gap Kit. Refer to 'Plumbing & electrical connection' for minimum install heights. Dual Air Gap Single Air Gap Thread wire clips onto the hoses before fitting them to the hose joiner.
-
Page 20: Installer Checklist
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Installation Electrical … … Check all parts are installed correctly and are secure. Ensure all electrical tests have been conducted in accordance with local regulations. … Ensure DishDrawer™ Dishwasher is securely fastened to the cabinetry and drawer opens Test operation and closes freely with no resistance. -
Page 21: Troubleshooting
TROUBLESHOOTING The DishDrawer is beeping continuously DISPLAY POSSIBLE CAUSE WHAT TO DO Refer to the ‘Fault codes’ section of your User guide Water Supply fault. 1 Ensure the water supply is turned on. No program indicator lights up when the drawer is opened 2 Press once to stop the beeping, Ensure power is connected and is switched on. - Page 22 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2021. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
