User Manual
Thank you for purchasing this product.
Be sure to read this documentation before use.
This documentation includes important safety precautions and instructions on how to operate the unit. Be sure to read this documentation to ensure
proper operation.
The contents of this documentation are subject to change without notice for the purpose of improvement.
© 2022 JAI
GOX-5105M-PGE
GOX-8105M-PGE
GOX-12405M-PGE
GOX-16205M-PGE
GOX-20405M-PGE
GOX-24505M-PGE
Monochrome and Color Camera with GigE Interface
Go-X_Series_PGE_Manual_Ver.1.0_2022-09-20
GOX-5105C-PGE
GOX-8105C-PGE
GOX-12405C-PGE
GOX-16205C-PGE
GOX-20405C-PGE
GOX-24505C-PGE
CMOS Digital Progressive Scan
Document Version: 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JAI GOX-5105M-PGE
Summary of Contents for JAI GOX-5105M-PGE
- Page 1 This documentation includes important safety precautions and instructions on how to operate the unit. Be sure to read this documentation to ensure proper operation. The contents of this documentation are subject to change without notice for the purpose of improvement. © 2022 JAI...
-
Page 2: Table Of Contents
User Manual (Ver. 1.0) - Table of Contents GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Table of Contents Table of Contents About Technical Note Notice/Warranty Notice Warranty Certifications CE Compliance Warning Supplement Supplement Usage Precautions Notes on Cable Configurations Notes on Attaching The Lens Notes on LAN Cable Connection Phenomena Specific to CMOS Image Sensors... - Page 3 User Manual (Ver. 1.0) - Table of Contents GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Recommended External Output Circuit Diagram Characteristics of the Recommended Circuits for Opto OUT Preparation Step 1: Install the Software (First Time Only) Step 2: Connect Devices ①...
- Page 4 1. Calculate the H Period 2. Calculate the Minimum Frame Period 3. Calculate the Maximum Frame Rate or Maximum Trigger Rate Timing Chart Exposure Mode = Timed (Overlap Readout) GOX-5105M-PGE, GOX-5105C-PGE GOX-8105M-PGE, GOX-8105C-PGE GOX-12405M-PGE, GOX-12405C-PGE GOX-16205M-PGE, GOX-16205C-PGE GOX-20405M-PGE, GOX-20405C-PGE GOX-24505M-PGE, GOX-24505C-PGE...
- Page 5 User Manual (Ver. 1.0) - Table of Contents GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE White Balance Color Temperature ALC (Automatic Level Control) Function To Use the ALC Function Gamma Function To Use the Gamma Function LUT (Lookup Table) To Use the LUT Function LUT Value...
- Page 6 User Manual (Ver. 1.0) - Table of Contents GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Counter and Timer Control Function Counter Occurrence Diagram Internal Camera Blocks To Use the Counter Function Action Control Function Action Control Example Event Control Function Chunk Data Function PTP (Precision Time Protocol)
-
Page 7: About Technical Note
Revision History About Technical Note Some additional technical information is provided on the JAI website as Technical Notes. In this manual, if a technical note is available for a particular topic, the above icon is shown. Please refer to the following URL for Technical notes. -
Page 8: Notice/Warranty
The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan, and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein. -
Page 9: Warning
User Manual (Ver. 1.0) - Notice/Warranty GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Warning Changes or modifications to this unit not expressly approved by the party responsible for FCC compliance could void the user’s authority to operate the equipment. -
Page 10: Supplement
Pollution by Electronic Information Products “, known as “China RoHS“. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years. Applicable models: GOX-5105M-PGE, GOX-8105M-PGE, GOX-12405M-PGE, GOX-16205M- PGE, GOX-20405M-PGE, GOX-24505M-PGE 重 要 注 意 事 项 有毒，有害物质或元素名称及含量表... -
Page 11: Supplement
User Manual (Ver. 1.0) - Notice/Warranty GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Supplement The following statement is related to the regulation on “Measures for the Administration of the Control of Pollution by Electronic Information Products “, known as “China RoHS“. The table shows contained Hazardous Substances in this camera. -
Page 12: Usage Precautions
User Manual (Ver. 1.0) - Usage Precautions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Usage Precautions Notes on Cable Configurations The presence of lighting equipment and television receivers nearby may result in video noise. In such cases, change the cable configurations or placement. -
Page 13: Phenomena Specific To Cmos Image Sensors
User Manual (Ver. 1.0) - Usage Precautions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Phenomena Specific to CMOS Image Sensors The following phenomena are known to occur on cameras equipped with CMOS image sensors. These do not indicate malfunctions. Aliasing: When shooting straight lines, stripes, and similar patterns, vertical aliasing (zigzag distortion) may appear on the monitor. -
Page 14: Features
In addition, these provide an attractive combination of high resolution, high speed, and high image quality for machine vision applications. Model Name Image Sensor Active Pixels Pixel Size Max Frame Rate* GOX-5105M-PGE Mono Type 1/1.8 2472 x 2064 2.74 μm x 2.74 μm 23 fps GOX-5105C-PGE... -
Page 15: Parts Identification
User Manual (Ver. 1.0) - Parts Identification GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Parts Identification ① Lens Mount (C-Mount) ② RJ-45 Connector ③ LINK LED ④ ACT LED ⑤ POWER/TRIG LED ⑥ DC IN/TRIG Connector (6-Pin Round) ⑦... -
Page 16: ② Rj-45 Connector
User Manual (Ver. 1.0) - Parts Identification GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ② RJ-45 Connector Connect a Gigabit Ethernet compatible LAN cable (Category 5e or higher, Category 6 recommended) here. GigE Vision Interface Signal TRD+ (0) TRD- (0) TRD+ (1) -
Page 17: ⑤ Power/Trig Led
User Manual (Ver. 1.0) - Parts Identification GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ⑤ POWER/TRIG LED Indicates the power or trigger input status. Status Lit amber Camera initializing Lit green Camera in operation During operation in trigger mode, trigger signals are being input. Blinking Note: The blinking interval is not related to the actual input interval of the external green... -
Page 18: ⑦ ⑧ Camera Locking Screw Holes
User Manual (Ver. 1.0) - Parts Identification GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ⑦ ⑧ Camera Locking Screw Holes Use these holes when mounting the camera directly to a wall or other structural system. ⑦ Upper part of camera: M3, 3mm depth, 20mm pitch ⑧... -
Page 19: Characteristics Of The Recommended Circuits For Opto Out
User Manual (Ver. 1.0) - Parts Identification GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Characteristics of the Recommended Circuits for Opto OUT OUTPUT LINE RESPONSE TIME For the operating conditions of applied voltage (User Power) +12V, load resistance 10kΩ, and cable length 1m, the timing is shown in the table below. -
Page 20: Preparation
Read this section to learn how the camera connects to devices and accessories. The preparation process is described below. Step 1: Install the Software (First Time Only) Install the software for configuring and controlling the camera (eBUS SDK for JAI) on the computer. Step 2: Connect Devices Connects the lens, LAN cable, computer, and other devices. -
Page 21: Step 1: Install The Software (First Time Only)
When using the camera for the first time, install the software for configuring and controlling the camera (eBUS SDK for JAI) on the computer. Note: When you install eBUS SDK for JAI, eBUS Player for JAI will also be installed. 1. Download the eBUS SDK for JAI from the JAI website (https://www.jai.com/support-software/jai-... -
Page 22: ① Lens
C-mount lenses with lens mount protrusions of 9 mm or less can be attached. To prevent vignetting and to obtain the optimal resolution, use a lens that will cover the image sensor size. Model Name Image Sensor GOX-5105M-PGE Mono Type 1/1.8 6.8 mm x 5.7 mm (8.82mm diagonal) GOX-5105C-PGE... -
Page 23: ② Direct Mounting (Or Use Mp-46 Tripod Adapter Plate)
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Cautions: The maximum performance of the camera may not be realized depending on the lens. Attaching a lens with a mount protrusion of 9 mm or longer may damage the lens or camera. ②... -
Page 24: ⑥ Ac Adapter (Power Supply) (If Necessary)
⑤ POWER/TRIG LED section. Step 4: Verify the Connection between the Camera and PC Verify whether the camera is properly recognized via Control Tool. 1. Launch eBUS Player for JAI eBUS Player for JAI startup screen appears. - 24 -... - Page 25 User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE 2. Select the camera you want to configure. Click the Select / Connect button. 3. The connected camera is listed. Please select one camera and click OK. - 25 -...
- Page 26 User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE 4. Check that the settings of the selected camera are displayed. 5. Click the Device control button. The screen shown below will be displayed. In this window, you can adjust various settings of the camera.
-
Page 27: Step 5: Change The Camera Settings
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Step 5: Change the Camera Settings This section explains how to change settings by describing the procedure for changing the output format as an example. Configure the Output Format Configure the size, position, and pixel format of the images to be acquired. -
Page 28: Step 6: Adjust The Image Quality
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Step 6: Adjust the Image Quality Related Setting Items: AnalogControl Display the camera image and adjust the image quality. Display the Image Display the image captured by the camera. When you click the Play button, the camera image appears in the right area. -
Page 29: Adjust The Gain
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Adjust the Gain Adjust the image quality using the gain and white balance functions. The Visibility must be changed from Beginner to Guru. Note: For details on the Gain control, see Gain Control in the Main Functions chapter. -
Page 30: Adjust The White Balance
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Adjust the White Balance Adjust the white balance using the automatic adjustment function. Note: The white balance is only supported on color models. Automatic White Balance Adjustment 1. -
Page 31: Adjust The Black Level
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Adjust the Black Level 1. Expand AnalogControl, and select the black level you want to configure in BlackLevelSelector. All (master black), Red* (digital R), and Blue* (digital B) can be configured. Note: *Color models only. -
Page 32: Step 7: Save The Settings
Related Setting Items: UserSetControl The setting values configured in eBUS SDK for JAI will be deleted when the camera is turned off. By saving current setting values to user memory, you can load and recall them whenever necessary. You can save up to three sets of user settings in the camera. (User Set1 to 3) Note: Changes to settings are not saved to the computer (eBUS SDK for JAI). -
Page 33: To Save User Settings
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE To Save User Settings 1. Stop image acquisition. 2. Expand UserSetControl, and select the save destination (UserSet1 to UserSet3) in UserSetSelector. Note: The factory default setting values are stored in Default and cannot be overwritten. Caution: Settings can only be saved when image acquisition on the camera is stopped. -
Page 34: To Load User Settings
User Manual (Ver. 1.0) - Preparation GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE To Load User Settings 1. Stop image acquisition. User settings can only be loaded when image capture on the camera is stopped. 2. Select the settings to load (UserSet1 to UserSet3) in UserSetSelector. 3. -
Page 35: Main Functions
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Main Functions This chapter describes the camera's main functions. Acquisition Control Related Setting Items: AcquisitionControl This camera has three Acquisition modes (SingleFrame, MultFrame, Continuous). Use the AcquisitionControl settings to perform operations and settings for image capture. -
Page 36: Changing The Frame Rate
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Note: After changing various settings, the black level may not be stable for several frames immediately after AcquisitionStart. Changing the Frame Rate When TriggerMode is disabled, you can change the frame rate in AcquisitionFrameRate. -
Page 37: Exposure Mode
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Exposure Mode Related Setting Items: AcquisitionControl This camera has three Exposure modes (Off, Timed, TriggerWidth). Use the AcquisitionControl settings to perform operations and settings for exposure. ExposureMode = Off Exposure control is not performed (free-running operation). -
Page 38: Actual Exposure Time
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Actual Exposure Time Related Setting Items: AcquisitionControl When ExposureMode is set to Timed, the actual exposure time will consist of the image sensor’s offset duration (2.45us) added to the ExposureTime setting configured on the camera. -
Page 39: Burst Trigger Mode
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Burst Trigger Mode Related Setting Items: AcquisitionControl In Burst Trigger mode, when a single external trigger signal is received, the camera acquires images continuously at high speed, stores the images in the internal memory temporarily, and then the image data is read out. -
Page 40: Burst Trigger Mode Usage Examples
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Number of Frames That Can Be Acquired in Burst Trigger Mode In BurstTrigger mode, all acquired frames cannot be output because the maximum frame rate for BurstTrigger mode is higher than the GigE bandwidth frame rate. - Page 41 User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Example 2: Use Continuous Mode with FrameStart Trigger In this example, the number of frames to be acquired is defined by the number of FrameStart triggers, and the frame rate is defined by the input trigger signal's interval.
-
Page 42: Trigger Control
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Trigger Control Related Setting Items: AcquisitionControl The camera allows the following controls to be performed via external trigger signals. TriggerSelector Description AcquisitionStart Start image acquisition in response to the external trigger signal input. -
Page 43: When Using The Framestart Trigger
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Select the trigger type with TriggerSelector, and set the following items for each trigger. TriggerMode Switch enable or disable. Select the source signal (PulseGenerator0-3, UserOutput0-3, Action0-3, Software, Line5 Opt In, Nand0 Out, Nand1 Out). -
Page 44: Pixel Format
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Pixel Format Related Setting Items: ImageFormatControl Pixel Format Alignments for GigE Vision Selectable PixelFormat is as follows. BayerRG8 (default), BayerRG10, BayerRG10Packed, BayerRG12, BayerRG12Packed, BayerGR8*, BayerGR10*, BayerGR10Packed*, BayerGR12*, BayerGR12Packed*, BayerGB8*, BayerGB10*, BayerGB10Packed*, BayerGB12*, BayerGB12Packed*, Color models... -
Page 45: Sensordigitizationbits
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE SensorDigitizationBits Related Setting Items: ImageFormatControl You can use SensorDigitizationBits to select the sensor output bits for this camera (8bits, 10bits, and 12bits: default = 10bits). Notes: When SensorDigitizationBits is set to "8Bits", the sensitivity is 4 times higher than when set to 10Bits/12Bits. -
Page 46: Gpio (Digital Input/Output Settings)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GPIO (Digital Input/Output Settings) Related Setting Items: DigitalIOControl The camera can input/output the following signals to and from external input/output connectors. External Output Line2 : Opt Out DC IN / TRIG IN Connector (6-pin round) Internal Output... -
Page 47: Videoprocessbypassmode
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE The table below shows the source signals that can be set. VideoProcessBypassMode Related Setting Items: ImagingControl The video process bypass mode is a function that bypasses internal video processing on the camera. To use this function, VideoProcessBypassMode must be set to On. -
Page 48: Calculate The Maximum Frame Or Trigger Rate (Approximate)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Calculate the Maximum Frame or Trigger Rate (Approximate) Related Setting Items: AcquisitionControl This section describes how to calculate the maximum frame rate or the maximum trigger rate (approximate). - Page 49 User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Select the PixelSize value from the table below based on your PixelFormat setting. PixelFormat PixelSize Mono8 BayerRG8 Mono10, Mono12 BayerRG10, BayerRG12 Mono10Packed, Mono12Packed BayerRG10Packed, BayerRG12Packed 2.
- Page 50 User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE B. SENSOR_LINETIME[clk] SENSOR_LINETIME[clk] = HMAX Select the HMAX value from the table below based on the Sensor Operation, the SensorDigitizationBits setting, and your camera model. Sensor GOX-5105 GOX-8105...
-
Page 51: Calculate The Minimum Frame Period
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE 2. Calculate the Minimum Frame Period Next, calculate the Minimum Frame Period value that is SensorMinimumFramePeriod[us] or FrameMemoryMinimumFramePeriod[us], whichever is larger. 1. Calculate SensorMinimumFramePeriod[us]. SensorMinimumFramePeriod[us] = Rounddown( (SENSOR_LINETIME[clk] / 74.25) x (Height(*1) + VBlanking + 2), 0 ) For Height(*1), enter the following value if using the... -
Page 52: Calculate The Maximum Frame Rate Or Maximum Trigger Rate
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE 3. Calculate Minimum Frame Period[us]. Minimum Frame Period[us] = MAX( SensorMinimumFramePeriod[us], FrameMemoryMinimumFramePeriod[us] ) 3. Calculate the Maximum Frame Rate or Maximum Trigger Rate Finally, calculate the maximum acquisition frame rate (when in Continuous Mode) or maximum trigger rate (when in Trigger Mode). - Page 53 User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Next, calculate the Maximum Trigger Rate. The formula depends on whether the Exposure Time value is longer or shorter than the MaxOverlapTime_TrOlrd value. A.
-
Page 54: Timing Chart
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Timing Chart Related Setting Items: AcquisitionControl This section shows the timing charts under the following conditions on each model when FrameStartTriger is set to On. Exposure Mode = Timed (Overlap Readout) Exposure Mode = TriggerWidth (Overlap Readout) Exposure Mode = Timed (RCT Mode) -
Page 55: Exposure Mode = Timed (Overlap Readout)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Exposure Mode = Timed (Overlap Readout) This section shows the timing charts when FrameStartTrigger is set to On, and ExposureMode is set to Timed (Overlap Readout). -
Page 56: Gox-5105M-Pge, Gox-5105C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-5105M-PGE, GOX-5105C-PGE Exposure Mode = Timed (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Edge to Pixel Format Frame Period [A] usec... -
Page 57: Gox-8105M-Pge, Gox-8105C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-8105M-PGE, GOX-8105C-PGE Exposure Mode = Timed (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Edge to Pixel Format Frame Period [A] usec Exposure Start [B] (usec) Full (Max Frame Rate) Mono8... -
Page 58: Gox-12405M-Pge, Gox-12405C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-12405M-PGE, GOX-12405C-PGE Exposure Mode = Timed (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Edge to Pixel Format Frame Period [A] usec Exposure Start [B] (usec) Full (Max Frame Rate) Mono8... -
Page 59: Gox-16205M-Pge, Gox-16205C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-16205M-PGE, GOX-16205C-PGE Exposure Mode = Timed (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Edge to Pixel Format Frame Period [A] usec Exposure Start [B] (usec) Full (Max Frame Rate) Mono8... -
Page 60: Gox-20405M-Pge, Gox-20405C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-20405M-PGE, GOX-20405C-PGE Exposure Mode = Timed (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Edge to Pixel Format Frame Period [A] usec Exposure Start [B] (usec) Full (Max Frame Rate) Mono8... -
Page 61: Gox-24505M-Pge, Gox-24505C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-24505M-PGE, GOX-24505C-PGE Exposure Mode = Timed (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Edge to Pixel Format Frame Period [A] usec Exposure Start [B] (usec) Full (Max Frame Rate) Mono8... -
Page 62: Exposure Mode = Triggerwidth (Overlap Readout)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Exposure Mode = TriggerWidth (Overlap Readout) This section shows the timing charts when FrameStartTrigger is set to On, and ExposureMode is set to TriggerWidth (Overlap Readout). -
Page 63: Gox-5105M-Pge, Gox-5105C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-5105M-PGE, GOX-5105C-PGE Exposure Mode = TriggerWidth (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Period from Exposure End Pixel Format... -
Page 64: Gox-8105M-Pge, Gox-8105C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-8105M-PGE, GOX-8105C-PGE Exposure Mode = TriggerWidth (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Period from Exposure End Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] to Next Trigger Start [C]... -
Page 65: Gox-12405M-Pge, Gox-12405C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-12405M-PGE, GOX-12405C-PGE Exposure Mode = TriggerWidth (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Period from Exposure End Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] to Next Trigger Start [C]... -
Page 66: Gox-16205M-Pge, Gox-16205C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-16205M-PGE, GOX-16205C-PGE Exposure Mode = TriggerWidth (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Period from Exposure End Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] to Next Trigger Start [C]... -
Page 67: Gox-20405M-Pge, Gox-20405C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-20405M-PGE, GOX-20405C-PGE Exposure Mode = TriggerWidth (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Period from Exposure End Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] to Next Trigger Start [C]... -
Page 68: Gox-24505M-Pge, Gox-24505C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-24505M-PGE, GOX-24505C-PGE Exposure Mode = TriggerWidth (Frame Start Trigger On, Overlap Readout) Period From Trigger Start Period from Exposure End Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] to Next Trigger Start [C]... -
Page 69: Exposure Mode = Timed (Rct Mode)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Exposure Mode = Timed (RCT Mode) This section shows the timing charts when FrameStartTrigger is set to On, and ExposureMode is set toTimed (RCT Mode). Frame Period (usec) Period From Trigger Start Edge to Exposure Start (usec) Data Invalid Period (usec) -
Page 70: Gox-5105M-Pge, Gox-5105C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-5105M-PGE, GOX-5105C-PGE Exposure Mode = Timed (Frame Start Trigger On, RCT Mode) Period From Trigger Start Data Invalid Period [C] Pixel Format... -
Page 71: Gox-8105M-Pge, Gox-8105C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-8105M-PGE, GOX-8105C-PGE Exposure Mode = Timed (Frame Start Trigger On, RCT Mode) Period From Trigger Start Data Invalid Period [C] Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] (usec) -
Page 72: Gox-12405M-Pge, Gox-12405C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-12405M-PGE, GOX-12405C-PGE Exposure Mode = Timed (Frame Start Trigger On, RCT Mode) Period From Trigger Start Data Invalid Period [C] Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] (usec) -
Page 73: Gox-16205M-Pge, Gox-16205C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-16205M-PGE, GOX-16205C-PGE Exposure Mode = Timed (Frame Start Trigger On, RCT Mode) Period From Trigger Start Data Invalid Period [C] Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] (usec) -
Page 74: Gox-20405M-Pge, Gox-20405C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-20405M-PGE, GOX-20405C-PGE Exposure Mode = Timed (Frame Start Trigger On, RCT Mode) Period From Trigger Start Data Invalid Period [C] Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] (usec) -
Page 75: Gox-24505M-Pge, Gox-24505C-Pge
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE GOX-24505M-PGE, GOX-24505C-PGE Exposure Mode = Timed (Frame Start Trigger On, RCT Mode) Period From Trigger Start Data Invalid Period [C] Pixel Format Frame Period [A] (usec) Edge to Exposure Start [B] (usec) -
Page 76: Gain Control
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Gain Control Related Setting Items: AnalogControl Adjust the overall gain with AnalogAll (master gain), and adjust the white balance by changing DigitalRed and DigitalBlue. Color Model Monochrome Model Automatic Gain Level Control... -
Page 77: White Balance
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE White Balance Related Setting Items: AnalogControl To adjust the white balance automatically, set BalanceWhiteAuto to Once (automatic adjustment only once) or Continuous (automatic adjustment always). The metering area can be limited for automatic adjustment. -
Page 78: Alc (Automatic Level Control) Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ALC (Automatic Level Control) Function Related Setting Items: AutoLevelControl The ALC (automatic level control) function combines the automatic gain control (AGC/Auto Gain Control) and automatic exposure control (ASC/Auto Shutter Control) functions and is capable of handling various changes in brightness. -
Page 79: Gamma Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Gamma Function Related Setting Items: AnalogControl The Gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing. -
Page 80: Lut (Lookup Table)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE LUT (Lookup Table) Related Setting Items: LUTControl The LUT function is used to generate a non-linear mapping between signal values captured on the sensor and those that are output from the camera. -
Page 81: Blemishcompensation
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE BlemishCompensation Related Setting Items: BlemishControl Multiple defective pixels that are not adjacent to each other can occur on CMOS sensor cameras. This camera features a function that interpolates defective pixels using the surrounding pixels. Up to 2000 pixels can be corrected. -
Page 82: Manual Configuration
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Manual Configuration 1. Select the index in BlemishCompensationIndex. You can select from 1 to 2000. However, configure the indexes in order starting with the smallest index. If you skip indexes while configuring settings, interpolation may not be performed. -
Page 83: Shading Correction
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Shading Correction Related Setting Items: ShadingControl The ShadingCorrection function corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V). -
Page 84: To Use The Shading Correction Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Cautions: For FlatShading and ColorShading, the maximum amount of correction gain for all pixels is limited to 8 times the amount of gain before correction. (The amount of gain cannot be increased to more than 8 times the amount of gain from before correction.) If the area in the screen with the highest brightness level is 1000 LSB or higher (during 10-bit video output), or if the lowest brightness level is less than 45 LSB (during 10-bit video... -
Page 85: Binning Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Binning Function Related Setting Items: ImageFormatControl The Binning function allows you to combine the signal values of clusters of adjacent pixels to create improved virtual pixels. -
Page 86: Image Scaling Mode (Xscale)
Image Scaling Mode (Xscale) Related Setting Items: ImageFormatControl JAI's Xscale algorithm digitally reduces the sensor image by specifying the vertical and horizontal scaling ratio. This function can also be used for color models and allows finer adjustment of resolution than the conventional Binning Function. -
Page 87: Limitations On Image Scaling Mode (Xscale)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE 4. Use ImageScalingHorizontal and ImageScalingVertical to specify the horizontal and vertical scaling ratio. For more information on how to specify the scaling ratio, see Limitations on Image Scaling Mode (Xscale) Specifying the Scaling... -
Page 88: Specifying The Scaling Ratio
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Specifying the Scaling Ratio Specify the scaling ratio in decimal point (maximum six decimal places) for ImageScalingHorizontal and ImageScalingVertical. The setting range is 0.0625 to 1. If "1" is specified, the image will not be scaled. - Page 89 User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Caution: Due to the Xscale's limitations, the H (Width) value must be 8n-4 (n: integer) and the V (Height) value must be 2n-2 (n: integer). If you enter another value, "NG" (no good) is displayed.
-
Page 90: Decimation Mode
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE 3. Enter the scaled resolution 3004 in the H and V boxes in the Target resolution. Caution: Due to the Xscale's limitations, the H (Width) value must be 8n-4 (n: integer) and the V (Height) value must be 2n-2 (n: integer). -
Page 91: Gradation Compression Mode
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Gradation Compression Mode Related Setting Items: ImageFormatControl This function compresses the bit depth of captured images to enable images containing a wide range of pixel values to be output as a narrower set of intensity gradations. -
Page 92: Examples
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE How to Configure 1. Set GradationCompressionMode to On to enable the function. 2. Select a value for GradationCompression1stKneePoint to indicate where to start applying compression on the intensity values coming from the sensor. - Page 93 Cautions: When VideoProcessBypassMode is set to Off, JAI cannot guarantee the configured knee point value because the GradationCompression1st(2nd)KneePoint value will not match the output signal's knee point level due to the effect of the digital gain value, which is performed during post-processing.
-
Page 94: Overlay Mode
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Overlay Mode Related Setting Items: ImageFormatControl Note: This function cannot be used with the Sequencer Function. OverlayMode = MultiRoiAreaMode In this mode, you can check the readout area when using the ROI Function (Multi ROI). -
Page 95: Roi Function (Single Roi)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ROI Function (Single ROI) Related Setting Items: ImageFormatControl The ROI (region of interest) function allows you to output images by specifying the areas to scan. Specify the area to scan by specifying width, height, and horizontal/vertical offset values under ImageFormatControl. -
Page 96: Single Roi - Example
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Height/OffsetY (Lines) Height Binning Mode Binning OFF Binning ON *C, D = HeightMax OffsetY Vertical Binning 8 to [(*C) - OffsetY], 4 to [ (*D) - OffsetY], GOX-5105MC-PGE 2064 1032 Height (lines) -
Page 97: Roi Function (Multi Roi)
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ROI Function (Multi ROI) Related Setting Items: MultiROIControl Notes: Refer to Functions That Cannot Be Used Together for usage restrictions. If this function is turned on while Shading Correction is set to On, Shading Correction will be forced to Off. - Page 98 User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Caution: The specified areas cannot overlap. If the areas overlap, all indexes after the overlapping areas become unconfigurable. Notes: The frame rate can be increased in relation to the size of the area specified in the vertical direction, but not in relation to the horizontal direction.
-
Page 99: Configuration Example
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Configuration Example To use four areas as shown below, refer to the following. 1. Set MultiROIControl->MultiRoiMode On. 2. Select “0” in MultiRoiIndex. Set MultiRoiWidth, MultiRoiHeight, MultiRoiOffsetX and MultiRoiOffsetY. -
Page 100: Edge Enhancer
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Edge Enhancer Related Setting Items: ImagingControl This camera is equipped with an Edge Enhancer function for enhancing the contrast of lines or edges within images. -
Page 101: Sequencer Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Sequencer Function Related Setting Items: SequencerControl The Sequencer function lets you define up to 32 index combinations of exposure time, gain, ROI, and other settings which can be stepped through each time a trigger is received. -
Page 102: Sample Triggersequencer Mode Operation
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE SequencerFrameCount: This configures the number of frame acquisitions for the selected SequencerIndex. SequencerReset: During TriggerSequencer mode operation, this switches the index number to be executed to that specified in SequencerSetStart. -
Page 103: Commandsequencer Mode
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE CommandSequencer Mode As with TriggerSequencer mode, you can define up to 32 indexes beforehand in this mode. Set SequencerCommandIndex to point to one of your preconfigured indexes. This index will be executed on each trigger, until it is changed to point to a different index, typically by your vision application. -
Page 104: Pulse Generator
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Pulse Generator Related Setting Items: PulseGenerator Tips for using the Pulse Generator By using this function, any signal can be generated inside the camera. The following is an example of signal generation. -
Page 105: Counter And Timer Control Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Counter and Timer Control Function Related Setting Items: CounterAndTimerControl Note: This camera supports only the counter function. The counter function counts up change points in the camera’s internal signals using the camera’s internal counter and reads that information from the host side. -
Page 106: Internal Camera Blocks
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Note: You can reset a specific counter's count value by executing CounterReset[Counter0, Counter1, Counter2, Counter3]. Internal Camera Blocks To Use the Counter Function Configure the settings as follows. -
Page 107: Action Control Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Action Control Function Related Setting Items: ActionControl How to use GigE Vision Action Commands The Action Control Function is a function that executes the pre-configured action when the camera receives action commands. - Page 108 User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ActionDeviceKey : 0x00001001 ActionGroupMask[1] : 0x00000011 ActionGroupKey[1] : 0x00000001 ActionGroupMask[2] : 0x00000111 ActionGroupKey[2] : 0x00000002 When the camera receives action commands (ActionDeviceKey:0x00001001, ActionGroupMask:0x00000011, ActionGroupKey: 0x00000002), Action2 is executed.
-
Page 109: Event Control Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Event Control Function Related Setting Items: EventControl The Event Control function is a function that outputs a signal change point inside the camera as information indicative of an event occurrence (event message). -
Page 110: Chunk Data Function
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Chunk Data Function Related Setting Items: ChunkDataControl The Chunk Data function adds camera configuration information to the image data that is output from the camera. -
Page 111: Non-Volatile Flash Memory
The camera has non-volatile memory for users to store data. Refer to the technical note “Storing Data in On-Camera Flash Memory” for more information. Note: JAI strongly recommends saving images to the PC or other storage location because the non-volatile flash memory may not have enough memory size to store large data. -
Page 112: Functions That Cannot Be Used Together
User Manual (Ver. 1.0) - Main Functions GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Functions That Cannot Be Used Together The table below shows functions that cannot be used with ImageFormatControl, MultiROIControl SequencerControl setting items. Note: For functions that are not in this table, refer to the relevent function topic or setting item topic. -
Page 113: Setting List
Setting List This camera complies with GenICam. Each setting item name conforms to GenICam SFNC (Standard Features Naming Convention). (There are some JAI-specific setting items). Each setting item is an integer type (IInteger), a real type (IFloat), an element enumeration type (IEnumeration), a character string (IString), a logical type (IBoolean), and a category type (ICategory) or a command type (ICommand) for executing the function. -
Page 114: Feature Properties
DeviceControl Display/configure information related to the device. Default DeviceControl Item Setting Range Description Value DeviceScanType 0:Areascan Display the device scan type. "JAI DeviceVendorName Display the manufacturer name. Corporation" DeviceModelName Display the model name. See the DeviceManufacturerInfo Display the manufacturer information. - Page 115 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Default DeviceControl Item Setting Range Description Value DeviceTLVersionMajor 2 (Fixed) Indicates the major version number of the device's Transport Layer. DeviceTLVersionMinor 0 (Fixed) Indicates the minor version number of the device's Transport Layer.
-
Page 116: Transportlayercontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE TransportLayerControl Display information on transport layer control. Setting TransportLayerControl Item Default Value Description Range PayloadSize Display the payload size. (Include ChunkData) (unit: bytes) GigEVision 0:Single Link GevPhysicalLinkConfiguration... - Page 117 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting TransportLayerControl Item Default Value Description Range GevCurrentDefaultGateway Display the default gateway. Display the current IP configuration status. GevIPConfigurationStatus 2:DHCP Setting Range: 0:None , 1:PersistentIP, 2:DHCP, 3:LLA, 4:ForceIP GevPersistentIPAddress 192.168.0.100 Set the persistent IP address.
- Page 118 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting TransportLayerControl Item Default Value Description Range Control access rights. 0:OpenAccess - Access rights have not been obtained by the application. 0:OpenAccess 1:ExclusiveAccess - Once the application has made this setting, no GevCCP 0～2...
- Page 119 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting TransportLayerControl Item Default Value Description Range Controls the delay (in GEV timestamp counter unit) to insert between each packet for this stream channel. (step 8) Min: 0 GevSCPD Max: The value depends on the PixelFormat, Width,...
-
Page 120: Imageformatcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ImageFormatControl Configure image format settings. Note: Refer to Functions That Cannot Be Used Together for usage restrictions. Setting Default Image Format Control Item Description Range Value... - Page 121 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Image Format Control Item Description Range Value Set the image width. Width Note: This setting is available only when ImageScalingMode=Off. WidthMax Related Topic: ROI Function...
- Page 122 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Image Format Control Item Description Range Value BinningVerticalMode 0:Sum Set the processing method for vertical binning. Monochrome 0:Sum Related Topic: Binning 1:Average models only.
- Page 123 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Image Format Control Item Description Range Value ReverseX 0～ 1 Reverse pixels horizontally. Related Topic: Image Flip Function ReverseY 0～ 1 Reverse pixels vertically.
- Page 124 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Image Format Control Item Description Range Value Set the pixel format. Color Models 0x01080009: BayerRG8 (Default) 0x0110000D: BayerRG10 0x010C0027: BayerRG10Packed 0x01100011: BayerRG12 0x010C002B: BayerRG12Packed 0x01080008: BayerGR8*...
- Page 125 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Image Format Control Item Description Range Value Set the first knee compression rate for the sensor's gradation compression function in dB. GradationCompression1stGain Setting Range (dB): 0, -6, -12, -18, -24, -30, -36, -42, -48, -54, -60, Set the second knee point of the sensor's gradation compression...
-
Page 126: Multiroicontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE MultiROIControl Configure settings for Multi ROI. Related Topic: ROI Function (Multi ROI) Note: Refer to Functions That Cannot Be Used Together for usage restrictions. Setting Default Multi ROI Control Item... - Page 127 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Multi ROI Control Item Description Range Value Set the vertical offset for the selected Multi Roi index. Min: The minimum value of the range where each Index does not overlap. MultiRoiOffsetY Max: The maximum value of the range where each Index does not overlap.
-
Page 128: Acquisitioncontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE AcquisitionControl Configure image capture settings. Acquisition Control Setting Range Default Value Description Item AcquisitionMode 0:SingleFrame Related Topic: 1:MultiFrame 2:Continuous Select the image capture mode. Acquisition 2:Continuous Control... - Page 129 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Acquisition Control Setting Range Default Value Description Item Select the trigger signal source. 7-10: PulseGenerator0-3 11-14: UserOutput0 -3 15-18: Action0-3 TriggerSource 24: Line5 Opt In 19:Software 24: Line5 Opt In 36: Nand0 Out...
-
Page 130: Digitaliocontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Acquisition Control Setting Range Default Value Description Item Enables RCT mode or BurstTrigger mode. 0: Off ExposureModeOption 1: RCT 0: Off Related Topic: Mode, Burst Trigger Mode 2: BurstTrigger... - Page 131 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Digital IO Control Setting Default Description Item Range Value Select the line source signal for the item selected in LineSelector. 0: Off (Only when LineSelector is set to TimestampReset) 1: AcquisitionActive 2: FrameActive 4: ExposureActive...
- Page 132 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Digital IO Control Setting Default Description Item Range Value Set the UserOutput signal. 0: User Output 0 UserOutput 0: User 1: User Output 1 Selector Output 0 2: User Output 2...
-
Page 133: Pulsegenerator
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE PulseGenerator Configure pulse generator settings. Related Topic: Pulse Generator Pulse Generator Item Setting Range Default Value Description Set the division value for the prescaler (12 bit) using 1 ～... - Page 134 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Pulse Generator Item Setting Range Default Value Description Set the start point of the Low interval in milliseconds. When the counter reaches this value, the output will be 0. The setting range varies depending on the ClockPreScaler PulseGeneratorEndPointMs value.
-
Page 135: Analogcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE AnalogControl Configure the analog control settings. Analog Control Default Setting Range Description Item Value GainSelector Select the gain to configure. 0: Analog All 0:Analog 1: Digital Red Related Topic:... - Page 136 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Analog Control Default Setting Range Description Item Value Select the area for which to configure AWBAreaEnable. Note: Color models only. 0: Low Right 1: Low Mid-Right 2: Low Mid-Left 3: Low Left...
-
Page 137: Lutcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Analog Control Default Setting Range Description Item Value Gamma Set the gamma value. Related Topic: 0.45～1 0.45 Gamma Setting Range: 0.45, 0.50, 0.55, 0.60, 0.65, 0.75, 0.80, 0.90, 1.00 Function 0: Off LUTMode... -
Page 138: Autolevelcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE AutoLevelControl Configure AutoLevelControl. Related Topic: ALC (Automatic Level Control) Function Auto Level Control Setting Default Description Item Range Value Sets the channel to be used for ALC control reference. Note: Color models only. - Page 139 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Auto Level Control Setting Default Description Item Range Value True: Operate ALC with all areas designated as photometry areas, regardless of the individual enabled/disabled photometry area states configured in ALCAreaSelector.
-
Page 140: Imagingcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ImagingControl Configure other JAI functions. Imaging Control Item Setting Range Default Value Description VideoProcessBypassMode 0: Off 0: Off Enable/disable VideoProcessBypass mode. 1: On... -
Page 141: Shadingcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ShadingControl Configure shading correction settings. Related Topic: Shading Correction Setting Default Shading Control Item Description Range Value Select the shading correction method. 0: Flat ShadingCorrectionMode 0: Flat Shading... -
Page 142: Blemishcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE BlemishControl Configure settings for JAI white blemish correction. Related Topic: BlemishCompensation Setting Default Blemish Control Item Description Range Value Enable/disable blemish correction. -
Page 143: Sequencercontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Blemish Control Item Description Range Value Display the Y coordinate (vertical pixel position) of the target blemish selected in BlemishCompensationIndex. You can also manually enter the Y BlemishCompensation coordinate of the blemish you want to correct. - Page 144 User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Setting Default Sequencer Control Item Description Range Value Set the vertical offset value for the selected SequencerIndex. Setting Range: 0～[Height - Height], Step 2(1)* SequencerOffsetY *For monochrome models, when BinningVertical = 2, the value in parentheses is applicable.
-
Page 145: Counterandtimercontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE CounterAndTimerControl Configure counter settings. Note: This camera only supports the counter functions. Related Topic: Counter and Timer Control Function Counter and Timer Control Setting Default Description... -
Page 146: Actioncontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ActionControl Configures action control settings. Related Topic: Action Control Function Default Action Control Item Setting Range Description Value 0x00000000 〜 An action command is executed if this ActionDeviceKey matches the DeviceKey ActionDeviceKey 0x00000000 0xFFFFFFFF... -
Page 147: Eventcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE EventControl Configure settings for event control. Related Topic: Event Control Function Setting Default Event Control Item Description Range Value Select the event to send the event message. 0: AcquisitionTrigger 0: Acquisition 1: FrameStart... -
Page 148: Chunkdatacontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE ChunkDataControl Configure Chunk Control settings. Related Topic: Chunk Data Function Default Chunk Data Control Item Setting Range Description Value 0: Off ChunkModeActive 0: Off Set whether to enable ChunkData. -
Page 149: Testcontrol
User Manual (Ver. 1.0) - Setting List GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE TestControl Configure the test control setting. Test Control Setting Default Description Item Range Value PendingAck function test command. The camera waits for TestPendingAck (ms) time and TestPendingAck 0〜... -
Page 150: Miscellaneous
GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. Power Supply and Connections Issue: The POWER/TRIG LED remains lit amber and does not turn green, even after power is supplied to the camera. -
Page 151: Specifications
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Specifications Item Monochrome Color Scanning System Progressive scan, 1 tap Synchronization Internal Interface 1000BASE-T Ethernet (GigE Vision 2.0), IEEE 802.3af Image Sensor Monochrome CMOS Bayer Color CMOS >60 dB@10bit Conditions:... - Page 152 User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Item Monochrome Color PixelFormat: Mono8, BayerRG8, BayerGR8, BayerGB8, BayerBG8 GOX-5105MC-PGE: 21fps GOX-8105MC-PGE: 13fps Acquisition Frame GOX-12405MC-PGE: 8fps Rate GOX-16205MC-PGE: 6fps (Max) - PixelFormat: GOX-20405MC-PGE: 5fps 8Bits GOX-24505MC-PGE: 4fps...
- Page 153 GOX-20405MC-PGE: 0 to [4512 (2256) - Height], step2(1) GOX-24505MC-PGE: 0 to [4608 (2304) - Height], step2(1) Note: For monochrome models, when BinningHorizontal = 2 or FD2x2BinningMode = On, the value in parenthesis is applicable. GOX-5105M-PGE: 2472 Digital Image Output GOX-8105M-PGE: 2856 Format: Binning (H) =...
- Page 154 User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Item Monochrome Color GOX-5105M-PGE: 1236 Digital Image Output GOX-8105M-PGE: 1428 Format: Binning (H) = GOX-12405M-PGE: 2064 2 or GOX-16205M-PGE: 2664 FD2x2BinningMode = GOX-20405M-PGE: 2256...
- Page 155 User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Item Monochrome Color Digital I/O LineSelector (6P): GPIO IN / GPIO OUT Default Level: 8LSB@8bit All (Mono/Color): -133 ~ +255 LSB Black Level Red (Color): -64 ~ +64 LSB Adjustment Blue (Color): -64 ~ +64 LSB...
- Page 156 User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Item Monochrome Color Regulations CE [EN 55032:2015(CISPR32:2015) Class B, EN 55035:2017 (CISPR35:2016)], FCC Part 15 Class B, EU RoHS/WEEE, (Tentative) China RoHS, KC Housing 29mm x 29mm x 55mm (WHD, excluding connectors) Weight...
-
Page 157: Package Contents
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Package Contents Camera (1) Sensor protection cap (1) Dear customer (sheet) (1) Optional Accessories (Sold Separately) MP-46 Tripod Adapter Plate Notes: Design and specifications are subject to change without notice. Approximately 30 minutes of warm-up are required to achieve these specifications. -
Page 158: Spectral Response (Gox-5105M-Pge/Gox-5105C
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Spectral Response (GOX-5105M-PGE/GOX-5105C-PGE) - 158 -... -
Page 159: Spectral Response (Gox-8105M-Pge/Gox-8105C
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Spectral Response (GOX-8105M-PGE/GOX-8105C-PGE) - 159 -... -
Page 160: Spectral Response (Gox-12405M-Pge/Gox-12405C
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Spectral Response (GOX-12405M-PGE/GOX-12405C-PGE) - 160 -... -
Page 161: Spectral Response (Gox-16205M-Pge/Gox-16205C
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Spectral Response (GOX-16205M-PGE/GOX-16205C-PGE) - 161 -... -
Page 162: Spectral Response (Gox-20405M-Pge/Gox-20405C
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Spectral Response (GOX-20405M-PGE/GOX-20405C-PGE) - 162 -... -
Page 163: Spectral Response (Gox-24505M-Pge/Gox-24505C
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Spectral Response (GOX-24505M-PGE/GOX-24505C-PGE) - 163 -... -
Page 164: Dimensions
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Dimensions Notes: Dimensional tolerance: ± 0.3mm Unit: mm - 164 -... -
Page 165: Comparison Of The Decibel Display And Multiplier Display
User Manual (Ver. 1.0) - Miscellaneous GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Comparison of the Decibel Display and Multiplier Display Decibels [dB] Multipliers [X] Remarks 0.501 0.562 0.631 0.708 0.794 0.891 1.122 1.259 1.413 1.585 1.778 1.995 2.239... -
Page 166: User's Record
63.096 70.795 79.433 89.125 112.202 125.893 User's Record Camera type: Go-X Series Global Shutter GigE interface Model name: …………… Revision: …………… Serial No: …………… Firmware version: …………… For camera revision history, please contact your local JAI distributor. - 166 -... -
Page 167: Revision History
User Manual (Ver. 1.0) - Revision History GOX-5105MC-PGE | GOX-8105MC-PGE | GOX-12405MC-PGE | GOX-16205MC-PGE | GOX-20405MC-PGE | GOX-24505MC-PGE Revision History Revision Date Device Version Changes 2022/09/20 DV0100 First Release Trademarks Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. Intel and Intel Core are trademarks of Intel Corporation in the United States and other countries.
Need help?
Do you have a question about the GOX-5105M-PGE and is the answer not in the manual?
Questions and answers
