User Manual
SP-45000M-CXP4A
SP-45000C-CXP4A
45M CMOS Digital Progressive Scan
Monochrome and color Camera
Document Version: 1.2
SP-45000MC-CXP4A_Ver.1.2_Oct.2021
Thank you for purchasing this product.
Be sure to read this manual before use.
This manual includes important safety precautions and instructions on how to operate the unit. Be sure
to read this manual to ensure proper operation.
The contents of this manual are subject to change without notice for the purpose of improvement.
© 2021 JAI
Advertisement
Table of Contents
Related Manuals for JAI SP-45000M-CXP4A
Summary of Contents for JAI SP-45000M-CXP4A
- Page 1 This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation. The contents of this manual are subject to change without notice for the purpose of improvement. © 2021 JAI...
-
Page 2: Notice/Warranty/Certifications
The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein. -
Page 3: Table Of Contents
SP-45000M-CXP4A/SP-45000C-CXP4A Contents Notice/Warranty/Certifications Gamma Function Usage Precautions Lookup Table (LUT) Features Blemish Compensation Parts Identifications Shading Correction Binning Function Preparation ROI Function (Single ROI) Preparation Process ROI Function (Multi ROI) Step 1:Connecting Devices Overlay mode Step 2:Verifying Camera Operation Image flip function... - Page 4 LensCommunicationControl EventControl Heartbeat About Technical Note ■ Some additional technical information is provided on the JAI website as Technical Notes. In this manual, if a technical note is available for a particular topic, the icon is shown. Technical notes Please refer to the following URL for Technical notes.
- Page 5 SP-45000M-CXP4A/SP-45000C-CXP4A Supplement The following statement is related to the regulation on “Measures for the Administration of the control of Pollution by Electronic Information Products“ , known as “China RoHS“. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.
-
Page 6: Usage Precautions
SP-45000M-CXP4A/SP-45000C-CXP4A Usage Precautions Notes on cable configurations The presence of lighting equipment and television receivers nearby may result in video noise. In such cases, change the cable configurations or placement. Notes on temperature conditions The guaranteed operating temperature and humidity of this camera are -5℃ to +45℃, 20% to 80% (non-condensing). -
Page 7: Features
SP-45000M-CXP4A/SP-45000C-CXP4A Features SP-45000M-CXP4A/SP-45000C-CXP4A are new members of JAI’s Spark Series, which provides an attractive combination of high resolution, high speed, and high image quality for machine vision applications. SP-45000M-CXP4A produces monochrome output and SP-45000C-CXP4A produces Bayer output. Both are industrial progressive scan cameras using a CMOS image sensor with a global shutter and an optical format of Super 35mm. -
Page 8: Parts Identifications
SP-45000M-CXP4A/SP-45000C-CXP4A Parts Identification ② ⑥ ⑤ ③ ⑧ ① ④ ⑦ ① Lens mount（F-mount） Mount an F-mount lens, microscope adapter, etc. here. ❖ Before mounting a lens, be sure to refer to “Step 2:Connecting Devices” and confirm the precautions for attaching a lens and the supported lens types. - Page 9 SP-45000M-CXP4A/SP-45000C-CXP4A ③ CXP (CoaXPress) connector 1～4 Coaxial cable for digital video output Connect. (The camera connector (Amphenol RF 034-1028-12G equivalent) is used.) The CxpLink Configuration supported by this camera is as follows. CXP12_X4*, CXP12_X3*, CXP12_X2*, CXP12_X1* CXP6_X4, CXP6_X3, CXP6_X2, CXP6_X1 Caution ・*The CxpLink Configuration (CXP12_X4, CXP12_X3, CXP12_X2, CXP12_X1) can only...
- Page 10 SP-45000M-CXP4A/SP-45000C-CXP4A ⑤ DC IN/TRIG connector（12-pin round） Connect the cable for a power supply (optional) or for DC IN / trigger IN here. Compatible connectors Camera side : HR10A-10R-12PB（71）（Hirose Electric or equivalent ） Cable side : HR10A-10P-12S (plug) (Hirose Electric or equivalent ）...
- Page 11 SP-45000M-CXP4A/SP-45000C-CXP4A ■ Recommended external input circuit diagram (reference example) (*1) (*2) Opto In 1 : (*1) Pin6 (Opto In 1＋) (*2) Pin5 (Opto In 1－) ■ Recommended external output circuit diagram (reference example) OPTO-In circuit characteristics Technical notes Digital I/O...
- Page 12 SP-45000M-CXP4A/SP-45000C-CXP4A ■Characteristics of the recommended circuits for Opto OUT OUTPUT LINE RESPONSE TIME Camera Output Signal Output Line Voltage For the operating conditions of applied voltage (User Power) +12V, load resistance 10kΩ, and cable length 1m, the timing is shown in the table below.
- Page 13 SP-45000M-CXP4A/SP-45000C-CXP4A ⑥ AUX connector（10-pin） Camera side：3260-10S3 (55) (Hirose Electric or equivalent) Cable side ：3240-10P-C (50) (Hirose Electric or equivalent) Pin No. Signal Description Input/Output TTL Out 2 Line 8 N.C. TTL In 2 Line 10 N.C. DC Out LENS Power...
-
Page 14: Preparation
SP-45000M-CXP4A/SP-45000C-CXP4A Preparation Preparation Process Connecting Devices Step 1 Connect the lens, CXP frame grabber, AC adapter, computer and other devices. Verifying Camera Operation Step 2 Verify whether the camera is turned on and ready for use. Verifying the Connection between the Camera and PC Step 3 Set settings and display image using suitable tool for CXP frame grabber board. -
Page 15: Step 1:Connecting Devices
SP-45000M-CXP4A/SP-45000C-CXP4A Step 1: Connecting Devices ⑥ AC adapter (not supplied) Camera body ⑤ DC IN/Trigger IN CXP-1 connection cable CXP-2 ③ CoaXPress cable ①Lens CXP-3 ④ CoaXPress frame grabber board CXP-4 CXP-1 ② Direct connection CXP-2 (or MP-42 tripod adapter plate) -
Page 16: Step 2:Verifying Camera Operation
SP-45000M-CXP4A/SP-45000C-CXP4A ④ CXP frame grabber board Refer to the operating instructions of the frame grabber board, and configure settings on the computer as necessary. ⑤ DC IN / trigger IN connection cable ⑥ AC adapter (power supply) Connect the AC adapter and the round connector of the connection cable to the DC IN / TRIG IN connector on the camera. -
Page 17: Step 4:Adjusting The Image Quality
SP-45000M-CXP4A/SP-45000C-CXP4A Step 4: Adjusting the Image Quality Adjusting the Gain To adjust the image quality The Visibility must be changed from [Beginner] to [Guru]. At first, adjust the sensitivity via the analog base gain. Next, set digital gain. For details on gain control, see “Gain Control”... -
Page 18: Step 5:Saving The Settings
SP-45000M-CXP4A/SP-45000C-CXP4A Step 5: Saving the Settings The setting values configured in the tool will be deleted when the camera is turned off. By saving current setting values to user memory, you can load and recall them whenever necessary. You can save up to three sets of user settings in the camera. (User Set1 to 3) Memory(Flash) 一時メモリ... -
Page 19: Main Functions
SP-45000M-CXP4A/SP-45000C-CXP4A Main Functions CXP2.0 Supported Functions This camera supports the following CXP2.0 functions (the CoaXPress frame grabber board used must support CXP 2.0 or later). You can check the current CXP version in Transport Layer Control's CxpVersionUsed. If CxpVersionUsed is CXP1.1, you cannot use these functions. -
Page 20: Acquisition Control
Acquisition Control This camera has three Acquisition modes (SingleFrame, MultFrame, Continuous). Use [AcquisitionControl] settings to perform operations and settings for image capture. SingleFrame When the [AcquisitionStart] command is executed, one frame of image is captured. Acquisition Acquisition Start Start MultiFrame When the [AcquisitionStart] command is executed, the number of frames set in [AcquisitonFrameCount] are acquired as images. -
Page 21: Exposure Mode
SP-45000M-CXP4A/SP-45000C-CXP4A Exposure Mode This camera has three Exposure modes (Off, Timed, TriggerWidth). Use [AcquisitionControl] settings to perform operations and settings for exposure. ExposureMode = Off Exposure control is not performed (free-running operation). The exposure time is the longest possible time within the operating conditions such as the frame rate. -
Page 22: Trigger Control
SP-45000M-CXP4A/SP-45000C-CXP4A Trigger Control The camera allows the following controls to be performed via external trigger signals. TriggerSelector Description AcquisitionStart Start image acquisition in response to the external trigger signal input. AcquisitionEnd Stop image acquisition in response to the external trigger signal input. -
Page 23: Pixel Format
SP-45000M-CXP4A/SP-45000C-CXP4A Pixel Format Selectable PixelFormat is as follows. SP-45000C-CXP4A : BayerRG8, BayerRG10, BayerRG12, BayerRG14 SP-45000M-CXP4A : Mono8, Mono10, Mono12, Mono14 Note 1. In SP-45000C-CXP4A, the Bayer array is changed by the image flip function. (Please refer to “Image flip function”) ReverseX : 0 (False) ReverseY : 0 (False) ->... -
Page 24: Gpio (Digital Input/Output Settings)
SP-45000M-CXP4A/SP-45000C-CXP4A GPIO (Digital Input/Output Settings) The unit can input/output the following signals to and from external input/output connectors. Line1 : TTL Out 1 DC IN / TRIG IN connector (12-pin round) External Line2 : Opt Out 1 DC IN / TRIG IN connector (12-pin round) - Page 25 SP-45000M-CXP4A/SP-45000C-CXP4A For digital output, set the output source signal using [LineSource]. Set the source signal in the same way for NAND Logic (Nand0In1, Nand0In2, Nand1In1, NandIn2) and TimestampReset. The table below shows the source signals that can be set. ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓...
-
Page 26: Various Imaging Controls
SP-45000M-CXP4A/SP-45000C-CXP4A Various Imaging Controls This camera is equipped with various Imaging Control functions. By using these functions, effects such as reduction of random noise can be obtained. The Imaging Control function has the following operation modes. ・HDR (High Dynamic Range) ・Frame Integration (Frame) mode... -
Page 27: Hdr (High Dynamic Range)
SP-45000M-CXP4A/SP-45000C-CXP4A HDR (High Dynamic Range) When imaging scenes with bright and dark areas, it can be difficult to achieve a good exposure. Setting the exposure for the bright areas can leave the dark areas completely black, while setting the exposure for the dark areas can oversaturate the bright areas. - Page 28 SP-45000M-CXP4A/SP-45000C-CXP4A ■ Maximum Frame Rate Reference The table below shows the maximum frame rate in HDR (Knee, Linear) mode. HDR(Knee) mode [Theoretical value] PixelFormat Width Height Maximum frame rate(fps) 8192 5460 Mono8/Bayer8 8192 4320 4096 2728 8192 5460 CXP12-4 Mono10/Bayer10...
-
Page 29: Frame Integration (Frame) Mode
SP-45000M-CXP4A/SP-45000C-CXP4A Frame Integration (Frame) mode Outputs one frame image that is the average of the captured values for all pixels in the 2-8 frames imaged. As a result, high-quality images with reduced random noise can be obtained. This mode is enabled when [Frame Integration Mode] in [Imaging Control] is set to [Frame]. -
Page 30: Frame Integration (Exposure) Mode
(12bit x 2) are added to calculate one frame image (13bit) inside the camera. The output Pixel Format is 14bit output as follows. SP-45000C-CXP4A : BayerRG14, BayerGR14, BayerGB14, BayerBG14 SP-45000M-CXP4A : Mono14 This mode is enabled when [Frame Integration Mode] in [Imaging Control] is set to [Exposure]. -
Page 31: Videoprocessbypassmode
SP-45000M-CXP4A/SP-45000C-CXP4A VideoProcessBypassMode The video process bypass mode is a function that bypasses internal video processing on the camera. When bypass is enabled, the sensor output and camera output data can be set to the same bit width. 12-bit outputs can only be performed in bypass mode. -
Page 32: Timming Chart
SP-45000M-CXP4A/SP-45000C-CXP4A Timing chart ■ When [ExposureMode] is [Timed] • FrameStartTrigger On A (Frame Period) Next trigger Input enabled Next trigger disabled Trigger Sensor Exposure Exposure Exposure time Active Readout CXP12-4 Period From Trigger start edge to PixelFormat Frame Period [A] (usec) - Page 33 SP-45000M-CXP4A/SP-45000C-CXP4A ■ When [ExposureMode] is [TriggerWidth] • FrameStartTrigger On A (Frame Period) Next trigger Input enabled (Next trigger disabled) Trigger Sensor Exposure Exposure ExposureTime Active Readout CXP12-4 Period From Exposure end to next Period From Trigger start edge to Period From Trigger end to...
-
Page 34: Maximum Frame Rate Reference
SP-45000M-CXP4A/SP-45000C-CXP4A Maximum Frame Rate Reference The table below shows the maximum frame rate in normal mode. [Theoretical value] PixelFormat Width Height Maximum frame rate(fps) 8192 5460 Mono8/Bayer8 8192 4320 4096 2728 8192 5460 CXP12-4 Mono10/Bayer10 8192 4320 4096 2728 8192... -
Page 35: Calculate The Maximum Frame Rate (Approximate)
SP-45000M-CXP4A/SP-45000C-CXP4A Calculate the maximum frame rate (approximate) Maximum frame rate This section describes how to calculate the maximum frame rate in normal mode, excluding HDR (Linear, Knee) mode and Frame Integration (frame, Exposure) mode. ■ LinePeriod[μs] The Value (A) is a fixed value for each LinkConfig(CoaXPress) and PixelFormat. -
Page 36: Gain Control
-7dB -7dB 15dB 15dB x 1.0 -7dB -7dB In SP-45000M-CXP4A, adjust the [AnalogAll] (master gain) setting. Digital All x 16 24dB x 1.0 ■ Automatic Gain Level Control Set [GainAuto] to [Continuous] to control the gain level automatically. When [GainAuto] is set to [Continuous], you can configure the conditions for automatic adjustment in detail. -
Page 37: White Balance
SP-45000M-CXP4A/SP-45000C-CXP4A White Balance To adjust the white balance automatically, set [BalanceWhiteAuto] to Once (automatic adjustment only once) or Continuous (automatic adjustment always). The metering area can be limited for automatic adjustment. To limit the metering area, specify each of the 16 areas with [AWBAreaSelector] and set [AWBAreaEnable] to True or False. -
Page 38: Alc (Automatic Level Control) Function
SP-45000M-CXP4A/SP-45000C-CXP4A ALC (Automatic Level Control) Function The ALC (automatic level control) function combines the automatic gain control (AGC/Auto Gain Control) and automatic exposure control (ASC/Auto Shutter Control) functions, and is capable of handling various changes in brightness.The function operates as follows in response to changes in brightness. -
Page 39: Gamma Function
SP-45000M-CXP4A/SP-45000C-CXP4A Gamma Function The gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing. -
Page 40: Lookup Table (Lut)
SP-45000M-CXP4A/SP-45000C-CXP4A LUT (Lookup Table) The LUT function is used to generate a non-linear mapping between signal values captured on the sensor and those that are output from the camera. You can specify the output curve using 257 setting points (indexes). -
Page 41: Blemishcompensation
SP-45000M-CXP4A/SP-45000C-CXP4A BlemishCompensation Multiple defective pixels that are not adjacent to each other can occur on conventional CMOS sensor cameras. This camera features a function that interpolates defective pixels using the surrounding pixels. Up to 3183 pixels can be corrected. Pixel interpolation can be performed via automatic detection or point-by-point manual settings. -
Page 42: Shading Correction
SP-45000M-CXP4A/SP-45000C-CXP4A Shading Correction The ShadingCorrection function corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V). -
Page 43: Binning Function
[ShadingMode]. Binning Function SP-45000M-CXP4A only The binning function allows you to combine the signal values of clusters of adjacent pixels to create improved virtual pixels. Using the function results in images with lower pixel resolution and higher sensitivity. -
Page 44: Roi Function (Single Roi)
SP-45000M-CXP4A/SP-45000C-CXP4A ROI Function (Single ROI) The ROI (region of interest) function allows you to output images by specifying the areas to scan. Specify the area to scan by specifying width, height, and horizontal/vertical offset values under [ImageFormatControl]. For details on how to configure the settings, see “Configuring the Output Format”. -
Page 45: Roi Function (Multi Roi)
SP-45000M-CXP4A/SP-45000C-CXP4A ROI Function (Multi ROI) In the Multi ROI mode, you can specify up to 64 scanning areas for a single-frame image. The areas cannot overlap. The Multi ROI mode can be used only when both the Sequencer mode and the Shading mode are off. -
Page 46: Overlay Mode
SP-45000M-CXP4A/SP-45000C-CXP4A Overlay mode In this mode, you can check the readout area when using the Multi ROI function. The area that is not read out is displayed with the brightness reduced to half. This makes it possible to set and adjust the readout area while checking the target area on the screen. -
Page 47: Image Flip Function
BayerBG12, BayerBG14 BayerGB12, BayerGB14 Edge enhancer SP-45000M-CXP4A is equipped with an edge enhancer function for enhancing the contrast of lines or edges within images. The edge enhancer function is enabled when EnhancerEnable[Edge] is set to True. Four enhancement levels are available: Low, Middle, High, and Strong. -
Page 48: Cxp Link Sharing Function
SP-45000M-CXP4A/SP-45000C-CXP4A CXP Link Sharing function This function has two operation modes (Sharing mode and Duplicate mode). ■Sharing mode This camera can be connected to multiple PCs and the captured images can be divided and sent to each PC. ① ②... - Page 49 SP-45000M-CXP4A/SP-45000C-CXP4A It is also possible to divide the captured image shown below. ■ Duplicate mode This camera can be connected to multiple PCs and the same captured image can be copied and sent to each PC. [LINK-1] CXP Master connection (LinkSharing Status: Master)
-
Page 50: Event Control Function
Event Control Function The Event Control function is a function that outputs a signal change point inside the camera as information indicative of an event occurrence (event message). ■ Flow from Detecting an Event to Sending an Event Message ■ Events that Can Use the Event Control Function Events that can use the Event Control function are as follows. -
Page 51: Sequencer Function
SP-45000M-CXP4A/SP-45000C-CXP4A Sequencer Function The Sequencer function lets you define up to 128 index combinations of exposure time, gain, ROI, and other settings which can be stepped through each time a trigger is received.This is particularly useful for quickly capturing multiple exposures of objects under inspection to adjust for areas or components with significantly different levels of reflectance. - Page 52 SP-45000M-CXP4A/SP-45000C-CXP4A Sample TriggerSequencer mode operation User-defined Indexes (up to 128) Triggers/ Image Frames Specify "1" in [SequencerSetStart], and start TriggerSequencer mode with index 1. Capture a 2-frame image with the first and second triggers. For the next index, configure index 3 specified in [SequencerSetNext], and capture an image with the number of frames (number of triggers) specified in [SequencerFrameNumber].
-
Page 53: Pulse Generator
SP-45000M-CXP4A/SP-45000C-CXP4A Pulse Generator By using this function, any signal can be generated inside the camera. The following is an example of signal generation. Settings PulseGeneratorStartPoint = 2 PulseGeneratorEndPoint = 6 PulseGeneratorLength = 10 PulseGeneratorPulseWidth = 4 PulseGeneratorClearSyncMode = AsyncMode StartPoint... -
Page 54: Counter And Timer Control Function
SP-45000M-CXP4A/SP-45000C-CXP4A Counter And Timer Control Function This camera supports only the counter function. The counter function counts up change points in the camera’s internal signals using the camera’s internal counter, and reads that information from the host side. This function is useful for verifying error conditions via the count value using internal camera operations. - Page 55 SP-45000M-CXP4A/SP-45000C-CXP4A ■ Internal camera blocks Counter0 Counter Event detection FrameStartTrigger At event occurrence or count up Counter1 Counter Event detection ExposureStart At event occurrence or count up Counter2 Counter Event detection SensorReadOut At event occurrence or count up Counter3 Counter...
-
Page 56: Lens Control (Transfer Camera Control Commands)
Refer to the technical note “Storing Data in On-Camera Flash Memory” for more information. Note JAI strongly recommends saving images to the PC or other storage location because the non-volatile flash memory may not have enough memory size to store large data. -
Page 57: Setting List
SP-45000M-CXP4A/SP-45000C-CXP4A Setting List This camera complies with GenICam. Each setting item name conforms to GenICam SFNC (Standard Features Naming Convention). (There are some JAI-specific setting items). Each setting item is an integer type (IInteger), a real type (IFloat), an element... -
Page 58: Feature Properties
SP-45000M-CXP4A/SP-45000C-CXP4A Feature Properties Item Setting range Default value Description DeviceControl Display/configure information related to the device. DeviceScanType ー Areascan Display the scan type. DeviceVendorName ー "JAI Corporation" Display the manufacturer name. DeviceModelName ー SP-45000M-CXP4A Display the model name. DeviceManufacturerInfo ー... - Page 59 SP-45000M-CXP4A/SP-45000C-CXP4A Item Setting range Default value Description TransportLayerControl Display information on transport layer control. PlayloadSize 32～268369920 44728320 Display the payload size. DeviceTapGeometry ー Geometry_1X_1Y Set the Tap Geometry. [Setting range] 0:Geometry_1X_1Y, 1:Geometry_2X_1Y, 2:Geometry_3X_1Y 3:Geometry_4X_1Y, 4:Geometry_8X_1Y CoaXPress CxpLinkConfigurationPreferred The Link configuration is returned as the combination of the Connection speed and the number of active Connections using the following format "CXPm_Xn", where m is the Connection speed and n the number of active...
- Page 60 PixelFormat ー SP-45000C-CXP4A : Set the pixel format. BayerRG8 In SP-45000C-CXP4A, the PixelFormat that can be set differs depending on the ReverseX settings. SP-45000M-CXP4A : [Setting range] Mono8 [SP-45000C-CXP4A] ReverseX : 0 (False) ReverseY : 0 (False) 0x01080009:BayerRG8, 0x0110000D:BayerRG10, 0x01100011:BayerRG12,...
- Page 61 SP-45000M-CXP4A/SP-45000C-CXP4A Item Setting range Default value Description AcquisitionControl Configure image capture settings. AcquisitionMode 0:SingleFrame, Countinuous Select the image capture mode. 1:MultiFrame, 2:Continuous AcquisitionStart ー ー Start image capture. AcquisitionStop ー ー Stop image capture. AcquisitionFrameCount 1～65535 In [MultiFrame] mode, set the number of frames to capture.
- Page 62 SP-45000M-CXP4A/SP-45000C-CXP4A Item Setting range Default value Description DigitalIOcontrol Configure settings for digital input/output. LineSelector ー Line1 Select the input/output to configure. [Setting range] 20:Line1 TTL Out1, 21:Line2 Opt Out1, 23:Line4 TTL In1 24:Line5 Opt In1, 26:Line7 Cxp In, 27:Line8 TTL Out2...
- Page 63 SP-45000M-CXP4A/SP-45000C-CXP4A Item Setting range Default value Description m) PulseGenerator Configure pulse generator settings. ClockPreScaler 1～4096 Set the division value for the prescaler (12 bit) using PixelClock as the base clock. PulseGeneratorClock (MHz) 0.0181274～74.25 Set the clock used for the pulse generator.
- Page 64 SP-45000M-CXP4A/SP-45000C-CXP4A Item Setting range Default value Description AnalogControl Configure analog control settings. GainSelector 0:DigitalAll, DigitalAll Select the gain to configure. 1:DigitalRed, (DigitalRed, DigitalBlue are available for SP-45000C-CXP4A only) 2:DigitalBlue Gain DigitalAll DigitalAll, x1.0 Set the gain value for the gain setting selected in [GainSelector].
- Page 65 Both the Frame and Exposure modes can be set only when HDRMode is Off. FrameIntegrationFrameNumber 2～8 FrameIntegrationExposure1 40～8000000 FrameIntegrationExposure2 40～8000000 EdgeEnhancer EdgeEnhancerEnable True, False False Enable/disable EdgeEnhancer. (SP-45000M-CXP4A only) EdgeEnhancerLevel 0:Low, 1:Middle, Middle Set the Level for EdgeEnhancer. (SP-45000M-CXP4A only) 2:High, 3:Strong - 65 -...
- Page 66 1: Succeeded (Shading calibration was Succeeded.) 2: Error1 (Image was too bright.) 3: Error2 (Image was too dark.) 4: Error3 (Could not calibrated.) 5: Error4 (Correction Limit.) BlemishControl Configure settings for JAI white blemish correction. BlemishEnable True, False True Enable/disable blemish correction. BlemishDetect ー...
- Page 67 SP-45000M-CXP4A/SP-45000C-CXP4A Item Setting range Default value Description SequencerControl Configure sequencer settings. SequencerMode Off, On Enable/disable [SequencerMode]. SequencerModeSelect 0:TriggerSequencerMode, TriggerSequencerMode Select the sequencer mode. 1:CommandSequencerMode SequencerSetSelector 1～128 Select the index number to configure. SequencerWidth 128～8192 step 128 8192 Set the width of the selected SequencerIndex.
- Page 68 SP-45000M-CXP4A/SP-45000C-CXP4A Item Setting range Default value Description LensCommunicationControl Configure settings for Lens Communication Control. LensCommunicationEnable 0, 1 Enable RS-232C for lens control. LensCommunicationBaudrate ー 115200bps Set the baud rate during communication. [Setting range] 0:9600bps, 1:19200bps, 2:38400bps, 3:57600bps, 4:115200bps LensCommunicationDataBit 0:7bit 1:8bit Set the data length during communication.
-
Page 69: Miscellaneous
SP-45000M-CXP4A/SP-45000C-CXP4A Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. ■ Power supply and connections Problem Cause and solution The POWER/TRIG LED remains lit amber and Camera initialization may not be complete does not turn green, even after power is due to lack of a network connection. -
Page 70: Specifications
Scanning system Progressive scan Synchronization Internal Interface CoaXPress v2.0/v1.1 SP-45000C-CXP4A Bayer color CMOS Image sensor SP-45000M-CXP4A Monochrome CMOS Image size (effective image) Super 35mm 31.5mm(diagonal) Pixel size 3.2 μm (H) x 3.2 μm(V) Effective image pixels 8192(H) x 5460(V) Acquisition... - Page 71 SP-45000M-CXP4A/SP-45000C-CXP4A LineSelector ( DC IN/TRIG connector (12-pin round), Digital /O AUX connector (10-pin) ) ：GPIO IN / GPIO OUT Default level 8LSB@8bit DigitalAll : -133 ~ +255 LSB @12bit Black Level Video level adjustment range DigitalRed : -64 ~ +64 LSB @12bit...
- Page 72 SP-45000M-CXP4A/SP-45000C-CXP4A Package contentsCamera body (1) Sensor protection cap (1) Dear Customer (sheet) (1) Optional accessories (not supplied) MP-42 tripod mount Design and specifications are subject to change without notice. Approximately 30 minutes of warm-up are required to achieve these specifications.
-
Page 73: Spectral Response
SP-45000M-CXP4A/SP-45000C-CXP4A Spectral Response SP-45000C-CXP4A Wave length (nm) SP-45000M-CXP4A Wave length (nm) - 73 -... -
Page 74: Dimensions
SP-45000M-CXP4A/SP-45000C-CXP4A Dimensions F-mount M42-mount Dimensional tolerance: ± 0.3mm Unit: mm - 74 -... -
Page 75: Comparison Of The Decibel Display And Multiplier Display
SP-45000M-CXP4A/SP-45000C-CXP4A Comparison of the Decibel Display and Multiplier Display Decibels [db] Multipliers [x] Remarks 0.447 0.501 0.562 0.631 0.708 0.794 0.891 1.122 1.259 1.413 1.585 1.778 1.995 2.239 2.512 2.818 3.162 3.548 3.981 4.467 5.012 5.623 6.31 7.079 7.943 8.913 11.22... -
Page 76: User's Record
Camera type: SP-45000M-CXP4A / SP-45000C-CXP4A Revision: …………… Serial No: …………… Firmware version: …………… For camera revision history, please contact your local JAI distributor. Trademarks • Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. -
Page 77: Index
SP-45000M-CXP4A/SP-45000C-CXP4A Index 12-pin round Heartbeat Acquisition Adjusting the Black Level Adjusting the Gain Lens Lens mount Lookup Table Binning Function Blemish Compensation Parts Identification Pixel format Camera locking screw holes POWER/TRIG LED Connecting Devices Counter And Timer Control CXP Connector... -
Page 78: Revision History
SP-45000M-CXP4A/SP-45000C-CXP4A Revision history Revision Date Changes Added the EventControl and Heartbeat functions. Oct. 2021 Added the Non-Volatile Flash Memory topic. Apr. 2021 Change the Caution for CXP connector. Nov. 2020 First Version - 78 -...
