User Manual
AP-3200T-10GE
Digital 3CMOS Progressive Scan
RGB Color Camera
Document Version: 1.0
AP-3200T-10GE_Ver.1.0 _Sep.2020
Thank you for purchasing this product.
Be sure to read this manual before use.
This manual includes important safety precautions and instructions on how to operate the unit. Be sure
to read this manual to ensure proper operation.
The contents of this manual are subject to change without notice for the purpose of improvement.
© 2020 JAI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-3200T-10GE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JAI AP-3200T-10GE

Summary of Contents for JAI AP-3200T-10GE

  • Page 1 This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation. The contents of this manual are subject to change without notice for the purpose of improvement. © 2020 JAI...

  • Page 2: Notice/Warranty/Certifications

    The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.

  • Page 3: Table Of Contents

    AP-3200T-10GE Contents ROI Function (Single ROI) Notice/Warranty/Certifications ROI Function (Multi ROI) Usage Precautions Sequencer Function Features Color Space Conversion Parts Identifications Edge Enhancer, Color Enhancer Chunk Data Function Preparation Counter And Timer Control Function Preparation Process Pulse Generator Step 1: Installing the Software (first time only)
  • Page 4 ActionControl EventControl TestControl About Technical Note ■ Some additional technical information is provided on the JAI website as Technical Notes. In this manual, if a technical note is available for a particular topic, the icon is shown. Technical notes Please refer to the following URL for Technical notes.
  • Page 5 AP-3200T-10GE Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

  • Page 6: Usage Precautions

    AP-3200T-10GE Usage Precautions Notes on cable configurations The presence of lighting equipment and television receivers nearby may result in video noise. In such cases, change the cable configurations or placement. Notes on temperature conditions The guaranteed operating temperature and humidity of this camera are -5℃ to +45℃, 20% to 80% (non-condensing).

  • Page 7: Features

    AP-3200T-10GE Features The AP-3200T-10GE is an industrial progressive scan camera that uses three 1/1.8-inch global shutter CMOS image sensors with 2064×1544 effective pixels. It allows maximum frame rates of 106.29 fps at full resolution. Enhanced color reproduction is achieved via the newly-developed compact-designed 1/1.8-inch 3CMOS C-mount F4 prism optical system in addition to the internal color...

  • Page 8: Parts Identifications

    AP-3200T-10GE Parts Identification ⑩ ⑩ ② ⑦ ⑥ ⑨ ⑨ ① ③ ⑧ ⑧ ① Lens mount（F-mount） Mount a C-mount lens, microscope adapter, etc. here. ❖ Before mounting a lens, be sure to refer to “Step 2:Connecting Devices” and confirm the precautions for attaching a lens and the supported lens types.
  • Page 9 AP-3200T-10GE ③ RJ-45 connector The camera supports the following Ethernet standards. (1000Base-T, 2.5GBase-T, 5GBase-T, 10GBase-T) Depending on the Ethernet standard to be used, the cable type and the maximum cable length are limited. For details, refer to "Step 2 Connecting Devices".
  • Page 10 AP-3200T-10GE ⑥ DC IN/TRIG connector（12-pin round） Connect the cable for a power supply (optional) or for DC IN / trigger IN here. Compatible connectors Camera side : HR10A-10R-12PB（71）（Hirose Electric or equivalent ） Cable side : HR10A-10P-12S (plug) (Hirose Electric or equivalent ）...
  • Page 11 AP-3200T-10GE Caution About Opto In.Check the recommended external input circuit diagram (reference example) and connect correctly. If you connect Opto In 1 and Opto In 2 in reverse, camera may be damaged. ■ Recommended external input circuit diagram (reference example)
  • Page 12 AP-3200T-10GE ■Characteristics of the recommended circuits for Opto OUT OUTPUT LINE RESPONSE TIME Camera Output Signal Output Line Voltage For the operating conditions of applied voltage (User Power) +12V, load resistance 10kΩ, and cable length 1m, the timing is shown in the table below.
  • Page 13 AP-3200T-10GE ⑦ AUX connector（10-pin） Camera side：3260-10S3 (55) (Hirose Electric or equivalent) Cable side ：3240-10P-C (50) (Hirose Electric or equivalent) Pin No. Signal Description Input/Output TTL OUT2 Line8 TTL_IN2 Line10 OptOut2(-) Line3 OptOut2(+) ⑧ Camera locking screw holes （M3, 5 mm depth）...

  • Page 14: Preparation

    When using the camera for the first time, install the software for configuring and controlling the camera (eBUS SDK for JAI) on the computer. ❖ When you install eBUS SDK for JAI, eBUS SDK for JAI player will also be installed. Download the eBUS SDK for JAI from the JAI website.

  • Page 15: Step 2: Connecting Devices

    AP-3200T-10GE Step 2: Connecting Devices (or direct connection) Camera body ④ Network card ③ LAN cable ①Lens ② Direct connection Switching hub ⑤ DC IN/trigger IN connection cable ⑥ AC adapter (not supplied) ① Lens ・C-mount lenses with lens mount protrusions of 4 mm or less can be attached.
  • Page 16 AP-3200T-10GE ② Direct connection（or MP-41 tripod adapter plate） When mounting the camera directly to a wall or other device, use screws that match the camera locking screw holes on the camera (M3, depth: 5 mm). Use the supplied screws to attach the tripod adapter plate.

  • Page 17: Step 3: Verifying Camera Operation

    Verifying the Connection between the Camera and PC Verify whether the camera is properly recognized via Control Tool. Connecting the Camera to Control Tool Startup eBUS Player for JAI eBUS Player for eBUS Player for JAI startup screen appears. Device Control — 17 —...
  • Page 18 AP-3200T-10GE eBUS Player for JAI File Tools Help Connection Select / Connect Disconnect IP address MAC address GUID XXXXXXXXXXX Vendor JAI Corporation AP-300T-10GE Model JAI_DEMO Name Acquisition Control Source Mode Play Stop Parameters and Controls Communication control Device control Image stream control Select the camera you want to configure.
  • Page 19 AP-3200T-10GE Check that the settings of the selected camera are displayed. eBUS Player for JAI File Tools Help Connection Disconnect Select / Connect IP address MAC address GUID XXXXXXXXXXX Vendor JAI Corporation AP-300T-10GE Model Name JAI_DEMO Acquisition Control Source Mode...

  • Page 20: Step 5 Configuring Basic Settings For The Camera

    AP-3200T-10GE Step 5 Configuring Basic Settings for the Camera This section explains how to change settings by describing the procedure for changing the output format as an example. Set the output format Set the size, position, and pixel format of the image to be captured.

  • Page 21: Step 6: Adjusting The Image Quality

    Display the camera image and adjust the image quality. Displaying the Image Display the image captured by the camera. When you push [Play] button, the camera image appears in right area. eBUS Player for JAI File Tools Help Connection Disconnect...
  • Page 22 AP-3200T-10GE Adjusting the Gain To adjust the image quality The Visibility must be changed from [Beginner] to [Guru]. Adjust the sensitivity via the analog gain (i.e., master gain). For details on gain control, see “Gain Control” in the “Main Functions” section.
  • Page 23 Adjusting the Black Level Expand [AnalogControl], and select the black level you want to configure in [BlackLevelSelector]. [DigitalAll] (master black), [DigitalRed] (digital R), and [DigitalBlue] (digital B) can be configured. Specify the adjustment value in [BlackLevel]. Analog Control — 23 —...

  • Page 24: Step 7: Saving The Settings

    AP-3200T-10GE Step 7: Saving the Settings The setting values configured in the tool will be deleted when the camera is turned off. By saving current setting values to user memory, you can load and recall them whenever necessary. You can save up to three sets of user settings in the camera. (User Set1 to 3) Memory(Flash) 一時メモリ...

  • Page 25: Main Functions

    AP-3200T-10GE Main Functions Acquisition Control This camera has three Acquisition modes (SingleFrame, MultFrame, Continuous). Use [AcquisitionControl] settings to perform operations and settings for image capture. SingleFrame When the [AcquisitionStart] command is executed, one frame of image is captured. Acquisition Acquisition...

  • Page 26: Exposure Mode

    AP-3200T-10GE Exposure Mode This camera has three Exposure modes (Off, Timed, TriggerWidth). Use [AcquisitionControl] settings to perform operations and settings for exposure. ExposureMode = Off Exposure control is not performed (free-running operation). The exposure time is the longest possible time within the operating conditions such as the frame rate.

  • Page 27: Trigger Control

    AP-3200T-10GE Trigger Control The camera allows the following controls to be performed via external trigger signals. TriggerSelector Description AcquisitionStart Start image acquisition in response to the external trigger signal input. AcquisitionEnd Stop image acquisition in response to the external trigger signal input.

  • Page 28: Gpio (Digital Input/Output Settings)

    AP-3200T-10GE GPIO (Digital Input/Output Setting) The unit can input/output the following signals to and from external input/output connectors. Line1: TTL Out 1 DC IN / TRIG IN connector (12-pin round) External Line2: Opto Out 1 DC IN / TRIG IN connector (12-pin round)
  • Page 29 AP-3200T-10GE For digital output, set the output source signal using [LineSource]. Set the source signal in the same way for NAND Logic (Nand0In1, Nand0In2, Nand1In1, NandIn2) and TimestampReset. The table below shows the source signals that can be set. LineSelector ✓...

  • Page 30: Timing Chart

    AP-3200T-10GE Timing chart ■ [ExposureMode] = [Timed] • [FrameStartTrigger] = [On], [TriggerOverlap] = [Readout] A (Frame Period) Next trigger Input enabled Next trigger disabled Trigger CMOS Exposure ExposureActive Exposure Time Readout Period From Trigger start edge to PixelFormat Frame Period [A] (usec)
  • Page 31 AP-3200T-10GE ■ [ExposureMode] = [Timed] • [FrameStartTrigger] = [On], [ExposureModeOption] = [RCT] A (Frame Period) Next trigger Input enabled Next trigger disabled Trigger CMOS Exposure ExposureActive Exposure Time Readout Period From Trigger start edge to PixelFormat Frame Period [A] (usec)
  • Page 32 AP-3200T-10GE ■ [ExposureMode] = [TriggerWidth] A (Frame Period) Next trigger Input enabled (Next trigger disabled) Trigger CMOS Exposure ExposureActive Exposure Time Readout Period From Exposure Period From Trigger Period From Trigger end end to next Trigger PixelFormat Frame Period [A] (usec)

  • Page 33: Calculate The Maximum Frame Rate (Approximate)

    AP-3200T-10GE Calculate the maximum frame rate (approximate) H_Period Use the foillowing formula to calculate H_Period. H_Period = MAX(Sensor_H_Period, Interface_H_Period, FPGA_H_Period) Among Sensor_H_Period, Interface_H_Period, and FPGA_H_Period, the one with the largest value is H_Period. ■ Sensor_H_Period Sensor_H_Period is a fixed value for each PixelFormat regardless of the ROI size.
  • Page 34 AP-3200T-10GE Maximum frame rate period formula Calculate H_Period (number of clocks) from H_Period. H_Period(number of clocks) = ROUNDUP(H_Period × 74.25, 0) Maximum frame rate = 74.25 × 1000000 ÷ ( H_Period(number of clocks) × (Height + 40) ) Acquisition Control...

  • Page 35: Gain Control

    AP-3200T-10GE Gain Control Gain control can be performed in the following two modes on this camera. ■ Adjusting the Master Gain and Performing Fine Adjustment with R and B (Master Mode) When using this mode, set IndividualGainMode to Off. Adjust the [AnalogAll] (master gain) setting first, and then adjust the [AnalogRed], [DigitalRed], [AnalogBlue], and [DigitalBlue] setting values to perform fine adjustment.
  • Page 36 AP-3200T-10GE ■ Automatic Gain Level Control Set [GainAuto] to [Continuous] to control the gain level automatically. Note When [IndividualGainMode] is set to [On], [GainAuto] will be fixed at [Off]. Analog Control — 36 —...

  • Page 37: White Balance

    AP-3200T-10GE White Balance To adjust the white balance automatically, set [BalanceWhiteAuto] to Once (automatic adjustment only once) or Continuous (automatic adjustment always). The metering area can be limited for automatic adjustment. To limit the metering area, specify each of the 16 areas with [AWBAreaSelector] and set [AWBAreaEnable] to True or False.

  • Page 38: Alc (Automatic Level Control) Function

    AP-3200T-10GE ALC (Automatic Level Control) Function The ALC (automatic level control) function combines the automatic gain control (AGC/Auto Gain Control) and automatic exposure control (ASC/Auto Shutter Control) functions, and is capable of handling various changes in brightness.The function operates as follows in response to changes in brightness.

  • Page 39: Gamma Function

    AP-3200T-10GE Gamma Function The gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing.

  • Page 40: Lut (Lookup Table)

    AP-3200T-10GE LUT (Lookup Table) The LUT function is used to generate a non-linear mapping between signal values captured on the sensor and those that are output from the camera. You can specify the output curve using 257 setting points (indexes).

  • Page 41: Blemish Compensation

    AP-3200T-10GE BlemishCompensation 画素欠陥補正機能（BlemishCompensation） Multiple defective pixels that are not adjacent to each other can occur on conventional CMOS sensor cameras. This camera features a function that interpolates defective pixels using the surrounding pixels. Up to 1736 pixels can be corrected for each of the three sensors. Pixel interpolation can be performed via automatic detection or point-by-point manual settings.

  • Page 42: Shading Correction

    AP-3200T-10GE Shading Correction The ShadingCorrection function corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V).

  • Page 43: Binning Function

    AP-3200T-10GE ■ ColorShading R-channel and B-channel properties are adjusted to using the G-channel shading properties as a reference. Post-correction Pre-correction Caution • For FlatShading and ColorShading, the maximum amount of correction gain for all pixels is limited to 8 times the amount of gain before correction. (The amount of gain cannot be increased to more than 8 times the amount of gain from before correction.)

  • Page 44: Roi Function (Single Roi)

    AP-3200T-10GE ROI Function (Single ROI) The ROI (region of interest) function allows you to output images by specifying the areas to scan. Specify the area to scan by specifying width, height, and horizontal/vertical offset values under [ImageFormatControl]. For details on how to configure the settings, see “Configuring the Output Format”.

  • Page 45: Roi Function (Multi Roi)

    AP-3200T-10GE ROI Function (Multi ROI) In the Multi ROI mode, you can specify up to 64 scanning areas for a single-frame image. The areas cannot overlap. The Multi ROI mode can be used only when both the Sequencer mode and the Shading mode are off.

  • Page 46: Sequencer Function

    AP-3200T-10GE Sequencer Function The Sequencer function lets you define up to 128 index combinations of exposure time, gain, ROI, and other settings which can be stepped through each time a trigger is received.This is particularly useful for quickly capturing multiple exposures of objects under inspection to adjust for areas or components with significantly different levels of reflectance.
  • Page 47 AP-3200T-10GE Sample TriggerSequencer mode operation User-defined Indexes (up to 128) Triggers/ Image Frames Specify "1" in [SequencerSetStart], and start TriggerSequencer mode with index 1. Capture a 2-frame image with the first and second triggers. For the next index, configure index 3 specified in [SequencerSetNext], and capture an image with the number of frames (number of triggers) specified in [SequencerFrameNumber].

  • Page 48: Color Space Conversion

    Default Caution If you set the color space to XYZ or HSI, eBUS Player for JAI will not display the images captured by the camera properly. To display them properly, XYZ- or HSI-compatible image processing must be performed on the computer side.

  • Page 49: Edge Enhancer, Color Enhancer

    AP-3200T-10GE Edge Enhancer, Color Enhancer This camera is equipped with an edge enhancer function for enhancing the contrast of lines or edges within images and a color enhancer function for enhancing specified colors. Edge enhancer function The edge enhancer function is enabled when EnhancerEnable[Edge] is set to True.

  • Page 50: Chunk Data Function

    AP-3200T-10GE Chunk Data Function The Chunk Data function adds camera configuration information to the image data that is output from the camera. Embedding camera configuration information in the image data allows you to use the serial number of the camera as a search key and find specific image data from among large volumes of image data.

  • Page 51: Counter And Timer Control Function

    AP-3200T-10GE Counter And Timer Control Function This camera supports only the counter function. The counter function counts up change points in the camera’s internal signals using the camera’s internal counter, and reads that information from the host side. This function is useful for verifying error conditions via the count value using internal camera operations.
  • Page 52 AP-3200T-10GE ■ Internal camera blocks Counter0 Counter Event detection FrameTrigger At event occurrence or count up Counter1 Counter Event detection ExposureStart At event occurrence or count up Counter2 Counter Event detection SensorReadOut At event occurrence or count up Counter3 Counter...

  • Page 53: Pulse Generator

    AP-3200T-10GE Pulse Generator By using this function, any signal can be generated inside the camera. The following is an example of signal generation. Settings PulseGeneratorStartPoint = 2 PulseGeneratorEndPoint = 6 PulseGeneratorLength = 10 PulseGeneratorPulseWidth = 4 PulseGeneratorClearSyncMode = AsyncMode StartPoint...

  • Page 54: Setting List

    AP-3200T-10GE Setting List This camera complies with GenICam. Each setting item name conforms to GenICam SFNC (Standard Features Naming Convention). (There are some JAI-specific setting items). Each setting item is an integer type (IInteger), a real type (IFloat), an element...

  • Page 55: Feature Properties

    AP-3200T-10GE Feature Properties Item Setting range Default value Description DeviceControl Display/configure information related to the device. DeviceVendorName ー "JAI Corporation" Display the manufacturer name. DeviceModelName ー AP-3200T-10GE Display the model name. DeviceManufacturerInfo ー See the possibilities Display the manufacturer information.
  • Page 56 AP-3200T-10GE Item Setting range Default value Description TransportLayerControl Display information on transport layer control. PayloadSize Display the payload size. GigEVision SingleLink SingleLink Display the status for LinkConfiguration. GevCurrentPhysicalLinkConfigration (fixed at SingleLink)。 GevSupportedOptionSelector Select the supported options for GigEVision. [Setting range]...
  • Page 57 AP-3200T-10GE Item Setting range Default value Description GevStreamChannelSelector 0(fixed) Selects the stream channel to control. GevSCPHostPort Controls the port to which the device must send messages. Setting this value to 0 closes the message channel. GevSCPSFireTestPacket True, False False Sends a test packet. When this feature is set, the device will fire one test packet.
  • Page 58 AP-3200T-10GE Item Setting range Default value Description MultiROIControl Configure settings for Multi ROI. MultiRoiMode 0: Off, Enable/disable Multi Roi. 1: On MultiRoiIndex 0 〜 7 0 〜 7 Select the index for the Multi Roi mode. MultiRoiWidth ー ー Set the width for the selected Multi Roi index.
  • Page 59 AP-3200T-10GE Item Setting range Default value Description DigitalIOcontrol Configure settings for digital input/output. LineSelector ー Line2 Select the input/output to configure. [Setting range] 20: Line1, 21: Line2, 22: Line3, 23: Line4, 24: Line5 25: Line6, 27: Line8, 29: Line10 53: Nand0In1, 54: Nand0In2, 55: Nand1In1, 56: Nand1In2...
  • Page 60 AP-3200T-10GE Item Setting range Default value Description PulseGenerator Configure pulse generator settings. ClockPreScaler 1〜4096 Set the division value for the prescaler (12 bit) using PixelClock as the base clock. PulseGeneratorClock (MHz) 0.0181274〜74.25 0.45 Set the clock used for the pulse generator.
  • Page 61 AP-3200T-10GE Item Setting range Default value Description AnalogControl Configure analog control settings. IndividualGainMode Off, On In IndividualGainMode, RGB can be configured individually for the entire gain adjustment range of the sensor. GainSelector ー AnalogAll Select the gain to configure. [Setting range]...
  • Page 62 AP-3200T-10GE Item Setting range Default value Description LUTControl Configure LUT settings. LUTSelector Red, Green, Blue Select the LUT channel to control. LUTIndex 0〜256 Set the LUT index table number. LUTValue 0〜4095 Gamma≒1.0 Set the LUT value. AutoLevelControl Configure AutoLevelControl. ALCControlReference...
  • Page 63 1: Succeeded (Shading calibration was Succeeded.) 2: Error1 (Image was too bright.) 3: Error2 (Image was too dark.) 4: Error3 (Could not calibrated.) 5: Error4 (Correction Limit.) BlemishControl Configure settings for JAI white blemish correction. BlemishEnable True, False True Enable/disable blemish correction. BlemishDetect ー...
  • Page 64 AP-3200T-10GE Item Setting range Default value Description SequencerControl Configure sequencer settings. SequencerMode Off, On Enable/disable [SequencerMode]. SequencerModeSelect 0:TriggerSequencerMode, TriggerSequencerMode Select the sequencer mode. 1:CommandSequencerMode SequencerSetSelector 1〜128 Select the index number to configure. SequencerWidth 16〜2064 step 16 2064 Set the width of the selected SequencerIndex.
  • Page 65 AP-3200T-10GE Item Setting range Default value Description EventControl EventSelector ー ー Select the event to send the event message. [Setting range] ExposureRedStart, ExposureRedEnd, ExposureGreenStart, ExposureGreenEnd ExposureBlueStart, ExposureBlueEnd Line1RisingEdge, Line1FallingEdge, Line2RisingEdge, Line2FallingEdge Line3RisingEdge, Line3FallingEdge, Line4RisingEdge, Line4FallingEdge Line5RisingEdge, Line5FallingEdge, Line6RisingEdge, Line6FallingEdge Line8RisingEdge, Line8FallingEdge, Line10RisingEdge, Line10FallingEdge...
  • Page 66 AP-3200T-10GE Item Setting range Default value Description EventLine6FallingEdgeData ー ー ー ー Display the EventID(0x931D). EventLine6FallingEdge ー ー Displays the Timestamp value when an event occurs. EventLine6FallingEdgeTimestamp ー ー Displays the FrameID value when an event occurs. EventLine6FallingEdgeFrameID EventLine8RisingEdgeData ー...

  • Page 67: Miscellaneous

    AP-3200T-10GE Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. ■ Power supply and connections Problem Cause and solution The POWER/TRIG LED remains lit amber and Camera initialization may not be complete does not turn green, even after power is due to lack of a network connection.

  • Page 68: Specifications

    AP-3200T-10GE Specifications Item AP-3200T-10GE Scanning system Progressive scan Synchronization Internal 10GBase-T, 5GBase-T, 2.5GBase-T, 1000Base-T Interface (GigE Vision 2.0), IEEE 802.3af Image sensor CMOS x 3 image size (effective image) 1/1.8-inch 7.12mm(H) x 5.33mm(V) : 8.89mm(diagonal) Pixel size 3.45 μm (H) x 3.45μm(V)
  • Page 69 AP-3200T-10GE MasterMode AnalogAll : 0dB 〜 18dB AnalogRed : -6.5dB 〜 12dB AnalogBlue : -6.5dB 〜 12dB DigitalRed : -0.915dB 〜 0.828dB DigitalBlue : -0.915dB 〜 0.828dB Gain Manual adjustment range IndividualMode adjustment AnalogAll : 0dB 〜 36.13dB AnalogRed : 0dB 〜 36.13dB AnalogBlue : 0dB 〜...

  • Page 70: Maximum Frame Rate Reference

    AP-3200T-10GE Maximum Frame Rate Reference [When the maximum packet length is 1476 bytes and the packet delay is 0 ns] [Theoretical value] Full pixels PixelFormat Framerate 10Gbps 2064 x 1544 RGB8 106.29fps 2064 x 1544 RGB10V1Packed, RGB10p32 79.85fps 2064 x 1544 RGB12V1Packed 70.91fps...

  • Page 71: Dimensions

    AP-3200T-10GE Dimensions Dimensional tolerance: ± 0.3mm Unit: mm — 71 —...

  • Page 72: Comparison Of The Decibel Display And Multiplier Display

    AP-3200T-10GE Comparison of the Decibel Display and Multiplier Display Decibels [db] Multipliers [x] Remarks 0.447 0.501 0.562 0.631 0.708 0.794 0.891 1.122 1.259 1.413 1.585 1.778 1.995 2.239 2.512 2.818 3.162 3.548 3.981 4.467 5.012 5.623 6.31 7.079 7.943 8.913 11.22...

  • Page 73: User's Record

    Camera type: AP-3200T-10GE Revision: …………… Serial No: …………… Firmware version: …………… For camera revision history, please contact your local JAI distributor. Trademarks • Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.

  • Page 74: Index

    AP-3200T-10GE Index 12-pin round Lens Lens mount Acquisition Lookup Table Adjusting the Black Level Adjusting the Gain Parts Identification Binning Function POWER/TRIG LED Blemish Compensation Regional Scanning Function Camera locking screw holes RJ-45 connector Chunk Data Function C-mount Connecting Devices...

  • Page 75: Revision History

    AP-3200T-10GE Revision history Revision Date Changes Sep.2020 First version — 75 —...
