Page 1 DOC. N° 1SDH002203A1002 E-kit User Manual...
Page 3: Table Of Contents
Power-up ................17 Firmware upgrade ............. 17 7 - E-kit user interface .............. 18 User level ................18 Usage session ..............18 Access to the web interface ..........18 Homepage ................. 18 3 | © 2022 ABB | - 1SDH002203A1002...
Page 5: General Information
ABB and its affiliates are not liable for damages and/or losses related to such security breaches, unauthorized accesses, interference, intrusion, loss and/or theft of data or information.
Page 6: Overview Of E-Kit
2 - Overview of E-kit How E-kit works E-kit is an ABB Electrification solution developed from the ABB Motion AC500 product which provides an application layer enabling ABB devices and third-party devices to be integrated. Using E-kit, a device can be integrated by setting a model allowing E-kit to interpret incoming data from that device correctly.
Page 7: Templates Supported By E-Kit
The SD card provided in E-kit enables the following functions to be performed: • Update the software of E-kit • Backup the configuration created • Update the catalog of templates and models supported by E-kit 7 | © 2022 ABB | - 1SDH002203A1002 Overview of E-kit...
Page 8: Power Supply
Positive pin of supply voltage +24 VDC Positive pin of supply voltage Negative pin of supply voltage Negative pin of supply voltage Terminal block Terminal block Ground connection removed plugged-in 8 | © 2022 ABB | - 1SDH002203A1002 Power supply...
Page 9: Rs-485 Serial Communication Interface (Com1 Port)
All “A” terminals must be connected to each other and all “B” terminals must be connected to each other, respectively. Note: Certain ABB devices, such as electrical metering instruments B21, B23, B24, are an exception. For this reason, terminal M+ will now be indicated as the positive terminal while terminal M- will be indicated as the negative terminal.
Page 10: Connection Among Devices
The main cable can be up to 700 m in length. This distance does not include branches (which, however, must be short). Up to 15 devices (besides E-kit) can be connected to a main cable. maximum number of devices 10 | © 2022 ABB | - 1SDH002203A1002 RS-485 serial communication interface (COM1 port)
Page 11: Type Of Cable Required
Installation of termination resistors can only be omitted if the main cable is less than 50 m in length. Note: there is no internal termination resistance in ABB SACE new Emax, X1 air and Tmax molded-case devices and in the majority of ABB devices.
Page 12 Slave at the end of the serial line, termination with 120 Ω resistors The following photo illustrates the COM1 terminal box of E-kit when it is inside the serial line. 12 | © 2022 ABB | - 1SDH002203A1002 RS-485 serial communication interface (COM1 port)
Page 13: Communication Parameters
The maximum length of a trunk, i.e. the maximum distance between two network components, is limited to 80 m due to the electrical properties of the cable. between devices 13 | © 2022 ABB | - 1SDH002203A1002 Ethernet communication interface (ports ETH1 and ETH2)
Page 14: Setting Of Static
The changes will be implemented once OK has been pressed for the second time. Shut down the CPU and then reboot to make the changes effective 14 | © 2022 ABB | - 1SDH002203A1002 Ethernet communication interface (ports ETH1 and ETH2)
Page 15: Setting Of Static Ip Address With Dhcp
The procedure for configuring the IP address of a PC with Windows 10 Operating System is given below. Right-click on the Start icon at the bottom left and select Settings. Having accessed the Settings window, click on Network & Internet. 15 | © 2022 ABB | - 1SDH002203A1002 Ethernet communication interface (ports ETH1 and ETH2)
Page 16 Select Ethernet from the window on the left of the menu and click on Change Adapter Option. Right-click on the connected Ethernet port and select Properties. Select Internet Protocol Version 4 (TCP/IPv4) and click on Properties. 16 | © 2022 ABB | - 1SDH002203A1002 Ethernet communication interface (ports ETH1 and ETH2)
Page 17: Commissioning Of E-Kit
Faulty operation of web interface Send an email to the Support Center ( ). The Support Center will provide global operations digital help and guide you through the E-kit firmware upgrade. 17 | © 2022 ABB | - 1SDH002203A1002 Commissioning of E-kit...
Page 18: E-Kit User Interface
The button at the bottom of the menu allows the Admin user to access the database for model management. 18 | © 2022 ABB | - 1SDH002203A1002 E-kit user interface...
Page 19: Web Interface Configuration
Click on Save to save the changes locally: the icon in the button becomes . Click on Cancel to cancel saving. 19 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 20: Copy Configuration
Each device comprises the following parts, indicated in the figure below: Index of device, i.e. the order in which the devices were inserted; Name of device; Template of device; Communication status (red: not connected, green: connected, white: not used); 20 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 21 Refresh time (only different from 0 if the device is connected), indicating how often it is interrogated. Click on the Configuration button at the bottom of the focus. This will access the window below, where you can configure the selected device in the following way: 21 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 22 13. If the device is connected in Modbus RTU network, the UnitID, IP Address and TCP Port properties are replaced by Slave, with default value 1, enabling the address of the device to be entered, as shown in the next figure. 22 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 23 To change a value in the User type channel, click on the corresponding value. This will access a window where the required value can be entered. Click on Update to change the value, otherwise click on Cancel to quit without performing actions. 23 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 24: Model Management
Address Base: select the Base Address type of the device whose model you want to create. The required channels can be selected in the right part and configured by browsing among the pages using arrows < and > . 24 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 25 12. Normalization denominator: scales the value by dividing it by the indicated number; 13. Normalization offset: adds an offset to the data item. The value set can be both positive and negative 25 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 26 Click on Save to save the changes to the model. The word Saved appears alongside the button to notify that saving has taken place. After this, press Close to close the window. 26 | © 2022 ABB | - 1SDH002203A1002 Web interface configuration...
Page 27: Use Of The Web Interface
You can browse among the pages of the available devices and among the pages of the channels of the selected device using arrows < and >. 27 | © 2022 ABB | - 1SDH002203A1002 Use of the Web interface...
Page 28: Integration With Ekip Connect 3
• Slave address 1 • Communication protocol: Modbus TCP • IP address: address of E-kit set during the configuration process (see Setting of static IP address (recommended) 28 | © 2022 ABB | - 1SDH002203A1002 Integration with Ekip Connect 3...
Page 29 ABB | E-kit Click on OK. If the procedure has been performed correctly, the web interface of E-kit will open in Ekip Connect. 29 | © 2022 ABB | - 1SDH002203A1002 Integration with Ekip Connect 3...
Page 30: Technical Specifications
ABB | E-kit 11 - Technical specifications Dimensions The dimensions of E-kit are given below in millimeters. The dimensions in inches are between brackets. 30 | © 2022 ABB | - 1SDH002203A1002 Technical specifications...
