- Page 1 CASTLES TECHNOLOGY S1E2 POS Terminal Book 2 User Manual S1E2 Confidential Version 1.0 Sep. 2022 CRT-S1-15-02-V1.0-CE-FCC-IC-UL-CB-cUL Castles Technology Co., Ltd. 6F, No. 207-5, Sec. 3, Beixin Rd., Xindian District, New Taipei City 23143, Taiwan R.O.C. http://www.castech.com.tw...
- Page 2 Castles Technology Co., Ltd. All trademarks mentioned are proprietary to their respective owners.
- Page 3 Revision History Version Date Descriptions Author Sep.12.2022 Initial creation. Dustin Castles Technology Co., Ltd. All Right Reserved. Pg. 3...
-
Page 4: Table Of Contents
Insert GSM Micro SIM Card ................12 2.5. Insert Micro SD card ..................13 Appendix ........................14 3.1. FCC ........................14 3.2. IC ........................16 3.3. UL / IEC 62368-1 ....................17 Castles Technology Co., Ltd. All Right Reserved. Pg. 4... -
Page 5: Regulatory Instruction Of Usage
● Please operate the unit carefully as it is a precision instrument. Do not apply impact, drop or heavy objects on top of the unit. ● Do not attach dust, oil, etc. to a part of the power terminal. Also, please do not scratch. Castles Technology Co., Ltd. All Right Reserved. Pg. 5... -
Page 6: Hardware Setup
2. Hardware Setup 2.1. Parts of the Terminal Front 1. Contactless Card Landing Zone 2. LCD Display (5”) Castles Technology Co., Ltd. All Right Reserved. Pg. 6... - Page 7 Rechargeable Battery 3. Product Label 4. Rechargeable Battery Cover 5. Rear Camera 6. Photo-Flash 7. Speaker 8. SAM Slots 1-2 9. GSM SIM Card Slots 1-2 10. Micro SD Card Slot Castles Technology Co., Ltd. All Right Reserved. Pg. 7...
- Page 8 11. Barcode Scanner Bottom 12. Smart Card Reader 13. Magnetic Stripe Reader Castles Technology Co., Ltd. All Right Reserved. Pg. 8...
- Page 9 Green Light: External power source connecting and battery is full. Red Light: Battery charging function activated 18. Microphone 19. Charger Pin 20. Magnetic Stripe Reader 21. Barcode Scan Button 22. Power Button 23. Contactless LED Indicator Castles Technology Co., Ltd. All Right Reserved. Pg. 9...
-
Page 10: Insert Battery
Step 3: Reverse the operation of step 1 to install the battery cover. Note 1: Please confirm the battery is installed before power on the terminal. Note 2: Highest specified charging temperature: 45±3°C; Lowest specified charging temperature: 0±3°C. Castles Technology Co., Ltd. All Right Reserved. Pg. 10... -
Page 11: Insert Sam Card
Step 2: Insert SAM card into desire slot. SAM 1 & 2: Gold contact is on the upper side of the card and facing down. Step 3: Reverse the operation of step 1 to install the battery cover. Castles Technology Co., Ltd. All Right Reserved. Pg. 11... -
Page 12: Insert Gsm Micro Sim Card
Cut corner is on the upper left side of card and facing down. SIM 2: Cut corner is on the lower right side of card and facing down. Step 3: Reverse the operation of step 1 to install the battery cover. Castles Technology Co., Ltd. All Right Reserved. Pg. 12... -
Page 13: Insert Micro Sd Card
Step 1: Remove battery cover / back cover Step 2: Place Micro SD memory card. Step 3: Reverse the operation of step 1 to install the battery cover. Castles Technology Co., Ltd. All Right Reserved. Pg. 13... -
Page 14: Appendix
Operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. Castles Technology Co., Ltd. All Right Reserved. Pg. 14... - Page 15 Note: The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all WiFi product marketed in US must fixed to US operation channels only. Castles Technology Co., Ltd. All Right Reserved. Pg. 15...
- Page 16 (ii) lorsqu’il y a lieu, les types d’antennes (s’il y en a plusieurs), les numéros de modèle de l’antenne et les pires angles d’inclinaison nécessaires pour rester conforme à l’exigence de la p.i.r.e. applicable au masque d’élévation, énoncée à la section 6.2.2.3, doivent être clairement indiqués. Castles Technology Co., Ltd. All Right Reserved. Pg. 16...
-
Page 17: Ul / Iec 62368-1
Le produit est destiné à être alimenté par un adaptateur secteur répertorié « L.P.S. » (ou "Source d'alimentation limitée") et est évalué à 5 Vdc, 2 A min., Tma = 40 degrés C. ~ END ~ Castles Technology Co., Ltd. All Right Reserved. Pg. 17...
