  • Page 1 Integra Technical Manual Version: Integra-TR S e r v i c e...
  • Page 2 Revision 5 June 2001 Dataradio COR Ltd. designs and manufactures radios and wireless modems to serve a wide variety of data communication needs. Dataradio produces equipment for the fixed data market including SCADA systems for utilities, petrochemical, waste and fresh water management markets and RF boards for OEM applications in the Radio Frequency Data Capture market.
  • Page 3 Integra-TR works with most makes and models of remote terminal units (RTU) and programmable logic controllers (PLC) and their protocols. Configuration settings allow tailoring for a variety of applications.
  • Page 4 800-992-7774. For international sales, phone 1-952-882-5529 or 1-305-829-4030. 1.2.3 FACTORY MUTUAL NI KIT The Integra-TR with the Factory Mutual NI Kit (DRL part number 023-1000-200) is approved as nonincendive for Class I, Groups ABCD, Division 2, hazardous locations by Factory Mutual Research Corporation.
  • Page 5 Figure 1-2 Installation Dimensions Part No. 001-4008-101/102...
  • Page 6 1.2.4 INTEGRA-TR CE Important Notice/Warning on restrictive use in all EU and EFTA member states: This device is a VHF/UHF Radio data transmitter intended for indoor and outdoor use. Operation of this device is subject to end-user licence. The end user is strongly advised to contact the local frequency management authorities to obtain such an end-user licence according to local legislations and frequency allocations.
  • Page 7 CERTIFICATE OF CONFORMITY OF A PRODUCT WITH THE ESSENTIAL REQUIREMENTS OF DIRECTIVE 1999/5/EC, ACCORDING TO THE CONFORMITY ASSESSMENT PROCEDURE REFERRED TO IN ARTICLE 10(5) AND ANNEX IV DESCRIPTION OF THE PRODUCT Manufacturer Dataradio COR Ltd. Address 299 Johnson Avenue, Waseca, Minnesota United States of America Product Brand name...
  • Page 8 Part No. 001-4008-101/102...
  • Page 9 Waseca, MN 56093-0833 USA Phone: 1-800-772-7774; 507-835-8819 Fax: 507-835-6648 Website: www.dataradio.com Declaration of Conformity We, the undersigned, Company Dataradio COR Ltd. Address, City 299 Johnson Avenue, Waseca, Minnesota Country United States of America Phone number +1 507 835 63 48...
  • Page 10 Part No. 001-4008-101/102...
  • Page 11 Model numbers 242-4016-xxx [T-96SR VHF] 242-4018-xxx [Integra TR VHF] 242-4046-xxx [T-96SR UHF] 242-4048-xxx [Integra TR UHF] manufactured by: Company Dataradio COR Ltd. Address, City 299 Johnson Avenue, Waseca, Minnesota Country United States of America Phone number +1 507 835 88 19...
  • Page 12 1.6 IF A PROBLEM ARISES... Component level repair is not recommended on the Integra-TR. DRL’s factory is best equipped to diagnose problems and make component level repairs. Contact Technical Service before returning equipment. A technician may suggest a solution eliminating the need to return equipment.
  • Page 13 The RMA number helps locate your equipment in the repair lab if there is a need to contact Dataradio concerning the equipment. Units sent in for repair will be returned to the customer re-tuned to the current Dataradio Test and Tune Procedure and will conform to all specifications noted in this section Customers are responsible for shipping charges (to Dataradio) for returned units in warranty.
  • Page 14 DRL’s Technical Service. 1.10 NETWORK APPLICATION Integra-TR is suited to a variety of network applications. Its primary design goal was to satisfy the needs of SCADA systems using RTUs or PLCs in either point-to-point or point-to-multipoint service.
  • Page 15 Figure 1-3 Basic Required Connections 1.10.3 COMMON CHARACTERISTICS The networks described in this section share common characteristics: 1. The network speed (2400, 4800, 9600 and 19,200 b/s) must be the same for all stations in a network. 2. Transmission of online diagnostics may be enabled or disabled at any station or stations without affecting their ability to communicate with other stations.
  • Page 16 If a simplex radio network is used (i.e. a single frequency for all stations), we recommend that the master Integra-TR be set to “master”, the remotes to “remote” and all units to remote “selective” data delivery. This will prevent remote stations from hearing each other's responses.
  • Page 17 1.10.6 EXTENDING A LANDLINE (TAIL CIRCUIT) Integra-TR may be used to extend a landline circuit (giving access to difficult locations, etc.). This type of connection is called a “tail circuit” and is shown in Figure 1-9. The tail circuit assembly may be used in any of the network types described in the preceding sections.
  • Page 18 Some point-to-point FDX landline modems or line drivers may require the use of DOX mode and an alternate pinout for DTR, DCD, CTS and RTS as shown in Figure 1-11. DE-9M DE-9M Figure 1-11 DCE Crossover Cable for DOX Mode 1-16 Part No.
  • Page 19 10 - 16 VDC maximum (nominal 13.3) Fuse protected against reverse voltage (internal surface mount 3A fuse: not field replaceable) Rx Current Drain at 13.3 VDC <170 mA (with a terminal connected to Integra-TR COM port) Tx Current Drain at 13.3 VDC <2.0 A <2.5 A...
  • Page 20 Modem / Logic Operation Simplex / half duplex Data Bit Rates 25 kHz channel: 4800 b/s, 9600 b/s, 19200 b/s Modulation Type DRCMSK (Differential Raise-Cosine Minimum Shift Keying) RTS/CTS Delay (RTS mode) 4 ms Addressing 8 bit station address, 1 bit station type (master / remote) Bit Error Rate (BER) 2400 b/s 6.25 kHz 4800 b/s 6.25 kHz...
  • Page 21 2.2.2 Connection to DTE Integra-TR is configured as DCE. Most DTE should be connected using a nine-conductor pin-to-pin “straight” cable. Some RTUs or PLCs may require a special cable to route the signals correctly. See the documentation for your data equipment for further information.
  • Page 22 2.2.4 COM Port Baud rates from 300 to 19200 are supported. Integra-TR's are factory set (default) for 9600 b/s, 8 bits, no parity, and 1 stop bit. Unless required by your operating protocol, we advise restricting port speed to be equal to or less than the RF network speed.
  • Page 23 Figure 2-2 COM and Setup Port Connectors Pin Locations 2.2.4.2 Wire Connection (DOX) Field Programming Software For DTE that lack RTS control, Integra-TR can operate in DOX mode (Data Operated Transmit) with only Transmit Data, Receive Data and Ground (“3-wire interface”).
  • Page 24 2.3.1 Heat Sink The rear panel heat sink is essential for proper operation of the Integra-TR transmitter. The unit must be mounted in a location that permits free air circulation past the heat sink. Cooling will be best if the fins are vertical.
  • Page 25 Field Programming Software. The programming cable (included in the Programming Kit - DRL part number 250-4008-001) is connected from the Setup Port on the Integra-TR to the PC’s COM port configured as the Primary Port. The Port Settings screen of the Field Programming Software is accessed via the Utilities pull-down menu (see Figure 2-7).
  • Page 26 Selecting the Swap Com Ports button moves the Secondary COM Port settings to the Primary COM Port (and moves the Primary COM Port to the Secondary settings). Since Integra-TR programming is done through the Primary COM Port, this is useful when two units are connected to the Primary and Secondary COM Ports.
  • Page 27 See Table 2-4 for Communication Modes configurations. Table 2-4 Communication Modes Mode Description Sync/ESC with No HS Sends data using Sync/byte-stuffing protocol without handshaking. Buffered with No HS Sends buffered data without handshaking. Sync/Esc with RTS/CTS HS Sends data using the Sync/Esc byte-stuffing protocol with RTS/CTS hardware handshaking.
  • Page 28 DCD shows the current state of the DCD (data carrier detect) line. DCD is an input to the PC. Bytes Tx’ed Bytes Transmitted shows the number of bytes (characters) transmitted since the port was last opened. Bytes Rx’ed Bytes Received shows the number of bytes (characters) received since the port was last opened. Framing Errors Framing Errors shows the number of Framing Errors received since the port was last opened.
  • Page 29 (full channel units only) The Integra-TR is capable of selectable network speeds of 2400 and 4800 b/s quarter-channel units, 4800 and 9600 b/s for half-channel units, and 4800, 9600, 19200 b/s for full-channel units. Use the Integra-TR mode whenever feasible.
  • Page 30 2400 b/s for one-quarter channel models of Integra-TR 4800 b/s - selectable for quarter-, half- and full-channel models of Integra-TR and for full-channel models of Integra-T 9600 b/s - selectable for half- and full-channel models of Integra-TR and for full-channel models of...
  • Page 31 Integra-TR Integra-TR Suspend Mode Time Graphic Suspend Mode Time Graphic (not to scale) (not to scale) Suspend mode time Suspend mode time Carrier Carrier Carrier & data - Carrier & data - sensed, no sensed, no continues after continues after...
  • Page 32 Integra-TR Control Signal Timing Integra-TR Control Signal Timing The PLC/RTU/Computer wants to send data The PLC/RTU/Computer wants to send data dropped dropped RTS is raised by the PLC/RTU or computer RTS is raised by the PLC/RTU or computer after last...
  • Page 33 9600 19200 For best results, Dataradio recommends using the same rates for both the COM Port and Network Speeds. DTE Data Format This field selects the format for the COM Port. All units in a network must use the same DTE data format:...
  • Page 34 Analog 1 Analog 1 selects configuration of Pin 3 of the Power/Analog connector (green wire): Input - for use on units not equipped with the cooling option - can be used to monitor an external voltage (0 to 10 volts) Fan Control - regulates an external fan.
  • Page 35 Range This field designates radio frequency range. Channel This field specifies whether the unit is quarter-, full-, or half-channel (6.25, 12.5, or 25 kHz). Transceiver Type This field configures the transmitting and receiving characteristics of the unit according to network application: Tx Only - For use in a full-duplex application to disable receptions on the unit used as the transmitter.
  • Page 36 2.4.4 Apply Station Reset Station Reset tells the Integra-TR to perform a software reset. Performing a Station Reset reacts the same as cycling power to the unit. Figure 2-13 Station Reset Screen 2.4.5 Version Request Selecting Version Request causes the Integra-TR Field Programming Software to display information about the version of the Integra-TR hardware and firmware.
  • Page 37 The parameters can be viewed and/or edited with the Setup Modem/Radio Parameters screens. Note: Dataradio recommends a Read be done anytime an initial connection is made to the Integra-TR Setup Port before accessing the Setup Modem/Radio Parameters screen. This will help avoid writing erroneous parameters to the connected unit.
  • Page 38 Figure 2-17 Offline Link Test Screen Blocks Tx’ed to Remote Blocks Tx’ed to Remote displays the number of data blocks transmitted to the remote unit. Responses from Remote Responses from Remote displays the number of responses heard from the remote unit. Blocks Rx’ed from Remote Blocks Rx’ed from Remote displays the number of data blocks received from the remote unit.
  • Page 39 Block Delay (s) Block Delay (s) allows the user to determine the delay between the transmission of data blocks in 0.25 second intervals (0.00 to 10.00 seconds). Clear Clear allows the user to clear the display (blocks transmitted, responses received, blocks received and link quality).
  • Page 40 Figure 2-18 Offline Diagnostics Screen Diagnostic Select / Selected Remote ID This button allows the user to gather Offline Diagnostics from the selected Remote ID only. Diagnostic Select / Remote ID List This button allows the user to gather Offline Diagnostics from all the IDs in the list of Remote IDs (including the local unit).
  • Page 41 The Rev Pwr check box allows the user to view the reverse power instead of forward power while the local unit is transmitting. Progress The Progress panel shows the progress of the Get Diags request. Tx Mode The Tx Mode combo box allows the user to select different transmit modes when the unit is told to transmit: Tone: the unit will transmit a 1200 Hz tone.
  • Page 42 Figure 2-19 Online Diagnostics The following Online Diagnostics are available: Short ID The Short ID displays the Short ID of the unit transmitting the diagnostics. Temp Temp displays the internal case temperature (in Celsius) of the unit transmitting the diagnostics. Batt Batt displays the supply voltage (in volts) of the unit transmitting the diagnostics.
  • Page 43 RevP RevP displays the approximate measure of reverse (reflected) power of the unit transmitting the diagnostics. This is represented as “Good” if the reverse power is within acceptable limits and is represented as “Bad” if the reverse power is too high. RSSI RSSI displays the Remote RSSI (in dBm) of the unit last transmitting the diagnostics.
  • Page 44 Save The Save button allows the user to save the current Online Diagnostics to a file. 2.4.12 Diagnostic IDs and Alarms The Diagnostics IDs and Alarms screen allows the user to set up the ID List for use with the Offline Link Test, and Offline and Online Diagnostics as well as Alarms for use with Online Diagnostics.
  • Page 45 Low/High Fwd Pwr: Low/High Pwr represents the low and high limits for the forward power diagnostics (in watts). Open The Open button allows the user to restore Diagnostic IDs and Alarms from a previously saved file. Save The Save button allows the user to save the current Diagnostic IDs and Alarms to the current file. Save As The Save As button allows the user to save the current Diagnostic IDs and Alarms to a name different than the current file.
  • Page 46 Temperature Internal temperature (in degrees Celsius) Forward Power Forward power (in watts) Reverse Power Reverse power (in watts) Analog Input 1 Voltage on the External Analog 1 Input from the Power / Analog Connector (in volts) Analog Input 2 Voltage on the External Analog 2 Input from the Power / Analog Connector (in volts) Preamble Good The number of correctly decoded transmissions received in the last 15.
  • Page 47 Rx / Tx Frequency Rx / Tx Frequency shows the current transmit frequencies. Pressing the F5 key will cause the unit to transmit on the programmed transmit frequency. Pressing the F6 key will cause the unit to go to receive on the programmed receive frequency. 2.4.14 ASCII / Hex Terminal Terminal Screens allow the user to select an ASCII or Hexadecimal Terminal Screen for the Primary and Secondary COM Ports (configured in the Port Settings screen - see Section 2.4.3) Data is sent according to...
  • Page 48 Hexadecimal data on the Secondary COM Port (set up in the Port Settings screen). 2.4.15 Program Code The Program Code pull-down menu allows the user to update the Integra-TR firmware (*.bin) with the Program Firmware option. Select Modem Code File allows the user to select the file to program the firmware in the Integra-TR.
  • Page 49 Check timer settings Polling protocols issue a poll and wait a certain time for a response. Integra-TR adds a short amount of delay to each poll and response (typically in the order of 60 to 70 ms). Timer settings that are too short may cause erroneous indication of missed polls, in which case the application may retry or continue to cycle, ignoring the missed station.
  • Page 50 1. 13.3 VDC / 5A regulated power supply. 2. Radio service monitor (IFR1200 or equiv.). 3. Cable with SMA male connector to connect Integra-TR to the service monitor. 4. Integra Field Programming Software kit. 5. A PC with Windows 95 or later operating system to run the Field Programming Software.
  • Page 51 This is particularly likely when field service is done during winter months. 1. Connect the Integra-TR antenna connector to the radio service monitor RF input using a 023-3410-118 or equivalent 50-ohm cable. That input should be able to support at least 5 watts.
  • Page 52 CS operation in the presence of noise, carrier at -120 dBm to the intermodulation, or other sources of radio Integra-TR RF input; interference (e.g., for ambient noise at -100 Raise the service monitor RF The CS LED should come on within 2...
  • Page 53 SECTION 4 NETWORK TROUBLESHOOTING 4.1 TROUBLESHOOTING OVERVIEW The Field Programming Software provides help for the user to find problems on individual units within a network. This program runs (only) from the Integra Setup port. Here is a list of tests that a user (having network communication problems) can try while using this software utility: With user network application's running: Monitor the current network activity by using online diagnostics monitoring feature...
  • Page 54 4.2.2 OFFLINE DIAGNOSTICS Offline diagnostics are used for trouble-shooting and test transmissions to remote units or to a local connected unit. Offline diagnostics are intrusive as they take control of radio channels. User applications must be offline. 4.3 GET STATUS The Get Status function allows the user suspecting network communications problems to gather diagnostics and check tolerances as follows: Local GET Status: gathers diagnostics from the unit connected to the network...
  • Page 55 Field Name Description Tolerance Temp Internal case temperature Operating limits: -30 degrees C to +75 degrees C Selected unit main DC power measured in tenths of a volt Should nominally be close to SWB+ from 6.0 to 18.8 volts, WARNING: Do not exceed 16Vdc. 13.3VDC Application of more than 16 VDC will damage the unit and is Operating limits:...
  • Page 56 Table 4-2 Link Test Display Format Action Format Results Relation Blocks Sent 0-100 Records the total number of blocks transmitted to the remote Blocks Received by remote 0-100 Indicates recorded total number of blocks received by the remote 0.0% to Link Quality to remote Ratio (percentage) of blocks received by the remote compared to B over A...
  • Page 57 Table 4-3 Typical Transmit Deviation Connected to an Integra-TR, Full Channel, Part Number 242-40X8-Y30, Native Compatibility Mode Network Speed Typical Deviation Voltage at Pin 4 when receiving that deviation from other (in b/s) (kHz) units (white wire of analog/power connector) (Vpp) 19200 + 4.0...
  • Page 58 5.1 PARAMETER OVERVIEW The parameters used to configure the Integra-TR units are described in the Field Programming Software help file. Section 5 summarizes the Integra-TR parameter settings and their variations when used within a network. Table 5-1 Normal Factory Settings (Units)
  • Page 59 Table 5-2 Normal Factory Settings (Bases) Full Duplex Base Integra-TR with Redundant Integra-TR Full Duplex Fields other Integra-TR Base with Integra-TR/ Integra-T RX Unit TX Unit Rx Units TX Units Network Settings Compatibility Mode Integra-TR Integra-TR and Integra-T Tx/Rx Mode...
  • Page 60 Section 6 describes the circuit operation of the logic board. This section is intended for use by engineering and service personnel. 6.2 CIRCUIT DESCRIPTION Refer to Figure 6-1 for the block diagram of the Integra-TR Logic Board. 6.2.1 MICROPROCESSOR CIRCUIT The microprocessor contains two Z84015 CMOS low power Intelligent Peripheral Controllers (IPC). Each IPC is an 8-bit microprocessor integrated with CTC, SIO, PIO Clock Generator Controller and Watch Dog Timer.
  • Page 61 CPU SIO-A for further processing and conversion to asynchronous format before delivery to the RS-232 driver and to the user port. 6.2.5 INTEGRA-TR A/D AND DIGIPOT An 8 channel, 8-bit successive approximation A/D converter, type ADC0838 (U4), is interfaced to CPU (U17) and Peripheral (U21).
  • Page 62 6.2.6 WAKE-UP CIRCUIT The wake-up circuit for the Integra-TR consists of a 50 ms monostable circuit that is triggered by the rising edge of a Sleep signal from CPU (U17). The falling edge of this 50 ms pulse (end of pulse) is connected to the NMI of the CPU and will wake up the CPU from Sleep mode after 50 ms.
  • Page 63 E-POT RSSI TX-EN RX-EN SYNTH U11,U12 DIAG 5 VOLTS TEMPERATURE REGULATOR SENSOR SW B+ EMISSION 990302 DESCRIPTION DATE DATARADIO INC. Design Draft DUNG NGUYEN Check Check DATE 990302 INTEGRA-R LOGIC BLOCK DIAGRAM 1 / 1 SIZE LEVEL SHEET 210-03315-000 DOC/N Figure 6-1 Logic Board Block Diagram Part No.
  • Page 64 Section 6 describes the circuit operation of the logic board. This section is intended for use by engineering and service personnel. 6.2 CIRCUIT DESCRIPTION Refer to Figure 6-1 for the block diagram of the Integra-TR Logic Board. 6.2.1 MICROPROCESSOR CIRCUIT The microprocessor contains two Z84015 CMOS low power Intelligent Peripheral Controllers (IPC). Each IPC is an 8-bit microprocessor integrated with CTC, SIO, PIO Clock Generator Controller and Watch Dog Timer.
  • Page 65 CPU SIO-A for further processing and conversion to asynchronous format before delivery to the RS-232 driver and to the user port. 6.2.5 INTEGRA-TR A/D AND DIGIPOT An 8 channel, 8-bit successive approximation A/D converter, type ADC0838 (U4), is interfaced to CPU (U17) and Peripheral (U21).
  • Page 66 6.2.6 WAKE-UP CIRCUIT The wake-up circuit for the Integra-TR consists of a 50 ms monostable circuit that is triggered by the rising edge of a Sleep signal from CPU (U17). The falling edge of this 50 ms pulse (end of pulse) is connected to the NMI of the CPU and will wake up the CPU from Sleep mode after 50 ms.
  • Page 67 E-POT RSSI TX-EN RX-EN SYNTH U11,U12 DIAG 5 VOLTS TEMPERATURE REGULATOR SENSOR SW B+ EMISSION 990302 DESCRIPTION DATE DATARADIO INC. Design Draft DUNG NGUYEN Check Check DATE 990302 INTEGRA-R LOGIC BLOCK DIAGRAM 1 / 1 SIZE LEVEL SHEET 210-03315-000 DOC/N Figure 6-1 Logic Board Block Diagram Part No.
  • Page 68 The Communications Port of Integra-TR. This port is configured as DCE and is designed to connect directly to DTE. Clear to Send. An RS-232 output signal from Integra-TR indicating that it is ready to accept data (used in RTS mode).
