EN
Features
• IP65 water resistant
• Selectable temperature units, °C or °F.
• Data hold function
• Maximum and minimum reading memory
• Stainless steel probe

Specification

Temperature range
Display Accuracy
Display resolution
Automatic power off
Battery
Water resistant rating
Probe size
Ambient temperature

Operation

Power ON/OFF
1. Press [ON-OFF] to turn on.
2. Press and hold for approximately 3 seconds to turn off.

Select Temperature Unit

Press and hold [°C/°F] for 3 seconds and release to change the
temperature unit.
Data Hold
1. Press the [HOLD] button once to retain display reading and the
°C or °F icon will be flashing.
2. Press the button again will release the hold function and return
to normal display.
Maximum/Minimum Reading Memory
1. Press the [MAX/MIN] to display maximum reading.
2. Press the button again to display minimum reading.
3. Press the button once more to display normally.
4. To reset the memory, switch the thermometer off then on.
• *Reset the memory once before taking new readings.
NOTE:
• Clean the probe immediately after each measurement to avoid
cross contamination.
• When replacing battery, ensure all screws are tighten fully,
otherwise it will affect the water resistant function.
• When the display becomes dim replace the battery.
• If there is any abnormal display or operation, switch off the unit
once. All user settings will be reset to ex-factory settings.
2
-50 to 200°C / -58 to 392°F
±1°C between -19.9°C to 119.9°C /
±1.8°F between -3.8°F to 247.8°F
0.1° over a full range
After idle for 10 minutes
1.5 volt, 1 x LR44 or equivalent (included)
IP65
3.5 (Ø) x 122 (L) mm
0°C to 50°C / 32°F to 122°F
