- Page 1 REV 1.6 fsi-solutions.com...
- Page 2 REV 1.6 fsi-solutions.com...
- Page 3 Dear SolarFlex Owner, Congratulations and thank you for your purchase of your new Keystone SolarFlex 600i-L System. We know this will help you on your journey with your new RV. To help get you started, we encourage you to take a few minutes and review the Owner’s Manual thoroughly.
- Page 4 Victron Products Your system includes components from Victron’s “Smart” energy line with Bluetooth connectivity in place of a physical remote display. This includes the SmartShunt, MPPT SmartSolar Controllers, and the Cerbo GX. Your MultiPlus Inverter does not have Bluetooth capabilities. The SmartShunt is monitoring your battery state and tracking how much power is flowing to or from the battery bank, giving you valuable information regarding your State-of-Charge (SOC).
- Page 5 Victron Products Default pincode is 000000. After connecting, the pincode can be changed by going into “Settings” ( ), select “Menu” ( ), “Product Info”, and here you can change the product name and pincode. You will need to “forget” the device from your device list. If you are not sure how to do this, a link will be displayed on your phone or tablet during the process that you can follow to learn how.
- Page 6 Victron Products This system is utilizing the SmartSolar MPPT 100|50 Solar Controller. A Solar Controller charges a lower nominal-voltage battery from a higher nominal voltage PV array. The Solar Controller will charge the battery with a current up to its rated output. The SmartSolar MPPT 100|50 Solar Controller has a maximum of 50 amps output.
- Page 7 Victron Products The SmartShunt is a very valuable piece of equipment in your system. This is the component that is responsible for helping you keep track of just how much energy is left in your battery bank at any given time. This component simply measures battery voltage and current.
- Page 8 Victron Products The settings on the SmartShunt need to be accurate in order to provide proper data regarding the Consumed Amp-hours, State of Charge, and Time Remaining readouts. If you find your readings are off, review your settings to ensure they are correct. All settings are recommended by Dragonfly Energy.
- Page 9 Batteries Your batteries are equipped with built in battery heaters to ensure cold climate does not stop your batteries from charging. The heaters are enabled or disabled by a lighted switch inside of the coach or on the iN-Command Display Commander’s Battery Heat Trigger. When the switch is turned on, the heaters will automatically activate when the internal temperature of the battery drops below approximately 35°F (1.6°C) and will automatically shut off...
- Page 10 Victron Products The 600i-L is equipped with a Victron MultiPlus 3kVA Inverter. The MultiPlus is a powerful true sine wave Inverter and sophisticated battery charger all in one package. When on shore or generator power, the MultiPlus will pass power through to the loads from the source. Any available power that is not used for the loads will be dedicated to battery charging.
- Page 11 Victron Products This all-new communication center allows you to always have control over your system from wherever you are. All of your Victron equipment is reporting to the Cerbo GX which then displays the data on an intuitive interface that is easy to understand and operate.
- Page 12 Victron Products NOTE: CERBO GX NEEDS TO BE POWERED UP AND BE LINKED TO A WI-FI NETWORK WITH INTERNET ACCESS. Go to http://www.victronenergy.com, click on the ‘Login’ tab and select ‘VRM’. Select the ‘Register for Free’ icon below the log in screen. Here, you will need to provide your name, email address, phone number, city, country, and select a new password.
- Page 13 Victron Products Shows the amount of power from the available source (shore or generator) that is being used by the Charger and the loads on the sub-panel. Shows the state the Inverter is currently in. Bulk, Absorb, and Float indicate charging. Inverting indicates no shore or generator power is present and the Inverter is supplying power to the sub-panel.
- Page 14 Victron Products OVERVIEW SCREEN Opening the Remote Console will bring up the system overview screen. This shows your battery information and total combined solar power. On the home screen there is also a moving graphic that represents where the power is coming from and going to in your system.
- Page 15 Victron Products Allows for you to choose who can access your system. This option opens a support tunnel between secure servers at Victron and your Cerbo GX. This is not used and should remain off. This will reboot your Cerbo GX in the event of certain settings changing or a communication glitch.
- Page 16 Victron Products This allows connection to the Remote Console from the VRM or VictronConnect without an additional password. Allows an additional password to be entered before remote console can be activated. Allows remote console to be opened through the VRM portal. Indicates if the Remote Console is currently connected through the VRM portal.
- Page 17 Victron Products Enable or disable Bluetooth communication from the Cerbo GX. Change the pincode needed to connect to the Cerbo GX via Bluetooth. Selecting the SmartShunt will allow you to view some of the more detailed information not seen on the home screen. NOTE: All settings must be changed through the Bluetooth connection for the SmartShunt.
- Page 18 Victron Products Selecting the MultiPlus from the menu opens the details page where infor- mation regarding the Inverter can be found. You can scroll through the list by pressing the down arrow. The only settings that can be changed from the Remote Console are the input current limit, and switch state.
- Page 19 Frequently Asked Questions Why do I see tank sensors on my settings menu? This is a default setting in the Cerbo GX and can be deactivated. Deactivating the tank sensor inputs will remove the unused items from the menu list. To do this: Open the Remote Console.
- Page 20 Frequently Asked Questions When and how should I update the firmware? The Solar Controllers, battery monitor, and Cerbo GX all have Firmware that can be updated. For SmartSolar Controllers and SmartShunt: Open the VictronConnect app on a smartphone or tablet and connect to the device. Select the Settings ( ) in the top right corner.
- Page 21 Frequently Asked Questions How do I expand my system? Your system can be expanded through additional batteries and/or additional solar panels depending on floorplan. When adding batteries, it is important to use the same Manufacturer and Model of battery as the original equip- ment.
- Page 22 System Tips Unit of electric charge; 1A of current flowing for 1 hour. # of minutes a battery can maintain a useful voltage under a 25A discharge. Ah = ((Reserve Capacity x 60) x 25) / 3600 or Ah = Reserve Capacity / 2.4 Inverter prioritizes coach loads.
-
Page 23: Your Generator
System Tips NOTE: If unit has generator prep, follow Option B. OPTION B This takes the place of the 50 amp plug. Your Generator Transfer Switch OPTION A Roof Top AC (with Soft Start) 50 Amp Plug 50 Amp Plug Split Phase Box (With Sub) MultiPlus... - Page 24 Helpful Charts VOLTAGE CAPACITY To accurately use this chart to verify State of Charge readout from the 14.4V 100% SmartShunt, the batteries must be at rest. This means there should be 13.6V 100% no (or very little) current flowing in or out of the batteries. To use this chart, turn off...
- Page 25 Helpful Links REV 1.6 fsi-solutions.com...
- Page 26 Notes REV 1.6 fsi-solutions.com...
