Summary of Contents for Keystone RV Outlast Extreme 1320i-L
- Page 1 REV 1.3 fsi-solutions.com...
- Page 2 REV 1.3 fsi-solutions.com...
- Page 3 Dear Outlast Extreme Owner, Congratulations and thank you for your purchase of your new Keystone Outlast Extreme 1320i-L System. We know this will help you on your journey with your new Fifth Wheel. To help get you started, we encourage you to take a few minutes and review the Owner’s Manual thoroughly.
- Page 4 Victron Products Your system includes components from Victron’s “Smart” energy line with Bluetooth connectivity in place of a physical remote display. This includes the SmartShunt, MPPT SmartSolar Controllers, and place of a physical remote display. This includes the SmartShunt, MPPT SmartSolar Controllers, and the Cerbo-S GX.
- Page 5 Victron Products Default pincode is 000000. After connecting, the pincode can be changed by going into “Settings” ( ), select “Menu” ( ), “Product Info”, and here you can change the product name and pincode. You will need to “forget” the device from your device list. If you are not sure how to do this, a link will be displayed during the process that you can follow to learn how.
- Page 6 Victron Products This system is utilizing the SmartSolar MPPT 100|50 This system is utilizing the SmartSolar MPPT This system is utilizing the SmartSolar MPPT Solar Controllers. A Solar Controller charges a lower Solar Controllers. A Solar Controller charges a lower Solar Controllers.
- Page 7 Victron Products The SmartShunt is a very valuable piece of equipment in your system. This is the component that is responsible for helping you keep track of just how much energy is left in your battery bank at any given time. This component simply measures battery voltage and current.
- Page 8 Victron Products The settings on the SmartShunt need to be accurate in order to provide proper data regarding the Consumed Amp-hours, State of Charge, and Time Remaining readouts. If you find your readings are off, review your settings to ensure they are correct. All settings are recommended by Dragonfly Energy.
- Page 9 Batteries Your batteries are equipped with built in battery heaters to ensure cold climate does not stop your batteries from charging. The heaters are enabled or disabled by a lighted switch inside of the coach or on the iN-Command Display Commander’s Battery Heat trigger. When the switch is turned on, the heaters will automatically activate when the internal temperature of the battery drops below approximately 35°F (1.6°C) and will automatically shut off...
- Page 10 The AC input can be supplied from a split phase 120/240V source, or single phase 120V source. When an AC source is available, the MultiPlus will feed through the AC to its output. The output will therefore mirror the AC input. The inverter/charger connects to the neutral and the preferred input line (L1).
- Page 11 Install a Cerbo GX or other GX product to connect to the internet. Operational data can be stored and displayed on our VRM (Victron Remote Management) website, free of charge. When connected to the internet, systems can be accessed remotely, and settings can be changed. REV 1.3 fsi-solutions.com...
- Page 12 The GX Touch 50 is a display accessory for the Cerbo-S GX. The five inch touch screen display gives an instant overview of your system and allows you to adjust settings. Simply connect the display to the Cerbo-S GX with just one cable. Both GX Touch displays have a waterproof design, a top-mountable setup and are simple to install.
- Page 13 Victron Products This all-new communication center allows you to always have control over your system from wherever you are. All of your Victron equipment is reporting to the Cerbo-S GX which then displays the data on an intuitive interface that is easy to understand and operate.
- Page 14 Victron Products NOTE: CERBO-S GX NEEDS TO BE POWERED UP AND BE LINKED TO A WI-FI NETWORK WITH INTERNET ACCESS. Go to http://www.victronenergy.com, click on the ‘Login’ tab and select ‘VRM’. Select the ‘Register for Free’ icon below the log in screen. Here, you will need to provide your name, email address, phone number, city, country, and select a new password.
- Page 15 Victron Products Shows SOC %, battery bank voltage as read by the SmartShunt, net current flowing into the battery bank, as well as a "Time to go" value. This allows you to gauge how much power is left in your battery bank. Think of it as a fuel gauge for your battery power.
- Page 16 Victron Products OVERVIEW SCREEN Opening the Remote Console will bring up the system overview screen. This shows your battery information and total combined solar power. On the home screen there is also a moving graphic that represents where the power is coming from and going to in your system.
- Page 17 Victron Products Allows for you to choose who can access your system. This option opens a support tunnel between secure servers at Victron and your Cerbo-S GX. This is not used and should remain off. This will reboot your Cerbo-S GX in the event of certain settings changing or a communication glitch.
- Page 18 Victron Products This allows connection to the Remote Console from the VRM or VictronConnect without an additional password. Allows an additional password to be entered before remote console can be activated. Allows remote console to be opened through the VRM portal. Indicates if the Remote Console is currently connected through the VRM portal.
- Page 19 Victron Products Enable or disable Bluetooth communication from the Cerbo-S GX. Change the pincode needed to connect to the Cerbo-S GX via Bluetooth. Selecting the SmartShunt will allow you to view some of the more detailed information not seen on the home screen. NOTE: All settings must be changed through the Bluetooth connection for the SmartShunt.
- Page 20 Frequently Asked Questions How are DC loads measured? This reading is actually a calculation done by the Cerbo, so it is possible for the accuracy to stray. The Cerbo uses information from the connected Victron equipment to determine where power is going. Any power that is not consumed or presented by a piece of Victron equipment that is connected to the Cerbo is accredited to DC loads.
- Page 21 Frequently Asked Questions When and how should I update the firmware? The Solar Controllers, battery monitor, and Cerbo-S GX all have Firmware that can be updated. For SmartSolar Controllers and SmartShunt: Open the VictronConnect app on a smartphone or tablet and connect to the device. Select the Settings ( ) in the top right corner.
- Page 22 Frequently Asked Questions Unit of electric charge; 1A of current flowing for 1 hour. # of minutes a battery can maintain a useful voltage under a 25A discharge. Ah = ((Reserve Capacity x 60) x 25) / 3600 or Ah = Reserve Capacity / 2.4.
- Page 23 System Tips VOLTAGE CAPACITY To accurately use this chart to verify State of Charge readout from the 14.4V 100% SmartShunt, the batteries must be at rest. This means there should be 13.6V 100% no (or very little) current flowing in or out of the batteries. To use this chart, turn off...
- Page 24 Helpful Charts REV 1.3 fsi-solutions.com...
- Page 25 Helpful Links REV 1.3 fsi-solutions.com...
