Page 4
@ Bluetooth Status LED C) " This is a small LED next to the On/Off switch that illuminates to show the current status of the Wake' s Bluetooth connection. • Flashing Slowly and Intermittently: The Wake is on and is not in pairing mode. This is also the indicator for "auto-reconnect' : where the Wake attempts to connect with the last paired Bluetooth device immediately after it...
Page 5
3. Enable Bluetooth on your phone or other device.*Then select"NUU Wake" from the list of discoverable devices. 4. If prompted for a PIN code, enter"OOOO" (4 zeros). It will take between 10-15 seconds for the NUU Wake to pair with your device. When pairing is successful, you will 6)"...
RE-CONNECTION: The NUU Wake will attempt to reconnect with the last paired device when it is powered on. Additionally, if the Wake is moved out of range of the currently-paired device, it will attempt to reconnect when brought back in range.
C][I] The green Battery Status LED � will turn on to show that the Wake' s internal battery is charging. When battery is fully charged, the green Battery Status LED � will turn off. Fully charged, the Wake will have up to 7 hours of playback time.
Page 8
� will be solidly lit while the Wake is charging. The NUU Wake may be used while it is charging. (D 3.5mm AUX-IN - Plug & Play The NUU Wake can connect to any device with a 3.5mm headphone jack. Use the supplied 3.5mm input cable to plug and play, no Bluetooth required.
WATERPROOF & DUSTPROOF PERFORMANCE The NUU Wake is designed to be waterproof and dustproof. Damage caused from misuse, abuse or failure to properly maintain the Wake is not covered by the limited warranty. • The Wake is IP57 certified and will operate at a water depth of 3 feet for up to 30 minutes.
Page 10
Do not open or close the charging port cover with wet or sandy hands or near water. • Make sure the Wake is completely dry before opening the charging port cover. SPE(I Fl(ATIONS Design and specifications are subjected to change without notice.
1. For sound distortion, try lowering the volume on the NUU Wake and/or your phone/device. 2. Move the NUU Wake closer to your phone/device. 3. Connect your phone/device to the NUU Wake via the 3.5mm input cable rather than Bluetooth. Ensure that the cable is fully inserted at both ends.
CONTACT SUPPORT We want to help solve whatever issues you may encounter when using your NUU Wake. If at any time you are not satisfied or have questions, please call or e-mail our dedicated customer support specialists and they will be more than happy to assist you.
Page 13
Read all instructions and warnings before using this product to ensure your personal safety and prevent property damage. • The cover over the charging and USB port MUST be closed in order for the NUU Wake to be waterproof. Press firmly until the cover clicks in order to ensure it is closed and sealed.
Page 14
Obey all signs and displays that require an electrical device or RF radio product to be switched off in designated areas. • Do not place the NUU Wake on high surfaces. During music playback, the product may move or shift, causing it to fall. •...
FCC INFORMATION FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Limited One Year Warranty Information NUU Limited (hereafter referred to as NUU), warrants this product to be free from defects in workmanship and materials, under normal use and conditions, for a period of one (1) year f r om the date of original purchase.
Page 17
DATA, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OFTHIS PRODUCT, EVEN IF NUU OR ITS AUTHORIZED RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPLACEMENT, REPAIR, OR REFUND OF THE PURCHASE PRICE PAID, AT NUU'S DISCRETION.
