Nuu Splash Trail Plus User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Splash Trail Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nuu Splash Trail Plus

Summary of Contents for Nuu Splash Trail Plus

  • Page 1 User Manual...

  • Page 2: Table Of Contents

    Contents: Getting Started ..............Waterproof & Dustproof Performance ......... Specifications ..............Troubleshooting ..............Contact Support ..............Warnings ................FCC Information ..............Warranty Information ............

  • Page 3: Getting Started

    Built-in Microphone Action Button Previous Track Volume Up Next Track Volume Down 3.5mm AUX-IN Micro-USB Charging Port In the Box • 3.5mm to 3.5mm audio cable • NUU Splash Trail Plus • User Manual • Micro USB power charging cable...
  • Page 4 On/Off Switch On: Slide the switch to the left to turn the NUU Splash on. When powered on, the Splash says “Power On!” to indicate this. Off: Slide the switch to the right to turn the NUU Splash off. When powered off.
  • Page 5 • (Green)Flashing Slowly: FM Mode active. • (Green)Flashing Quickly: FM automatic channel scan in progress. • (Green)Solidly Lit: Line-in mode active. Action Button The Action button controls: • Switching Modes • FM auto-scanning • Bluetooth pairing • Play/Pause • Re-connect •...
  • Page 6 2. Wait for the Splash to fully enter Bluetooth mode. You will hear either “Bluetooth connected” if you previously connected a phone to your Splash, OR you will hear “Waiting for connection” if you did not. When you hear one of those phrases, you may go to step #3. 3.
  • Page 7 You will hear “Waiting for connection” as in Step #3 TO PAIR THE SPLASH WITH YOUR BLUETOOTH DEVICE: Enter Bluetooth pairing mode as above Enable Bluetooth on your phone or other device, then select “NUU Splash” from the list of discoverable devices...
  • Page 8 If prompted for a PIN code, enter “0000” (4 zeros) It will take between 10-15 seconds for the Splash to pair with your device. When pairing is successful, you will hear the Splash say “Bluetooth connected!” and the Bluetooth status light will remain steadily lit NOTE: Procedures for activating Bluetooth will vary across devices.
  • Page 9 MUTE (in Line-in mode): While in Line-in mode, clicking the Action button once mutes the sound. Clicking it again un-mutes the sound. Volume Up Volume Down CONTROLLING VOLUME Press or hold the volume keys to adjust the volume. When you reach maximum volume, the Splash will say “Maximum volume!”.
  • Page 10 USB Charging Port Micro- CHARGING THE SPLASH’S BATTERY: For best results, ensure the Splash is fully charged before use. Connect the supplied Micro-USB cable into the charging port , and plug the USB side into your computer or a USB AC adapter (adapter not supplied).
  • Page 11 Built-in Microphone – Making and Taking Calls The Splash may be used as a wireless speakerphone when paired with your phone via Bluetooth. Use your phone to dial as usual, and speak toward the built-in microphone located at the top of the unit. The built-in microphone only works when your phone/device is connected via Bluetooth.
  • Page 12 Previous Track Next Track When you are streaming audio via Bluetooth, you may press the button to skip forward to the next track in your playlist. Press the button to skip back to the previous track in your playlist, or to the beginning of your current track. Listening to the FM Radio: The Splash Trail+ comes with an integrated FM antenna that allows it to pick up FM radio stations.
  • Page 13 5. Use the Previous/Next Track buttons to switch between stations that showed up clearly during the scan in Step #2 EXAMPLE: While scanning for stations, the Splash turns up stations A, B, and C. Starting on station A, pressing the Next Track button would switch the Splash to station B, and pressing it again would then switch it to station C.

  • Page 14: Waterproof & Dustproof Performance

    Ensure the Splash is fully charged before using as a USB speaker. Your computer’s USB port may not be able to supply enough power to charge and play music at the same time. WATERPROOF & DUSTPROOF PERFORMANCE The Splash is designed to be waterproof and dustproof. Damage caused from misuse, abuse or failure to properly maintain the Splash is not covered by the limited warranty.

  • Page 15: Specifications

    1. Firmly seat the inside edge of the cover in place 2. Using both thumbs, press down at both ends of the cover at the same time to ensure it is in place, flush, and sealed • If dirt or sand gets on the power charging port(s), wipe the area clean with a soft cloth that will not leave behind any fibers. •...

  • Page 16: Troubleshooting

    Liquid ingress protection level 7 - Ingress of water in harmful quantity shall not be possible when the enclosure is immersed in water under defined conditions of pressure and time (up to 3 feet of submersion for 30 minutes). Drop Testing - NUU Splash drop testing meets or exceeds 1M drop test standards. TROUBLESHOOTING •...
  • Page 17 3. If your phone/device is connected to a number of other Bluetooth devices, disconnect some of them before pairing with the NUU Splash. 4. Turn Bluetooth off and then on again on your phone/device. If the NUU Splash still won’t pair, remove it from the list of discoverable devices and retry the pairing process from the start.

  • Page 18: Contact Support

    CONTACT SUPPORT We want to help solve whatever issues you may encounter when using your NUU Splash. If at any time you are not satisfied or have questions, please call or e-mail our dedicated customer support specialists and they will be more than happy to assist you.

  • Page 19: Warnings

    Read all instructions and warnings before using this product to ensure your personal safety and prevent property damage. • The cover over the charging and AUX-IN port MUST be closed in order for the NUU Splash to be waterproof. Press firmly on the cover to ensure it is closed and sealed.
  • Page 20 Do not use abrasive cleaners on this product. Wipe it with a soft, water-dampened cloth. • Only charge the battery in accordance with the user manual supplied. Use only the manufacturer supplied charger. Using other chargers could result in electric shock and/or damage the NUU Splash. Using other chargers will void the warranty.
  • Page 21 • Do not charge the NUU Splash in damp areas or in extremely high or low temperatures, as this could result in electric shock. • Do not attempt to replace the product’s built-in battery. Attempts to disassemble the unit or replace internal battery will void the warranty.

  • Page 22: Fcc Information

    FCC INFORMATION FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 23 However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interfer- ence by one or more of the following measures: •...

  • Page 24: Warranty Information

    Limited One Year Warranty Information NUU Limited (hereafter referred to as NUU), warrants this product to be free from defects in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original purchase.
  • Page 25 FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THIS PRODUCT, EVEN IF NUU OR ITS AUTHO- RIZED RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPLACEMENT, REPAIR, OR REFUND OF THE PURCHASE PRICE PAID, AT NUU’S DISCRETION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HERE-IN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
  • Page 26 Made in China © 2015 NUU. ALL RIGHTS RESERVED The Bluetooth word mark and logo are registered trademarks and are owned by the Bluetooth SIG, Inc.
