INSTRUCTION MANUAL
Thank you for purchasing DAYTONA STEERING DAMPER KIT.
Product Features
- Stabilizes steering especially at high speed.
- Prevents the front forks from being twisted during high speed
cornering.
- Bolt-on mount. The kit inclides application specific brackets and
all hardware for easy mounting.
1. Read all instructions before use.
2. After installation, check to see if all the parts are correctly
installed, and see if all the screws are torqued properly.
3. Do not adjust the damper while riding.
4. Periodical inspection of the installed parts is required every
500km (300mile). If anything unusual may be found while
riding, pull over at a safe place to check.
Install
*Install stabilizer on the right side of motorcycle.
Fig.1
Before installing, turn the adjustable knob
counter-clockwise to the end.
Softer
Install FORK BRACKET
1. Attach fork bracket(#2) on the right front fork tube.
Fig.2
Fig.3
LOWER TRIPLE CRAMP
#2. FORK BRACKET SET
M6X20 CAP SCREW
L-FORK TUBE
STEERING DAMPER KIT
for H-D FXST ('00-'07)
LOWER TRIPLE CRAMP
Fig.4
Install FRAME BRACKET
2. Attach frame bracket(#3)
on the right side frame down tube.
FRAME DOUN TUBE
Fig.5
Install DAMPER BODY
3. Install the DAMPER BODY(#1)
with the M8X30 BUTTON HEAD SCREW.
Fig.6
37582 / 80674 : 20210915
25-30 degrees
#2. FORK BRACKET
M6X20 CAP SCREW
#3. FRAME BRACKET SET
#2. FORK BRACKET
#4. M8X25 BUTTON HEAD SCREW
Apply thread locking fluid
#1. DAMPER BODY
PAGE 1 of 2
