ChinaPST HUA6-3P Manual

PM2.5 detector
(temperature and humidity)
HUA6-3P
Before use the device, please read this operation instruction first
Packing list
HU JA6-3P
Charger
When you first open the box,please check the packing list,if accessories
are not complete, please contact retail store
Product introduction
Our Directsense IAQ can monitor the air index and quality in the house.
When the sense detects abnormal situations,
It will send an alarm notification to user's mobile device via
Pride of Life App and turn on Fresh air ventilator automatically.
Notes:
1. Do not use machine in humid environment,it may be influence the service life
of machines.
2. The product is not water-proof design,please keep it way from water.
3. In order to ensure the normal operation of the product, please put the product
on the horizontal plane. The terrain clearance over 20cm.
4. Do not use machine in oily fume(kitchen).
5. Please use original charger.
6. Do not use fuel or paint thinner to clean the product. And do not spray the wine
and pesticide, it will influence the display data.
7. Don't put foreign stuff from the back of the product, don't hinder the air inlet 5cm.
Operation instruction
USB line
HUA6-3P Explanatory Chart
Wifi indicator light
PM2.5
Numerical value
Temperature
(degree celsius)
Metal touch pad
Power
Product specifications
Product name: PM 2 5 detector(temperature and humidity)
Product model: HUA6-3P
Product size:110*98*48mm
Packing size:140*130*81mm
Battery capacity:1400mAh
Input voltage:5V/2A
Charger voltage:5V/2A
USB:MICRO USB,length:1000mm
Net weight:250g
Troubleshooting list
Fault
Unable to boot
Charger not properly connected
Unable to charge
Unable to connect the wifi
APPcan not display product data Router not connect the internet
Unable to connect to server cloud
Humidity index
Air inlet
Wifi button
USB charger
Reason
Solution
No power Use charger To power up
Reset the charger
Recheck the password
Wrong password entered
Reset the router
Disconnect to WIFI
Restart
