Assembly Instructions & User's Manual
for
Member's Mark Colton 4pc Seating
Item Number: 8406501-0440004
Model Number: 980250193
Customer Assistance
: 1-866-563-1732
(spare/replacement parts)
or Email:
customerservice@peakseasoninc.net
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Related Manuals for Member's Mark 980250193
Summary of Contents for Member's Mark 980250193
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Colton 4pc Seating Item Number: 8406501-0440004 Model Number: 980250193 Customer Assistance : 1-866-563-1732 (spare/replacement parts) or Email: customerservice@peakseasoninc.net THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Product Information ..........................4 Components .............................. 4 Hardware ..............................5 Tools ................................5 Step 1 – Table Assembly ........................6 Step 2 –... -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Product Information
Product Information Chair – 38.2” W x 34.2” D x 28.7” H (97.03cm x 86.87cm x 72.9cm) Sofa – 102.4” W x 34.2” D x 28.7” H (260.1cm x 86.89cm x 72.9cm) Table – 56” W x 30” D x 16.95” H (142.24cm x 76.2cm x 43.05cm) Components Component A Component B... -
Page 5: Hardware
Hardware Hex ¼”-20*25mm Bolt (H3) Hex M6*20mm Bolt (H1) Hex M6*35mm Bolt (H2) Qty: 4 Qty: 8 Qty: 8 Flat Washer 1 (H4) Flat Washer 2 (H5) Bolt Cap (H6) Qty: 16 Qty: 4 Qty: 20 Hex M6*45mm Bolt (H7) Plastic Washer (H8) Qty: 12 Qty: 8... -
Page 6: Step 1 - Table Assembly
Step 1 – Table Assembly Place Tabletop (C) on a smooth, flat surface and attach Table Leg 1 (E) and 2 (F) using the ¼”-20*25mm Bolt (H3) and Flat Washer 1 (H4). The holes should all face inwards. Tighten with included Hex Wrench. Do not completely tighten until all components are assembled. -
Page 7: Step 2 - Table Assembly
Step 2 – Table Assembly Attach the Table Shelf (D) to each of the legs using the M6*35mm Bolt (H2) and Flat Washer 2 (H5). Tighten with included Hex Wrench. Do not completely tighten until all components are assembled. After fully assembled and tightened, cover exposed bolts with Bolt Caps (H6) P a g e... -
Page 8: Step 3 - Table Assembly
Step 3 – Table Assembly Turn assembled Table over onto its legs and if needed, adjust the levelers to level the table. P a g e... -
Page 9: Step 4 - Sofa Assembly
Step 4 – Sofa Assembly Lay Sofa on a smooth, flat surface and attach the Sofa Corner Foot (H) putting the M6*20mm Bolt (H7) through Plastic Washer (H8). Tighten with included Hex Wrench. Repeat on all four corners. Do not completely tighten until all components are assembled. -
Page 10: Step 5 - Sofa Assembly
Step 5 – Sofa Assembly Attach the Sofa Center Leg (G) using the M6*20mm Bolt (H1) and Flat Washer 2 (H5). Tighten with included Hex Wrench (H9). Do not completely tighten until all components are assembled. After fully assembled and tightened, cover exposed bolts with Bolt Caps (H6). 10 | P a g e... -
Page 11: Troubleshooting
Troubleshooting Problem Possible Cause Prevention / Solution Tilting / Leaning Surface not level Orient adjustable feet until level Care & Use Instructions Care - Clean once a year with mild soap and water, then rinse - We recommend using outdoor furniture covers or store when not in use - DO NOT use solvents, janitorial cleaners, alcohol-based cleaners, protectants, scouring agents, bleach, gasoline, or ammonia-based cleaners Warranty Information...
