Assembly Instructions & User's Manual
For
Member's Mark
Halstead 5pc Sectional Set
Item Number: xxxxxxxx
Model Number: GC-11428A-5PC
Customer Assistance
: 1-800-691-2824
(spare/replacement parts)
or Email: customerservice@coronadocasuals.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark Halstead GC-11428A-5PC
Summary of Contents for Member's Mark Halstead GC-11428A-5PC
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Halstead 5pc Sectional Set Item Number: xxxxxxxx Model Number: GC-11428A-5PC Customer Assistance : 1-800-691-2824 (spare/replacement parts) or Email: customerservice@coronadocasuals.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
- Page 2 Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................4 Components .............................. 5 Hardware ..............................5 Tools ................................5 Step 1 ................................. 6 Step 2............................7 Furniture Cover..........................7 Warranty Information ..........................
- Page 3 Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
- Page 4 Package Contents Component Description Quantity Component Description Quantity Lounge chair with Connection plate right arm Lounge chair with Allen/Hex Bolt armless M6x25mm Lounge chair with M6 Washer left arm Product Information Product Dimensions： Lounge chair with right arm: 52.75” x 40” x 35.5” (134cm x 101.6cm x 90.17cm) Lounge chair with armless: 47”...
- Page 5 Components Lounge chair with Lounge chair with Lounge chair with right arm armless left arm Qty: 1pc Qty: 2pcs Qty: 1pc Hardware Connection plate Allen/Hex Bolt M6 Washer Qty: 6pcs M6x25mm Qty: 12pcs Qty: 12pcs Tools M6 Allen Wrench Qty: 1pc Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
- Page 6 Step 1 Lounge chair with right arm Lounge chair with Lounge chair with left Connection plate Qty: 1pc armless Qty: 6pcs Qty: 2pcs Qty: 1pc Allen/Hex Bolt M6 Washer M6 Allen Wrench M6x25mm Qty: 12pcs Qty: 1pc Qty: 12pcs Attach the Lounge chair with right arm(A) to Lounge chair with armless (B) using Connection plate (D), bolts(E) and Washer(F) with M6 Allen Wrench(G).
- Page 7 Step 2 If the chair, sofa and table is uneven, you can adjust the feet to make it even. Furniture Cover Component Description Quantity Component Description Quantity Lounge chair with Back cushion right arm Lounge chair with Seat cushion armless Lounge chair with Storage coffee table left arm...
- Page 8 Warranty Information This product component has a 5 year guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number customerservice@coronadocasuals.com 1-800-691-2824 or email us at NOTE: Please consider recycling all applicable packaging material.
