Mainboard Specifications; Form Factor - MSI NetON AP1900 User Manual

NetOn AIO PC

Mainboard Specifications

Processor
- Intel Atom processor N270/ N280 (Optional)
® TM
- Front Side Bus (FSB) 533 MHz (N270)/ 667 MHz (N280)
- Thermal Design Power (TDP) 2.5 W
- Highest Frequency Mode (HFM) 1.6 GHz
- Lowest Frequency Mode (LFM) 800 MHz (N270)/ 1 GHz (N280)
Chipset
- North Bridge: Intel
- South Bridge: Intel
Memory
- 1 DDR2 SO-DIMM slot (Non-ECC)
- Supports DDR2 400/ 533 SDRAM (200-Pin/ 1.8 V)
LAN
- Supports Gigabit Ethernet Controller for PCI Express
by Realtek ® RTL8111C
- Compliant with PCI 2.3
- Supports ACPI Power Management
Audio
- Chip integrated by Realtek
- Compliant with Azalia 1.0 spec

Form Factor

- 430 mm (W ) X 85 mm (H)
945GSE chipset
®
ICH7M chipset
®
® ALC888
2
TM Applications
