(NAVRGB6.0-VI+HONIRC1)
Manual Version: 1.0
NOTICE: We recommend having this installation performed by a certified technician.
All product names, logos, brands, trademarks and registered trademarks are
property of their respective owners.
Installation Manual
Honda Insight 2010-2011
NavTool.com | Call: +1-877-628-8665 | Text: +1-646-933-2100
DESIGNED + MANUFACTURED IN THE
1
Advertisement
Related Manuals for NAV TOOL NAVRGB6.0-VI
Summary of Contents for NAV TOOL NAVRGB6.0-VI
- Page 1 Installation Manual (NAVRGB6.0-VI+HONIRC1) Honda Insight 2010-2011 DESIGNED + MANUFACTURED IN THE Manual Version: 1.0 NOTICE: We recommend having this installation performed by a certified technician. All product names, logos, brands, trademarks and registered trademarks are property of their respective owners.
-
Page 2: Important Warning
WELCOME Precautions IMPORTANT WARNING PLEASE READ BEFORE YOU START THE INSTALLATION Failure to follow these instructions carefully or not installing the interface • Please study these instructions carefully before installing the interface. as described could cause damage to the vehicle or safety systems on the •... -
Page 3: What's In The Box
What’s In The Box? Push Button Interface (Part # NT-PUSH-BTN) (Part # NAVRGB6.0-VI) Vehicle Specific Vehicle Specific Interface Harness Plug and Play Harness Plug and Play Harness (Part # NT-WHNT6) (Part # NT-HONIRC1) (Part # NT-LONG-RIB) NavTool.com | Call: +1-877-628-8665 | Text: +1-646-933-2100... - Page 4 Installation Instructions Step 1: The Honda headunit is equipped with a anti-theft radio code. Prior to start of the installation, get the radio code. With the vehicle’s ignition on and the navigation unit on, press the “OPEN” button. Step 2: With the display open, disconnect and remove the navigation unit from the vehicle and place it on a flat surface, workbench would work the best for this application.
- Page 5 Installation Instructions Step 3: Disconnect the factory ribbon cable by carefully pulling up on the brown release tab. Step 4: Remove three screws on each side of the navigation unit. NavTool.com | Call: +1-877-628-8665 | Text: +1-646-933-2100...
- Page 6 Installation Instructions Step 5: Remove two screws from the plastic trim cover. Step 6: Gently remove the plastic trim cover by pushing on the release tabs on all four sides of the navigation unit. NavTool.com | Call: +1-877-628-8665 | Text: +1-646-933-2100...
- Page 7 Installation Instructions Step 7: Remove the black plastic holder by carefully pinching both sides together. Step 8: Remove the factory flex ribbon cable by gently pulling on the brown release tabs on each side. NavTool.com | Call: +1-877-628-8665 | Text: +1-646-933-2100...
- Page 8 Installation Instructions Step 9: Place the supplied ribbon cable through the black plastic fastener in the same way the factory ribbon cable originally was with the silver pads facing UP. Step 10: Route the supplied small flex ribbon cable thru the back of the radio, under the white connector with silver traces facing DOWN.
- Page 9 Installation Instructions Step 11: Connect the supplied small flex ribbon cable to the main flex cable 9 pin connector with the silver traces facing UP. Connect the main flex ribbon cable to the factory navigation with the silver traces facing UP. Step 12: Carefully fold the main flex ribbon cable into the factory navigation unit.
- Page 10 Installation Instructions Step 13: Assemble the navigation headunit in reverse order of steps, staring from step 6 down to step 1. Step 14: Connect both 10 pin connectors on the Interface harness and the Vehicle Specific Harness LONG-RIB together. Step 15: Cut off the Red (+12 Volts ACC) and Black (Ground) wires off of the 6-pin plug on the interface harness.
- Page 11 Quick Connection Diagram ON 1 Click Switches 1 and 2 UP Click Behind Vehicle’s Screen Do Not Connect Behind Radio (Part # NT-LONG-RIB) NavTool.com | Call: +1-877-628-8665 | Text: +1-646-933-2100...
-
Page 12: Testing And Operation
Testing and Operation Step 1: Turn on the ignition. A green LED will light up on the interface to confirm it has power. Step 2: Press the push button once to turn on and display Video 1. Skip this step if only using reverse camera. (If no video source is connected you will see a “no signal”... - Page 13 User Manual You do not need to use the push button if only a reverse camera was installed The reverse camera will automatically display when the vehicle is placed in Reverse. It will automatically Turn OFF when the vehicle is placed in any other gear and will display the factory screen. To View Video 2 (Front Camera if Installed) If no video source is connected you will see a “No Signal”...
