Directed Electronics 1100X/F-GD Programming Instructions

NOTE TO THE INSTALLER:
THIS GUIDE IS INTENDED FOR USE WITH AN 1100F OR 1100X THAT HAS BEEN UPDATED TO AN 1100GD USING THE DIRECTLINK UPDATER TOOL.
DIRECTLINK UPDATER SOFTWARE IS AVAILABLE AT WWW.DIRECTECHS.COM.
WARNING! READ MANUAL PRIOR TO INSTALLATION
ATTENTION! BEFORE PROCEEDING WITH INSTALLATION,
LOOK FOR INSTALL GUIDE UPDATES AT WWW.DIRECTED.COM.
PRODUCT DESCRIPTION
The 1100X/F-GD interface module is used when installing remote start
products in GM/Daewoo vehicles equipped with a factory immobilizer.
The 1100X/F-GD allows for easy interfacing between the remote start and
the factory immobilizer, while maintaining the integrity of the OEM sys-
tem. The factory transponder-based anti-theft system uses a small elec-
tronic chip hidden in the key to send a code to the vehicle's transceiver
when the ignition is energized. The key must be placed in the ignition
and turned to the RUN position. This energizes a coil surrounding the
key, which in turn energizes the chip, which sends a code to the vehicle. If
the vehicle does not detect the code being sent, the vehicle will start and
then immediately shut off or will just crank, and the anti-theft light will
fl ash. The 1100X/F-GD provides a valid code to the vehicle whenever it is
remote started, but does not affect the immobilizer system during normal
vehicle operation; the immobilizer system remains fully functional.
STEP 1: SELECT INSTALLATION MODE
Complete the wire connections to the vehicle and to the remote starter/alarm
system. Connect all harnesses including the 4-pin power harness. The
module LED will now fl ash green intermittently. (Note: if this condition is
not present, your module may need to be reset to the factory default).
1. Press and release the programming switch to select installation
mode.
Press the switch to alternate between the two modes (only standard
mode should be used).
1 fl ash, pause, I fl ash, pause = (This mode is not used)
2 fl ashes, pause, 2 fl ashes, pause = Standard installation mode
2. Once your installation mode is selected, press and hold the
programming button until the LED displays a solid green light for two
VEHICLE COMPATIBILITY & WIRING CROSS REFERENCE CHART
Year
Chevrolet Aveo (LS) 2004 - 06
Chevrolet Aveo 5 (LS) 2004 - 06
Chevrolet Epica (LS/LT) 2004 - 06
Suzuki Swift 2004 - 06
Suzuki Verona
2004 - 06
Pontiac Wave 2004 - 06
Pontiac Wave 5 2004 - 06
NOTICE:
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of this product, be that either damage to the
vehicle itself or to the installed device. This device must be installed by a certifi ed technician. This guide has been written for properly trained technicians; a certain level of
skill and knowledge is therefore assumed. Please review the Installation Guide carefully before beginning any work.
© 2006 Directed Electronics, All rights reserved.
PROGRAMMING INSTRUCTIONS
DATA
Pin Ignition Pin Data Wire
Wire
1 Pink 6 Black/White
1 Pink 6 Black/White
7 Green/Black
1 Pink 6 Black/White
7 Green/Black
1 Pink 6 Black/White
1 Pink 6 Black/White
seconds. Your installation mode is now programmed. Please proceed
to step 2.
NOTE: Should you wish to change the installation mode, follow the
"Factory Reset" instructions.
STEP 2: PROGRAMMING PROCEDURE
1. Insert the key into vehicle ignition.
2. Turn the ignition to the "ON" position and wait for the module LED
to illuminate green for 2 seconds. (Note : If module LED remains
illuminated red after 10 seconds elapsed time, turn the key to "OFF"
and repeat programming procedure )
3. Programming has been completed.
LED DIAGNOSTICS
1. During STEP 2, if the LED fl ashes red this indicates the wire
connections are incorrect.
2. Once programming has been completed, if the LED fl ashes red,
the module failed to learn correctly. Reset module and repeat the
programming procedure.
3. When the remote starter is engaged, the LED will fl ash green to
indicate the module has been correctly programmed. If the LED
remains illuminated red, the device is incorrectly programmed.
FACTORY RESET
1. Unplug all connectors from the module.
2. Press and hold the programming button while inserting either the
4-PIN standard or 4-PIN optional Directed connector.
3. The LED will begin to fl ash red. Immediately release the
programming button. The LED will turn on solid for 2 seconds to
confi rm module reset.
4. Plug remaining connectors and return to:
STEP 1: SELECT INSTALLATION MODE.
Conn Data Wire Connector Location
D 7 PIN connector at Key Barrel
D 7 PIN connector at Key Barrel
E 15 PIN connector at BCM
D 7 PIN connector at Key Barrel
E 15 PIN connector at BCM
D 7 PIN connector at Key Barrel
D 7 PIN connector at Key Barrel
1
TYPE 1 & 2 INSTALLS
SECURITY THEFT LIGHT
Pin Theft Light Wire Conn Theft Light Connector Location
20 Yellow/Black F 30 PIN connector at BCM
20 F 30 PIN connector at BCM
1100
X/F-GD
Transponder Bypass
GM/DAEWOO
Type
1
1
2
1
2
1
1
N1100X/F-GD 10-06
