Shiratech iCOMOX Installation Manual

Installation
Guide
Infrastructure requirements
NBIOT
Asset requirements:
1. Local SIM card with good Cellular signal strength
2. 220V outlet
3. 220V to USB Adapter
Configuration PC requirements:
Windows 10 operating system
1.
Administrator privileges for installing applications
2.
Cellular SIM requirements:
SIM should be unlocked with no need for PIN code
1.
Details about the APN configuration of the Cellular
2.
Step 01 - NBIOT
Unit configurator:
To prepare the iCOMOX for Internet connection with your local cellular provider you must first configure the
provider APN in the iCOMOX. In the following few steps, we will explain the process of preparing your iCOMOX and
the configuration details in the iCOMOX.
01
iCOMOX Physical preparation
Insert the SIM card into the iCOMOX
into the left position (exactly as
shown in the image below).
POE
Network requirements:
1. PoE (power over ethernet) port connection to
the organization IT network
2. Allow in the organization firewall connection to
xxx.xxx.xxx
02
Connect the iCOMOX
to the PC
on TCP port xxxxx
03
On the iCOMOX (switch)
Move the power switch to the left
(away from the USB port) to turn
the device on.
