- Page 1 CAM1 Quick Start Guide...
- Page 2 CAM1 /Quick Start Guide INDEX Quick Start............................2 Document Revision History ......................9 Page 1 of 9 Rev 1.0 www.shiratech-solutions.com...
-
Page 3: Quick Start
CAM1 /Quick Start Guide Quick Start Please perform the following steps in order to activate the 96Boards CAMERA 1 Mezzanine: Equipment required: • 96Boards Avenger96 from Arrow • Display with HDMI cable • Keyboard + Mouse • P.S to Avenger96 EVB board Test process: 1. - Page 4 CAM1 /Quick Start Guide Page 3 of 9 Rev 1.0 www.shiratech-solutions.com...
- Page 5 CAM1 /Quick Start Guide 3. Connect the 96Boards CAMERA 1 Mezzanine 4. Connect the 12V power supply to Avenger96 board 5. Wait until you will see the main screen: Page 4 of 9 Rev 1.0 www.shiratech-solutions.com...
- Page 6 CAM1 /Quick Start Guide 6. Double clock on Camera icon 7. Wait few seconds until you will get the camera view Page 5 of 9 Rev 1.0 www.shiratech-solutions.com...
- Page 7 CAM1 /Quick Start Guide 8. Second option open camera is by sending the following commands via the Terminal cd /home/root ./v4l2_start.sh Page 6 of 9 Rev 1.0 www.shiratech-solutions.com...
- Page 8 CAM1 /Quick Start Guide The following screen will apreas: Page 7 of 9 Rev 1.0 www.shiratech-solutions.com...
- Page 9 CAM1 /Quick Start Guide And after 10 seconds you will get the following screen: Page 8 of 9 Rev 1.0 www.shiratech-solutions.com...
-
Page 10: Document Revision History
Revision Date Author Status and Description 08/10/2020 Shmuel Asis Initial version 08/10/2020 Ori Makover Template formatting T. +972.3.943.5050 F. +972.3.943.5055 E. info@shiratech-solutions.com 58 Amal St, Kiryat Arie POB 3272, Petach Tikva 4951358, Israel www.shiratech-solutions.com Page 9 of 9 Rev 1.0 www.shiratech-solutions.com...
