Finding the SA-x DSP on the Network
The SA-x DSP uses DHCP and mDNS to receive an IP address and be easily accessed through the local network. Be sure that the SA-x
and your computer are on the same local network and subnet.
Currently the SA-x supports Firefox, Chrome browsers on both Windows and MacOS computers, and Safari on MacOS. We
recommend Firefox for most applications.
Method One – Use Direct Connection using Ethernet without a Network or Router
The simplest option is to connect directly without a router. By default, the SA-x will have an IP Address of 169.254.0.8. Note that you
can only connect one (1) SA-x at a time with this method and your computer must have a wired ethernet connection. A switch (not a
router) can also be used to simplify the connections. Wi-Fi cannot be used.
Connect the SA-x unit to the Ethernet port of your computer by plugging an Ethernet cable from the computer directly to the SA-x
without a router or switch. Turn on the unit and take it out of standby.
Open your web browser and enter the IP Address of
Method Two – mDNS Name
We recommend that you connect one (1) SA-x at a time on the network if you use the mDNS Name method until you have changed
the hostname to a unique name for the installation.
NOTE: All SA-8 and SA-8DSP come factory default set to the Hostname "SA-8"; All SA-3 DSP are "SA-3"; All SA-2 DSP are "SA-2". If
you use the mDNS name with multiple amplifiers of the same model on the same network, you may not control the correct
amplifier. Proceed with caution!
1. Connect the SA-x and computer to a DHCP server. It is important to be on the same subnet.
2. Power on the amplifier and open your web browser
3. System Control Page should be found
Method Three – IP Scan
This is perfect for installations with multiple SA-x on the network, or where the mDNS name is not working.
NOTE: The Hostname may not appear correctly based on your local router settings. In this case, look for the MAC address beginning
with 8C:1F:64:xx:xx:xx.
1. Use
Angry IP Scanner
2. Scan the local network
3. SA-x will appear in the list
4. Enter the IP address that is shown into your browser. In the example below, 192.168.2.227 is the SA-8
SA-X DSP QUICK START GUIDE .DOCX
SA-x DSP Amplifier User Interface
Quick Start Setup Guide for SA-8, SA-8 DSP, SA-2 DSP, SA-3 DSP
169.254.0.8/wizard.html
SA-8 / SA-8 DSP =
SA-3 DSP =
SA-2 DSP =
or
Advanced IP
Scanner, or any other IP scan tool.
to access the setup wizard.
http://SA-8.local
http://SA-3.local
http://SA-2.local
2022-11-22
- 1 -
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wisdom SA-8
Summary of Contents for Wisdom SA-8
- Page 1 NOTE: All SA-8 and SA-8DSP come factory default set to the Hostname “SA-8”; All SA-3 DSP are “SA-3”; All SA-2 DSP are “SA-2”. If you use the mDNS name with multiple amplifiers of the same model on the same network, you may not control the correct amplifier.
- Page 2 System Control Page (landing page) Here you will find the basic information about the amplifier. Click on the Wrench Icon to open the advanced page. The first time you open the advanced page it may take a few seconds to load. NOTE: If this or any other page does not load after 30 seconds, you can try reloading the page.
- Page 3 • Mains Power Recovery: This only applies to the SA-8 and SA-8 DSP - What does the SA-8 do during an unexpected power failure? Power Failure is when the power is lost unexpectedly. The system can only respond if the power is out for more than several minutes, otherwise it assumes the user intended to flip the switch on the back.
- Page 4 Home: This will populate with the routing matrix automatically as the system is programmed. SA-X DSP QUICK START GUIDE .DOCX - 4 - 2022-11-22...
- Page 5 Inputs: Custom names can be entered here for each physical input, or the default names can be used. SA-X DSP QUICK START GUIDE .DOCX - 5 - 2022-11-22...
- Page 6 Channels: These are the “speaker channels” such as Left, Right, Center, etc…This is not where you enter the bi-amp speaker settings. • Name: Custom Name for each channel • Input Sources: What are the physical inputs that will be used for input into the channel Click the + button to add more than one input into a channel.
- Page 7 Speakers: Select the speakers that are connected to the outputs and assign the correct input channels and output connections. • When selecting the Speaker Type, the system will automatically create the correct EQ and Crossover Filters for the speaker • Multiple speakers can use the same Input Channel, but only one speaker can use an output •...
- Page 8 Speaker testing: This page can be used to send test signals to any or all of the outputs. Volume level of the test tone. Have you ever heard full scale pink noise from all speakers? You can do that here, but please don’t!!! SA-X DSP QUICK START GUIDE .DOCX - 8 - 2022-11-22...
- Page 9 • Power Conservation: This only applies to the SA-8 and SA-8 DSP - To meet low power requirements, this is enabled by default. Uncheck this and the Network connection will stay active even when the SA-8 is in standby. This will let the webpage still function regardless of if the SA-8 is On or in Standby.
- Page 10 • “Import Configuration” loads a saved configuration – NOTE: This will also import network settings that may make your amplifier un-reachable over the network. Proceed with caution or call Wisdom Audio before using this!!! Blink Front Panel is only available for the SA-8.
- Page 11 WISDOM and the stylized W are registered trademarks of Wisdom Audio. Wisdom Audio 1572 College Parkway, Suite 164 Carson City, Nevada 89706 USA Telephone: 775.887.8850 Fax: 775.887.8820 www.wisdomaudio.com SA-x DSP Quick Start Guide-1.0 © 2022-11-18 Wisdom Audio, Inc. All rights reserved.
