- Page 1 Operating Instruction QUICK GUIDE 720P 1080P Real time Recording & Full HD Display DVR Before installing and using this product, please read the instruction fully and keep it handy for late use.
- Page 2 Real Time Recording & Full HD Display Features • 4/8/16ch Stand-alone HD Display Real time DVR (1080p) • Independent for each channel resolution, quality and frame rate setting • Camera menu control through UTC (16ch only) • Quick search using up to 256 times normal speed playback feature •...
-
Page 3: Name And Function Of Each Part
Real Time Recording & Full HD Display Name and Function of Each Part 1. FRONT PANEL ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑪ PLAY MULTI MENU ⑫ ⑬ ① ⑭ ⑩ Name Function Numeric buttons Channel selection, Number input ①... -
Page 4: Rear Panel - 4Ch
Real Time Recording & Full HD Display Name and Function of Each Part 3. REAR PANEL - 8CH VIDEO IN SPOT OUT AOUT HD OUT ① ② ③ ④ ⑤ ⑥ ⑦⑧ Name Function VIDEO IN Camera Video Input ① AUDIO OUT Audio Output ②... -
Page 5: Specifications
Real Time Recording & Full HD Display Specifications ITEM 16CH Video Input 4ch BNC 8ch BNC 16ch BNC Video Output Monitor 1ch HD OUTPUT, 1ch Spot (Multi channel), 1ch VGA 1ch HD OUTPUT, 1ch VGA Multitasking Quadplex H.264 Video Compression Resolution 1920x1080, 1024x768, 1280x720, 1280x1024, 1440x900 No. -
Page 6: Setup Menu
Real Time Recording & Full HD Display Setup menu 1-1. Password The default password is 1234 for entering DVR menu and connecting through network. ■ Mouse menu Name Function ① View 1 ① Single screen selection menu ② View 4 ②... - Page 7 Real Time Recording & Full HD Display Setup menu 1-2-1. DDNS Default shows default address based on the MAC address. Hostname can be set by user's preference for domain name. Type the word you want to use, press Check button, you can check the presence of the name in the DDNS server.
- Page 8 Real Time Recording & Full HD Display Setup menu 1-3-3. Bookmark to PLAY Bookmark search function is supported. The list of bookmarks are displayed. It is convenient to use bookmarks on the plaback buckup. 1-3-4. Event Event search is supported. Select start time, end time and channels that you want to search in the event search menu, then event lists that occurred during that time period are displayed.
-
Page 9: Network Monitoring
Real Time Recording & Full HD Display Setup menu 1-6. NETWORK MONITORING 1-6-1. CMS Network monitoring program is provided. It supports Windows PC and Mac PC. ► SYSTEM Requirements Item Windows PC Mac Book Intel Pentium 4 / 3.0GHz Intel Core 2 Duo / 2.2GHz Main Memory Video Memory 128MB... - Page 10 Real Time Recording & Full HD Display Setup menu 4) Select the ‘Connection’ by clicking the mouse 5) If you to edit the DVR name or DVR Group, right button on DVR list you added or doble-click click the ‘Edit DVR’ on menu bar as below. the DVR name.
- Page 11 1-6-2. Mobile Provide Real-time video monitoring, recorded video search function using a smart phone. Android App: Search ‘ronix’ or ‘rview’ and install the application ‘RVIEW’ iPhone / iPad App: Search ‘rview’ and install the application ‘RVIEW’ • Install and run the application.
- Page 12 QUICK GUIDE for Real time Recording & Full HD Display DVR RME0800-V4...
