- Page 1 Operating Instruction QUICK GUIDE 720P Real time Recording & Full HD Display DVR Before installing and using this product, please read the instruction fully and keep it handy for late use.
- Page 3 Real Time Recording & Full HD Display Features • 4/8/16ch Stand-alone HD Display Real time DVR (1080p) • Independent for each channel resolution, quality and frame rate setting • Quick search using up to 256 times normal speed playback feature •...
-
Page 4: Name And Function Of Each Part
Real Time Recording & Full HD Display Name and Function of Each Part 1. FRONT PANEL ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑪ PLAY MULTI MENU ⑫ ⑬ ① ⑩ Name Function Numeric buttons Channel selection, Number input (10 => 0+0, 11=> 0+1 ) ①... -
Page 5: Rear Panel - 4Ch
Real Time Recording & Full HD Display Name and Function of Each Part 3. REAR PANEL - 8CH VIDEO IN SPOT OUT AOUT HD OUT ① ② ③ ④ ⑤ ⑥ ⑦⑧ Name Function VIDEO IN Camera Video Input ① AUDIO OUT Audio Output ②... -
Page 6: Specifications
Real Time Recording & Full HD Display Specifications ITEM 16CH Video Input 4ch BNC 8ch BNC 16ch BNC Video Output Monitor 1ch HD OUTPUT, 1ch Spot (Multi channel), 1ch VGA Multitasking Quadplex Video Compression H.264 Resolution 960x480, 704x480, 704x240, 352x240(NTSC) / 960x576, 704x576, 704x288, 352x288(PAL) No. -
Page 7: Setup Menu
Real Time Recording & Full HD Display Setup menu 1-1. Password The default password is 1234 for entering DVR menu and connecting through network. ■ Mouse menu Name Function View 1 > ① View 1 ① Single screen selection menu View 4 >... -
Page 8: Quick Search
Real Time Recording & Full HD Display Setup menu 1-2-1. DDNS Default shows default address based on the MAC address. Hostname can be set by user's preference for domain name. Type the word you want to use, press Check button, you can check the presence of the name in the DDNS server. - Page 9 Real Time Recording & Full HD Display Setup menu 1-3-3. Bookmark to PLAY Bookmark search function is supported. The list of bookmarks are displayed. It is convenient to use bookmarks on the plaback buckup. 1-3-4. Event Event search is supported. Select start time, end time and channels that you want to search in the event search menu, then event lists that occurred during that time period are displayed.
-
Page 10: Network Monitoring
Real Time Recording & Full HD Display Setup menu 1-6. NETWORK MONITORING 1-6-1. CMS Network monitoring program is provided. It supports Windows PC and Mac PC. • Live S : This mode is for controlling one DVR. After excuting the CMS program, put the mouse cursor on the My Group on the top right corner of the screen and then right-click. - Page 11 Real Time Recording & Full HD Display Setup menu 1-6-2. Mobile Smart Phone application is also supported. iPhone, iPAD, Android smartphones are supported. • Install and run the application. • If you press the menu button, DVR's list management menu will pop up at the bottom of the screen.
- Page 12 QUICK GUIDE for Real time Recording & Full HD Display DVR RME0800-V0...
