Ronix RMD-AH08 Operating Instruction

Ahd, bnc/utp, 1080p, real time recording & full hd ahd2.0 dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Preliminary
Operating Instruction
1080P
Real time Recording &
Full HD AHD2.0 DVR
Before installing and using this product,
please read the instruction fully and keep it handy for later use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RMD-AH08 and is the answer not in the manual?

Questions and answers

Related Manuals for Ronix RMD-AH08

Summary of Contents for Ronix RMD-AH08

  • Page 1 Preliminary Operating Instruction 1080P Real time Recording & Full HD AHD2.0 DVR Before installing and using this product, please read the instruction fully and keep it handy for later use.

  • Page 3: Safety Precautions

    Real Time Recording & Full HD Display 1. Safety Precaution To prevent fire or shock hazard, do not expose the device to rain or moisture. To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 4: Table Of Contents

    Real Time Recording & Full HD Display 2. Table of Contents 1. Safety Precautions ......... 03 2.

  • Page 5: Features

    Real Time Recording & Full HD Display 3. Features BNC Input (Video Over Coaxial cable) only • 4ch/8ch/16ch Stand-alone HD Display Real time DVRs (1080p) • Camera menu control through Up-The-Coax.(UTC) communication. BNC/UTP Input (Video Over Cat.5e Unshield Twist Pair cable) •...

  • Page 6: Components

    Real Time Recording & Full HD Display 4.Composition DVR Set Mouse Instruction CD Quick Guide Adaptor & Power cable HDD mounting screws OPTION Rack mount bracket (2pcs) Rack mounting screw (6pcs) (4ch: 4pcs) (8ch/16ch: 8pcs) 5. Name and Function of Each Part 1.
  • Page 7 Real Time Recording & Full HD Display 5. Name and Function of Each Part 2. REAR PANEL 2-1. UTP 4CH RS485 POWER DC48V ETHERNET HD VIDEO ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ① ③ ⑤ ② ④ 2-2. UTP 8CH RS485 POWER DC48V...
  • Page 8 Real Time Recording & Full HD Display 5. Name and Function of Each Part 2-3. BNC 4CH RS485 ETHERNET HD VIDEO ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ 2-4. BNC 8CH RS485 ETHERNET HD VIDEO ① ② ③ ④...

  • Page 9: Specifications

    Real Time Recording & Full HD Display 6. Specifications ITEM 16CH Video Input UTP type 4ch UTP 8ch UTP BNC type 4ch BNC 8ch BNC 16ch BNC Video Output Monitor 1ch HD OUTPUT, 1ch Spot (Multi channel), 1ch VGA 1ch HD OUTPUT, 1ch VGA Transmission Distance UTP type: Up to 200m / BNC type: Up to 500m Multitasking...

  • Page 10: Operation

    Real Time Recording & Full HD Display 7. Operation 7-1. PRODUCT INSTALLATION 7-1-1. Harddisk installtion: Install SATA harddisk drivers to the DVR, using the provied rack brackets. 7-1-2. Connecting the camera: Connect the cameras. 7-1-3. Power supply: Connect the power supply to operate the product. 7-1-4.

  • Page 11: Setup

    Real Time Recording & Full HD Display 7. Operation ■ Mouse menu Name Function ① ① Single screen selection menu View 1 ② ② 4-split screen selection menu View 4 ③ ③ 9-split screen selection menu View 9 ④ 16-split screen selection menu View 16 ④...

  • Page 12: Search

    Real Time Recording & Full HD Display 7. Operation 7-4. SEARCH Search Search menu displays as shown above . Depending on search method, Quick, Calendar, Bookmark, Event, USB search options are available. Quick Calendar Bookmark Event Exit 7-4-1. Quick SEARCH Quick Search menu window appeares as shown above.

  • Page 13: Playback

    Real Time Recording & Full HD Display 7. Operation 7-4-3. BOOKMARK to PLAY Bookmark Bookmark search function is supported. No.10 2015/02/14 12:52:28 MULTI_16 The list of bookmarks are displayed. No. 9 2015/02/14 12:50:18 MULTI_16 It is convenient to use bookmarks on the plaback buckup.

  • Page 14: Backup

    Real Time Recording & Full HD Display 7. Operation ■ PLAYBACK Mouse menu User can select the playback screen mode which is single, 4-split, 9-split, 16-split support zoom fuction at display mode. User can set a bookmark during playback. The saved bookmarks are used A-B repeat during playback. 7-6.

  • Page 15: Setup Menu

    7-7-2. Mobile Smart Phone application is also supported. iPhone, iPAD, Android smartphones are supported. • Android App: Search ‘ronix’ and install the application ‘RVIEW’ • iPhone / iPad App: Search ‘rview’ and install the application ‘RVIEW’ 8. Setup Menu ■ SETUP Menu Table...
  • Page 16 Real Time Recording & Full HD Display 8. Setup Menu Resolution Display HD OUTPUT/VGA SYSTEM VGA only Off, Everyday, Sun ~ Sat. Auto Reboot Time 00:00 ~ 23:00 Auto UPnP Static Type TCP/IP DHCP Default DDNS Hostname Stream Channel, Resolution, Quality, Frame rate NETWORK IP Address EXT.
  • Page 17 Real Time Recording & Full HD Display 8. Setup Menu Address, Port, ID, SMTP Password, SSL, MIME E-mail Condition Period, Prohibition EVENT Motion, Video Loss, Contents Record Status, System Access Post Record Post Alarm Record None, 10~60sec Admin Password Name Password User CH1~CH16, PTZ, Playback,...

  • Page 18: System

    Real Time Recording & Full HD Display 8. Setup Menu ■ SETUP Menu Instructions 8-1. SYSTEM System Network Record Event Account Camera Info Name Name Time Date Time Format Language SW Upgrade Configuration Buzzer Display Auto Reboot Apply 8-1-1. Name and ID 1) Name: Set the name of the DVR.
  • Page 19 Real Time Recording & Full HD Display 8. Setup Menu 8-1-4. Upgrade Software Application or kernel of the DVR can be upgraded by USB memory. After receiving an upgrade file from homepage, you can copy it to a USB memory. System Network Record...
  • Page 20 Real Time Recording & Full HD Display 8. Setup Menu 8-1-6. Buzzer The operation of the buzzer is depending on the status of the DVR. System Network Record Event Account Camera Info Name Motion Time Date Video Loss Record Fail Language Record Warning SW Upgrade...

  • Page 21: Network

    Real Time Recording & Full HD Display 8. Setup Menu 6) Resolution : Select the output resolution for HD OUTPUT and VGA ports. Selectable resolutions are 1024x768, 1280x720, 1280x1024, 1440x900, 1920x1080. 7) HD OUTPUT/VGA : Adjust the display parameters of HD OUTPUT, VGA port. Luminance, Contrast, Hue, Saturation can be adjusted.
  • Page 22 Real Time Recording & Full HD Display 8. Setup Menu System Network Record Event Account Camera Info TCP/IP Type Static DDNS IP Address 192.168.0.100 Stream Subnet Mask 255.255.0.0 Gateway Status 192.168.0.1 Port Client Info UPnP Remote DVR DNS IP 8.8.8.8 DDNS Link Bandwidth Limitation(kbps) Apply...
  • Page 23 Real Time Recording & Full HD Display 8. Setup Menu 8-2-2. DDNS 1) Default: Show the default address based on MAC address for network access. System Network Record Event Account Camera Info TCP/IP Default 0010c0.eznetdns.com DDNS Hostname .eznetdns.com Stream Check Status Input DVR Name Client Info...
  • Page 24 Real Time Recording & Full HD Display 8. Setup Menu 8-2-3. Stream 1) Channel: Network stream type is H.264. Individual channel setup or all channel setup is possible. • Resolution : 480 x 270(NTSC/PAL) only • Quality : 4 different modes(LOW, MEDIUM, HIGH, SUPER) can be selected. •...
  • Page 25 Real Time Recording & Full HD Display 8. Setup Menu • Status Test Result: > IP Address : Display the currently assigned IP number. > EXT. IP Address : Display the currently assigned external public IP address number. > Network Test : Display the results of connection test with the router. >...
  • Page 26 Real Time Recording & Full HD Display 8. Setup Menu Input the network information of remote DVR. Press Add button to input the information. 1) Name : Name of the remote DVR 2) Address : IP address of the remote DVR 3) Port : Port No.

  • Page 27: Record

    Real Time Recording & Full HD Display 8. Setup Menu 8-3. RECORD System Network Record Event Account Camera Info Channel Channel Schedule Resolution Misc Quality Super Playback Framerate Mode Continuous Apply 8-3-1. Channel It is used to set resolution, quality, frame rate, record mode for all channel or each channel. 1) Channel : possible to set ALL or indivisual channel.
  • Page 28 Real Time Recording & Full HD Display 8. Setup Menu Schedule 1 00 ~ 01 01 ~ 02 02 ~ 03 03 ~ 04 04 ~ 05 05 ~ 06 06 ~ 07 07 ~ 08 08 ~ 09 09 ~ 10 10 ~ 11 11 ~ 12 12 ~ 13...

  • Page 29: Hard Disk(Hdd)

    Real Time Recording & Full HD Display 8. Setup Menu 8-3-4. Playback 1) Playback: • Channel : Select the channel to playback. If ALL is selected, 16 channels will be playbacked simultaneously. • Start Point : Choose the start point of the playback. •...
  • Page 30 Real Time Recording & Full HD Display 8. Setup Menu 8-4-2. S.M.A.R.T 1) S.M.A.R.T : Choose whether to check S.M.A.R.T. test. The test works only ON condition in the check interval. The test results are recorded in the System Log. There are 3 results which are PASSED, WARNING, ERROR. WARNING is occured when even one kind of abnormal test is checked, It indicates a potential problem that is likely to occur.

  • Page 31: Event

    Real Time Recording & Full HD Display 8. Setup Menu 8-4-4. Information1 Display the information of harddisk. It shows the model name and used capacity of the harddisk driver. 8-4-5. Information2 Display temperature and SMART test results. 8-4-6. Record Time The available record time will be displayed based on the current state.
  • Page 32 Real Time Recording & Full HD Display 8. Setup Menu All On All Off Save Exit 8-5-2. E-mail The e-mail will be sent when a event occurs. 1) Address: • Sender : Enter the e-mail address of the sender. The email address to use must be registered in the SMTP server. •...
  • Page 33 Real Time Recording & Full HD Display 8. Setup Menu System Network Record Event Account Camera Info Motion Address SMTP Condition Contents Email Address smtp.gmail.com Post Record Port Authentication Password MIME Apply 3) Condition: Set the sending conditions of the email. •...
  • Page 34 Real Time Recording & Full HD Display 8. Setup Menu System Network Record Event Account Camera Info Motion Address SMTP Condition Contents Email Motion Post Record Video Loss Record Status System Access Apply 8-5-3. Post Record Set the duration time after the termination of the event. NONE, 10s, 20s, 30s, 40s, 50s, 60s can be selected. System Network Record...

  • Page 35: Account

    Real Time Recording & Full HD Display 8. Setup Menu 8-6. ACCOUNT 8-6-1. Admin Set the admin password. Default value is '1234'. System Network Record Event Account Camera Info Admin Password ********** User Log off Apply 8-6-2. User Manage the acoounts of users and feature set for each account. User's account can be up to 100. Using the buttons at the bottom of the menu, users can add, delete, and modify.

  • Page 36: Camera

    Real Time Recording & Full HD Display 8. Setup Menu 8-6-3. Log Off 1) Auto: Set whether to use an automatic log off. 2) Wait Time: Set the wait time of an automatic log off. 30s, 1min, 3min, 5min, 10min can be selected. System Network Record...
  • Page 37 Real Time Recording & Full HD Display 8. Setup Menu 8-7-4. UTC (16ch only) Camera menu can be adjusted through DVR using Up-the-Coax(UTC) function per channel. Selects channel for camera setting and click UTC button then camera menu and 5 command key are displayed.
  • Page 38 Real Time Recording & Full HD Display 8. Setup Menu 8-7-6. Sequence Automatic screen switch setting. 1) Channel: Single channel (CH-1 ~ CH-16), 4-split screen (M1-4, M5-8, M9-12, M13-16), 9-split screen (M1-9, M8-16), 16 split screen (M1- 16) can be selected for sequential switching. 2) Dwell Time: Set the time interval of the sequence.

  • Page 39: Information

    Real Time Recording & Full HD Display 8. Setup Menu 8-8. INFORMATION 8-8-1. Event Log Related event log shows. Setting the event log search time, the channel can be selected. System Network Record Event Account Camera Info Event Log Start 2015/04/17 04:18PM System Log...

  • Page 40: Cms

    Real Time Recording & Full HD Display 8. Setup Menu 8-8-3. Information Model name, Video type, Version (Hardware, Kernel, Software) information, MAC Address is displayed. System Network Record Event Account Camera Info Event Log Model RX-AH16J System Log Video Type NTSC Information Version...

  • Page 41: Program

    Real Time Recording & Full HD Display 9. CMS 1) Open the CMS program 2) Click the mouse right button as below and select ‘Add DVR’ 3) After clicking the Add DVR, enter the information of DVR which you want to Add. The default ID/PW are admin/1234.
  • Page 42 Real Time Recording & Full HD Display 9. CMS 9-4. PROGRAM 9-4-1. Screen Configuration 1) Function window : LiveS, LiveM, Search, Playback, Backup, E-Map, Information, DVR Configuration, PC Configuration can be selected. 2) Video monitoring window : DVR's video shows. 3) Connection list management window : Manage the group and DVR using add, modify, and delete function.
  • Page 43 Real Time Recording & Full HD Display 9. CMS 1) Computer's time : Computer time is displayed. 2) No. of frames : Display the number of total frames per second over the network. 3) Function selection : LiveS Icon is displayed in blue when LivsS mode is working. 4) DVR name, account, time : The currently connected client's name, account and the current time of the DVR are displayed.
  • Page 44 Real Time Recording & Full HD Display 9. CMS 6) List management window : Add, modify, delete DVR list. When you click the right mouse button, pop up a window displaying Disconnect, Add group, Modify group, Delete group, Add DVR, Modify DVR, Delete DVR. 7) Screen configuration : 2x2, 3x3, 4x4, 5x5, 6x6, 7x7, 8x8, FULL Screen(video only), move previous page, move next page button can be selected.
  • Page 45 Real Time Recording & Full HD Display 9. CMS 9-4-5. Playback 1) Computer's time : Computer time is displayed. 2) No. of frames : Display the number of total frames per second transmitted over the network. 3) Function selection : Playback Icon is displayed in blue when it is selected. 4) DVR name, accout, time, speed of playback: Display the currently connected DVR's name, account, time and playback speed.
  • Page 46 Real Time Recording & Full HD Display 9. CMS 9-4-6. Backup 1) Computer's time : Computer time is displayed. 2) No. of frames : Display the number of total frames per second transmitted over the network. 3) Function selection : Backup Icon is displayed in blue when it is selected. 4) DVR name, accout, time, speed of playback: Display the currently connected DVR's name, account, time and playback speed.
  • Page 47 Real Time Recording & Full HD Display 9. CMS 9-4-7. E-Map 2015-07-01 14:40:51 1) Computer's time : Computer time is displayed. 2) Function selection : View, Modify, Setup, Exit function button. Button is displayed in blue when it is selected. In the view Mode, User's monitoring E-Map.

  • Page 48: Dvr Configuration

    Real Time Recording & Full HD Display 9. CMS 1) Computer's time : Computer time is displayed. 2) Function selection : Information Icon is displayed in blue when it is selected. 3) Group selection window : Group selection window for confimation of DVR. Info, Log group selection is possible. 4) Information display window : Display the information and system log of DVR.
  • Page 49 Real Time Recording & Full HD Display 9. CMS Display the program version information and the computer's storage device information.

  • Page 50: Mobile

    Provide Real-time video monitoring, recorded video search function using a smart phone. 10-2. Installing the program 10-2-1. Android phone After connecting App Store, enter RONIX on the search menu. Install the app using android market or download ‘RVIEW’. 10-2-2. iphone After connecting App Store, enter RVIEW on the search menu.
  • Page 51 Real Time Recording & Full HD Display 10. Mobile 2) Edit : Press the Edit button to edit the information of the selected DVR. 3) Delete/Exit : Press the Delete/Exit button to delete or exit the App. If selects ‘Delete’ menu, confirmation message will pop up for deletion the selected DVR on the list.
  • Page 52 Real Time Recording & Full HD Display 10. Mobile 10-3-4. Screen Configuration After selecting the DVR from the list, press the Connection button, then DVR will be connected. 1) Disconnect : Disconnection button. 2) DVR name : Display the name of the connected DVR. 3) Capture : Image capture button.
  • Page 53 Real Time Recording & Full HD Display 10. Mobile 10-3-6. PTZ control 1) Quit PTZ : Exit PTZ control mode button. 2) DVR name : Display the name of the connected DVR. 3) Capture : Image capture button. 4) DVR time : Display the currently connected DVR's time. 5) Video monitoring window : Display Currently connected DVR's video.
  • Page 54 Real Time Recording & Full HD Display 10. Mobile 10-3-9. Remote control DVR relay control window. Auto(Port is off automatically after selected seconds pass by) or Manual contol is possible. 10-3-10. Setup Preferences menu for application. Network stream types(Main, Sub, Auto), Aspect Ratio(Full, 4:3), Playback option(Skip, Non skip), Audio ON/OFF, OSD visibility can be selected.

  • Page 55: Appendix-Emergency Recovery

    Real Time Recording & Full HD Display 11. Appendix - Emergency recovery 11-1. SUMMARY Put specific name of files on a USB memory. Turn on the DVR. While booting, DVR copies the file and replace the corrupted file by new one. Use this procesure when DVR does not work because of power outage during the program upgrade.
  • Page 56 Real time Recording & Full HD AHD2.0 DVR MADE IN KOREA RME0900-V1...
