5.2 Display Explanation

Flow Rate／Net Totalizer
Display flow rate and net totalizer.
Flow Rate／Velocity
Display flow rate and velocity.
Flow Rate／Positive Totalizer
Display flow rate and positive totalizer.
Select the Flow Rate units in Window M31.
Select the positive Totalizer units in Window M3 the positive Totalizer units in Window M32.
If the positive totalizer has been turned off, the otalizer has been turned off, the
positive totalizer value displayed is the total the total otalizer value displayed is the total the total
that existed prior to turning it off.
Flow Rate／Negative Totalizer
Display flow rate and negative totalizer.
Select the negative totalizer value in Window M3 otalizer value in Window M32.
If the negative totalizer has been turned off (refer to otalizer has been turned off (refer to
M36), the value displayed is total the total that existed M36), the value displayed is total the total that existed
prior to turning it off.
