How To Program A Wiseboxes Circuit To A 2 Button Switch; How To Program A Master On/Off Function For The Wisebox; How To Change The Switching Mode - Wise Controls WiseBox Simple Instructions

3.

How to program a WiseBoxes circuit to a 2 button switch.

Programming a WiseBoxes circuit this way will result in 1 button being On, and 1 button being Off.
Programming to either button 1 or 2 will result in button 1 being On, and button 2 being Off while programming to either
Programming this way means only a maximum of 2 circuits can be controlled from a 4 button switch.
a) Make sure that the mains 240V supply into the WiseBox is ON.
b) Press the programming button (M1, M2, M3, or M4) twice within 1 second, holding on the second press.
(the buzzer will sound continuously).
c) While holding down the programming button, press the button on the switch / remote you wish to control the circuit with.
(The buzzer will sound intermittently to confirm the programming is successful.)
d) The 2 buttons will now turn that circuit on or off.
4. How to program the WiseBoxes to a 7 button switch. (ALL ON / ALL OFF)
a) The 'MT' button automatically programs the WiseBoxes 'all on', and 'all off' function. To program this feature you will need
to have a 7 button switch or remote (this utilises 2 of the 3 buttons at the bottom of the switch).
b) Program circuits 1 - 4 as previously instructed.
c) Press and hold 'MT' (group control)
(the buzzer will sound continuously).
d) With 'MT' held down, press button 5 on the switch/remote.
The buzzer will sound intermittently to confirm the programming is successful.
e) The function is now activated and will work as follows,
5. How to program a master On/Off function for the WiseBox (1 x ON, 1 x OFF).
a) To apply this function to the WiseBox, a minimum of a 2 button switch / remote is required.
b) Press the MT button and hold.
(the buzzer will sound continuously).
c) Press either buttons 1 or 2 / 3 or 4 on the switch / remote.
the buzzer will sound intermittently to show programming is successful.
d) Button 1 has now been assigned a master 'on' function while button 2 is a master 'off' function.
6.

How to change the switching mode.

a) The dip switch panel at the top centre of the WiseBox circuit board can change the switching mode from switching to
push to make.
Caution – Make sure that the circuit is OFF before changing the dip switch.
b) The dip switch in the UP position will change the channel to a on/off circuit. (default position)
c) The dip switch in the DOWN position will change the channel to a push to make circuit.
wisebox
PROGRAMMING (CONT.)
button 3 or 4 will result in button 3 being On, and button 4 being Off.
The switching mode allows you to flip between making a
circuit push to make or an on / off circuit
Button 5 = All On
Button 7 = All Off
wise controls
