General Description of use.
2 circuit radio receiver for switching all light sources. Powered from a mains voltage power supply, with optional push-
buttons input for manual controls. Switches contacts via radio signal from a wireless switch / remote. Ideal for dimming
most light sources wirelessly.
1.

How to install the WisePack Switching.

a)
Connect a mains 240V supply into the WisePack Switching using terminals 5(Live), 6(Neutral) and 2(Earth).
b)
Connect circuit 1 to terminals 9(Live), 10(Neutral) and 12(Earth).
c)
To connect a second circuit, use terminals 7(Neutral), 8(Live) and 11(Earth).
d)
To connect a second WisePack, use terminals 3(Live), 4(Neutral) and 1(Earth).
2.

How to program the WisePack Switching to 1 button.

a)
Make sure that the mains 240V supply into the WisePack Switching is ON.
b)
Press and hold 'MEM1', (The buzzer will sound continuously).
c)
With 'MEM1' held down, press one of the buttons on the wall or remote switch.
d)
The buzzer will sound intermittently to confirm the programming is successful.
e)
You will now be able to control the WisePack Switching using that switch button.
f)
If a second circuit is required, repeat this procedure with 'MEM2', storing on a different switch button.
Repeat this procedure for all Switches and Remotes that you want programmed to the WisePack Switching
g)
wisepack switch receiver
LED 1: Receiving of a Radio Function.
LED 2: Indicates a malfunction (interrupted load, internal fault)
LED 3: Active memory function.

INSTALLATION

PROGRAMMING

Simple Instructions for the
WisePack Switching
