- Page 1 QUICK START INSTRUCTIONS HLF 1700 QUICK START INSTRUCTIONS ENGLISH Part Code: 9BQE17G04 Q.S.I. HLF 1700 Eng V4-2019 HLF Italian Design...
-
Page 2: Quick Start Instructions
RETAIN FOR FUTURE USE ! The copyright of these Instructions Manual, which are entrusted to the recipient personally, remains with the HLF company. The content may not be disclosed or made available to any third party without the express consent of the HLF company. -
Page 3: Installation
• Exposing it to rain, excessive cold or heat, or damp places 1.1.1 Receiving the unit NOTE Before to open the box of the HLF 1700 coffee maker, check out the packaging to be sure there is no damage. If damage is noticed, place a claim with the freight forwarder immediately. - Page 4 HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 5 The packing material must not be left accessible to others, as it is a potential source of danger. For the disposal contact qualified companies. Now the unit is free and ready to be installed on a base, table or cabinet strong enough to hold 50 Kg. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 6 WARNING Don’t try to operate the HLF 1700 coffee maker in case of presence of internal damages. Even if the damages are minimal, it’s strongly recommended to leave the unit disconnected from the power supply and call the technical service.
- Page 7 Electric Requirements: Be sure to choose a wall plug with enough power to supply the unit and that it’s grounded in observance with current safety norms. Refer to paragraph 1.3.3 of this Instruction Manual to select the correct wall plug. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 8 After filling the tank, replace it into its original place and be sure to re-insert the clear tube into the tank and close it with the round cap. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 9 Refer to the national laws of your country for the connection to the water line. To connect the water line to the HLF 1700, is necessary to use a tube with a female screw of ¾ of inch at each end of it, as showed on the following picture.
- Page 10 Then make a hole in the plastic drip tray (see following image). In this way the liquid collected, will be discharged externally through the tube that was previously connected (previous step). HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 11 Insert the power cord on the back of the machine near to the main power switch. WARNING INSERT THE POWER CORD INSIDE A CORRECT WALL PLUG, WITHOUT USING ANY OTHER ELECTRIC ADAPTER. THE USE OF EXTENSION CORDS, ADAPTERS AND/OR MULTIPLE PLUGS IS STRONGLY FORBIDDEN ! HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 12 1.3.1.1 Coffee beans Fill up the coffee beans hopper with fresh coffee beans. Remember to open the beans stopper located at the bottom of the coffee beans hopper. (see image A below). HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 13 It’s recommended to use a mix of coffee beans for automatic coffee makers, in order to avoid a rapid consumption of the grinder’s blades and also to get the best performance for the HLF 1700 For information refer to a coffee beans dealer. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 14 Place back the container in its original position. 1.3.1.3 Milk (In case of fresh milk machine) WARNING Refer to paragraph 2.2.1.3 for the proper use of the milk with HLF 1700 machine. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 15 Open the door of the machine and take out the clear pipe from the inside. Pass the pipe through the milk tube holder on the side of the machine and then put it inside the milk container. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 16 1.3.1.4 Detergent (in case of a Self Cleaning machine) In order to refill detergent tank follow the instructions below. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 17 Choose the correct quantity of detergent refilled (assuming the capacity of a bottle of detergent is 1000ml), insert the password (default is 123456, you can edit or disable it in Main Menu > Security), and the alarm will disappear. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 18 1.3.2 Turning ON the unit Turn on the unit by the main switch situated on the back of the HLF 1700 coffee maker. The coffee group will position and the front LED will start blinking fast. The machine is ready to be connected to an Android device via Bluetooth. See Paragraph 1.3.3.
- Page 19 When discovery process is finished, select from the shown list the device with the Serial number of the machine, placed on a label on the back of the machine. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 20 At the first time of connection, a "Pair Code" will be requested. Type in 1234 and push OK. Once the connection is established the message will appear on the screen. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 21 If the machine has been just un-packed, it's necessary to run a CLEANING CYCLE to fill the boiler and the internal circuits with water. Make sure to have completely filled the water tank or to have the main water supply opened and connected to the machine. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 22 Once the cleaning cycle has finished, wait for the boiler to heat the water to the perfect temperature (following screenshot) HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 23 Once the temperature is reached the list of drinks will appear on the screen and the label "SELECT A DRINK PLEASE" will appear at the top. Now it's possible to have a superb hot drink from your HLF! HLF Italian Design...
- Page 24 Android device to the machine. See Chapter 5.2.1.1 of the Manual; • Download User Manual (pdf): To download the User Manual of the machine. Needs a pdf viewer app to open the file; HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 25 It means that the cleaning cycle has to be run in order to load water into all the hydraulic circuits. Push on the Start button and then enter the password 1111. This operation will take about 5 minutes. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 26 If the below screen shot will appear, push on the error icon (top right corner). HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 27 Push on the FLOW METER KO alarm and the following screen shot will appear. This happened because at the first initial water fill in of the machine, the water doesn’t arrive directly to the boiler. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 28 After the press of the RESET button the machine will load the boiler, and the cleaning screen will be shown again. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 29 1.3.4.1 Initial heating Once the cleaning cycle is finished, the following screen will appear . Push on the alert (top right corner). The following screen shot will appear. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 30 When the notification icon disappears the machine is ready to work. At this point it is possible to: • start delivering drinks • access the software and consult the instruction manual as follows: HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 31 Push the top left corner. Then push Main Menu key. Enter the password: 123456, as follows, then push OK. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 32 If a more recent version is found, you will be asked to start the download. The PDF file of this Instruction Manual will be displayed on the touch screen. HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 33 The possible operations to do are the following: to scroll to the previous page to scroll to the next page to access the manual index and select a section to search words HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 34 1.3.5 Instruction Manual Scan the below QR Code or click on the following link to access the instructions manual of the machine: https://kutt.it/IM-1700-Eng HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
- Page 35 HLF Italian Design Q.S.I. HLF 1700 Eng V5-2020...
