Introduction
Congratulations on your purchase of the M-Audio ProKeys 88, the complete all-purpose live stage piano, with additional MIDI
control. We strongly recommend that you read through this manual to learn about proper installation, operation and advanced
functionality before using this product.
What's in the Box
Besides the product itself, the ProKeys 88 package will include the following items:
Software Driver CD (drivers and applications)
<
USB cable
<
Printed User Manual
<
Power supply (12V DC)
<
Sustain Pedal
<
If any of these items are missing, please contact the retail outlet at which you purchased this product.
ProKeys 88 Overview
The ProKeys 88 is a stage piano with 14 high-quality onboard sounds. M-Audio's unique hammer-action keyboard design makes
for a realistic grand piano feel. It also functions as a useful MIDI controller for your sequencer or sound module.
We have designed the ProKeys 88 with live performance in mind. As such, the control interface is simplified, with all of the main
features accessible via a single button press. Advanced features such as digital effects and MIDI control messages can be edited
"on-the-fly."
All connectors are 1/4" jack inserts allowing easy connection into a PA amplifier, mixer or other live sound setup.
The ProKeys 88 is able to start and stop playback from an external MIDI sequencer, as well as controlling sequence tempo. These
features have dedicated buttons giving you real-time control of a MIDI sequencer in a live situation
Before you start reading about the various features of your ProKeys 88, you should first familiarize yourself with some of the
terminology that is commonly used when describing these features.
Terminology
Edit Mode - Edit Mode describes the 3-second period after a function button has been pressed during which the parameters of
that function can be altered. The numeric keypad can be used to alter a parameter during this time. The LED display will flash
to show you that the displayed parameter can be edited. If an Edit Function Button has been pressed in error, you can press a
different Edit Function Button and re-trigger a new three-second time out period.
Normal Mode - Normal Mode describes the state of the device when no function buttons have been pressed. In normal mode,
the LED will display the program number that was last entered.
Function Buttons – These are the buttons to the left of the LED display. When any of these MIDI buttons or digital effects buttons
are pressed, your ProKeys 88 will enter Edit Mode.
Instrument – The ProKeys 88 comes with 14 built-in sounds that represent various instruments such as pianos, strings and bass.
The term "instrument" refers to one of the 14 internal sound programs. Different instruments are selected by pressing one of the
14 instrument buttons to the right of the LED display.
Split Mode – When the Split Button is pressed, your ProKeys 88 will enter Split Mode. In this mode, the keyboard is split into two
adjacent, non-overlapping zones. Each zone can have a different instrument assigned to it. Notes to the left of the Split Point will
control one instrument, and those notes to the right of the Split Point continue to control the previously selected instrument.
Layer Mode – When the Layer Button is pressed the device enters Layer Mode. In this mode, two instrument sounds can be
assigned across the entire keyboard range: the Main Instrument and the Layer Instrument. If Split Mode is also active, only the
keys to the right of the Split Point will have a Layered Instrument.
Main Instrument – This is the instrument that is selected when neither Split Mode nor Layer Mode is engaged.
Split Instrument – This refers to the instrument controlled by the keys to the left of the Split Point when Split Mode is active.
Layer Instrument – This refers to the second instrument that is controlled when Layer Mode is active.
Pro Keys 88 • User Guide
3

Advertisement

Table of Contents
loading

Summary of Contents for M-Audio ProKeys 88

  • Page 1 14 instrument buttons to the right of the LED display. Split Mode – When the Split Button is pressed, your ProKeys 88 will enter Split Mode. In this mode, the keyboard is split into two adjacent, non-overlapping zones. Each zone can have a different instrument assigned to it. Notes to the left of the Split Point will control one instrument, and those notes to the right of the Split Point continue to control the previously selected instrument.
  • Page 2: Performance Tips

    Performance Tips The ProKeys 88 is capable of some very expressive and fl exible sound combinations. Through layering and splitting the instrument sounds (which are described on pages 10-11 of this manual), and also transposing and adjusting volumes and applying effects, you can create some very unique performances.
  • Page 3: Minimum System Requirements

    Minimum System Requirements The ProKeys 88 is a stand-alone premium stage piano, which is also capable of being used as a MIDI controller with your compatible computer software.I If you are using your ProKeys 88 with a computer the following minimum system requirements apply: USB 1.0 port...
  • Page 4: Before You Connect

    Before You Connect Your ProKeys 88... The ProKeys 88 is a stand-alone digital piano and does not require a computer for operation. If you wish to use the MIDI controller functions of the ProKeys 88 with your computer, please check the installation documentation below fi rst.
  • Page 5: Using With Software

    When installed, the ProKeys 88 will appear in the computer as a simple MIDI device with one input port and one output port. You will select the ProKeys 88 input port as the MIDI input device in your audio application. The application will then be able to read any of the data transmitted by you from the ProKeys 88.
  • Page 6: Use Of The Controls

    On power up, the pedal is off. If the pedal is held down at power up, the pedal will work in reverse. This allows your ProKeys 88 On power up, the pedal is off. If the pedal is held down at power up, the pedal will work in reverse. This allows your ProKeys 88 to work with pedals of either polarity.
  • Page 7: Modulation Wheel

    Pitch Bend Wheel. If you are using the ProKeys 88 as a MIDI controller, the Pitch Bend Wheel transmits MIDI Pitch Bend Messages as it is moved. External MIDI devices may not respond to pitch bend messages. Check the MIDI implementation charts provided with your other MIDI equipment.
  • Page 8: Demo Button

    If you are using your ProKeys 88 as a MIDI controller, Program 0, Bank LSB 0 and Bank MSB 0 are sent out when this button is pressed. This would access Grand Piano on any GM-compatible synth or module.
  • Page 9 Note that the maximum transpose shift is always 12 notes in either direction. If you are using the ProKeys 88 as a MIDI controller, these buttons will also affect the note on that is sent out of the MIDI out ports.
  • Page 10: Midi Control Section

    MIDI Control Section The buttons in this section only have relevance if you are using your ProKeys 88 as a MIDI controller. Program Button When the Program Button is pressed, the LED display will fl ash the currently assigned program number. The default number is 000, which will select a Grand Piano sound in GM-compatible MIDI equipment.
  • Page 11 Clock synchronization. The ProKeys 88 is not able to respond to external MIDI Clock Messages sent from a different device. In other words, the ProKeys 88 always acts as the “master” clock device to which other devices will “slave” for sync.
  • Page 12: Troubleshooting

    Timing Clock Byte (F8h) The Timing Clock Byte (F8h) is sent at a rate of 96 per note. So, if your ProKeys 88 has a tempo setting of 120 BPM, the timing clock should be sent 192 times per second (2 X 96). For a tempo setting of 100 BPM, the Timing Clock Byte should be sent 160 times per second.
  • Page 13 Technical Support (fax): ........(418) 872-0034 Sales (e-mail): ........infocanada@m-audio.com Sales (phone): .
  • Page 14: Technical Info

    Note: Your M-Audio ProKeys 88 has been tested to comply with FCC Standards FOR HOME OR OFFICE USE. Modifications not authorized by the manufacturer may void users authority to operate this device.
  • Page 15 Appendices Appendix A MIDI Implementation Chart for the ProKeys 88 �������� Basic :Default Channel:Changed :Default Mode :Messages :Altered Note Number:True Voice Velocity: Note ON : Note OFF After : Keys Touch :Ch’s Pitch Bend Control 0-119 Change 120-127 Program Change:True Number...
  • Page 16: Warranty Registration

    Warranty Warranty Terms M-Audio warrants products to be free from defects in materials and workmanship, under normal use and provided that the product is owned by the original, registered user. Visit www.m-audio.com/warranty for terms and limitations applying to your specific product.
