Fun Generation PL 108 A User Manual

Active 2-way speaker
Hide thumbs Also See for PL 108 A:
Table of Contents

Advertisement

Quick Links

PL 108 A / 110 A /
112 A / 115 A
active 2-way speaker
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL 108 A and is the answer not in the manual?

Questions and answers

Related Manuals for Fun Generation PL 108 A

Summary of Contents for Fun Generation PL 108 A

  • Page 1 PL 108 A / 110 A / 112 A / 115 A active 2-way speaker user manual...

  • Page 3: Table Of Contents

    5 Connections and controls........................16 6 Playback via Bluetooth......................... 25 7 Technical speci cations........................26 8 Plug and connection assignment....................34 9 Cleaning............................... 39 10 Protecting the environment......................40 PL 108 A / 110 A / 112 A / 115 A...

  • Page 4: General Information

    General information General information This user manual contains important information on the safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to another user, be sure that they also receive this manual.

  • Page 5: Further Information

    Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. PL 108 A / 110 A / 112 A / 115 A...

  • Page 6: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’, ‘OFF’.
  • Page 7 Warning signs Type of danger Warning – high-voltage. Warning – danger zone. PL 108 A / 110 A / 112 A / 115 A...

  • Page 8: Safety Instructions

    Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 9 Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or e. If in doubt, seek advice from a regis‐ tered electrician. PL 108 A / 110 A / 112 A / 115 A...
  • Page 10 Safety instructions CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
  • Page 11 Possible damage due to installation of a wrong fuse The use of different types of fuses can cause serious damage to the unit. Fire hazard! Only fuses of the same type may be used. PL 108 A / 110 A / 112 A / 115 A...
  • Page 12 Safety instructions NOTICE! Possible staining The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate or PVC oor and ater some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the oo, but use felt-pad oor potectors or a carpet.

  • Page 13: Features

    1 × AUX IN (RCA) 1 × AUX OUT (RCA) 1 × lockable NL4 chassis connector for connecting an additional passive speaker box solid plastic housing with pole mount and handles PL 108 A / 110 A / 112 A / 115 A...

  • Page 14: Starting Up

    Starting up Starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 15 Starting up The unit can be mounted on a stand or set up on the oor or a s sufficiently sized and stable surface, e.g. a wall bracket. PL 108 A / 110 A / 112 A / 115 A...

  • Page 16: Connections And Controls

    Connections and controls Connections and controls Model PL 108 A active 2-way speaker...
  • Page 17 Connections and controls Model PL 110 A PL 108 A / 110 A / 112 A / 115 A...
  • Page 18 Connections and controls Model PL 112 A active 2-way speaker...
  • Page 19 Connections and controls Model PL 115 A 1 Display of the built-in media player. 2 SD card slot. PL 108 A / 110 A / 112 A / 115 A...
  • Page 20 Connections and controls 3 USB port. 4 Selection and control buttons of the built-in media player: Play / Pause button to start / stop track playback. Stop button to stop playback. Selection button. Press the button repeatedly to activate a playback mode. The active mode and the title of the cur‐ rent track will appear on the display: ‘NOR’: normal playback, all tracks of the selected audio source are played one time in succession.
  • Page 21 Switch button. Press this button to select an audio source directly: SD card, USB input or Bluetooth port. The active source is shown on the display. 5 [MIC] 3-pin balanced XLR input socket to connect a microphone (PL 108 A and PL 110 A). PL 108 A / 110 A / 112 A / 115 A...
  • Page 22 Input channel 1 and 2, each with a 3-pin XLR balanced input socket for connecting a microphone and a 6.35 mm phone socket as well as separate volume controls [LEVEL] (PL 112 A and PL 115 A). 6 [VOL] (PL 108 A and PL 110 A) Volume control. Use this control to adjust the volume of the MIC input signal.
  • Page 23 Volume control. Use this control to adjust the volume of the LINE input signal. 14 Lockable NL4 chassis connector output for connecting an additional passive speaker box 15 IEC chassis plug for power supply with fuse holder PL 108 A / 110 A / 112 A / 115 A...
  • Page 24 Connections and controls [POWER] On / o ffswitch [LINE IN] (PL 108 A and PL 110 A) Line input. 3.5 mm input socket to connect an external audio device (CD or MP3 player). active 2-way speaker...

  • Page 25: Playback Via Bluetooth

    ‘PL110A’, ‘PL112A’ or ‘PL115A’. The display shows the message ‘BT CONNECTING’.. You can then play the music les sored in the Bluetooth device. Use the buttons of the built-in player for control. PL 108 A / 110 A / 112 A / 115 A...

  • Page 26: Technical Speci Cations

    Technical speci cations Techniscp ae l ci ations PL 108 A Inputs 1 × RCA socket pair, stereo 1 × 3-pin XLR socket, balanced Outputs 1 × RCA socket pair, stereo 1 × NL4 Speaker Two-way system with 1" compression driver and 8" woofer Max.
  • Page 27 Fuse 5 mm × 20 mm, 1 A, 250 V, slow-blow Dimensions (W × H × D) 245 mm × 390 mm × 195 mm Weight 5.2 kg PL 108 A / 110 A / 112 A / 115 A...
  • Page 28 Technical speci cations PL 110 A Inputs 1 × RCA socket pair, stereo 1 × 3-pin XLR socket, balanced Outputs 1 × RCA socket pair, stereo 1 × NL4 Speaker Two-way system with 1" compression driver and 10" woofer Max. sound pressure level 109 dB Frequency range 80 Hz …...
  • Page 29 Fuse 5 mm × 20 mm, 1 A, 250 V, slow-blow Dimensions (W × H × D) 310 mm × 495 mm × 250 mm Weight 7.8 kg PL 108 A / 110 A / 112 A / 115 A...
  • Page 30 Technical speci cations PL 112 A Inputs 2 × 1/4" phone socket 1 × RCA socket pair, stereo 2 × 3-pin XLR socket, balanced Outputs 1 × RCA socket pair, stereo 1 × NL4 Speaker Two-way system with 1" compression driver and 12" woofer Max.
  • Page 31 Fuse 5 mm × 20 mm, 1 A, 250 V, slow-blow Dimensions (W × H × D) 375 mm × 585 mm × 295 mm Weight 11.5 kg PL 108 A / 110 A / 112 A / 115 A...
  • Page 32 Technical speci cations PL 115 A Inputs 2 × 1/4" phone socket 1 × RCA socket pair, stereo 2 × 3-pin XLR socket, balanced Outputs 1 × RCA socket pair, stereo 1 × NL4 Speaker Two-way system with 1" compression driver and 15" woofer Max.
  • Page 33 Fuse 5 mm × 20 mm, 1 A, 250 V, slow-blow Dimensions (W × H × D) 480 mm × 740 mm × 390 mm Weight 15 kg PL 108 A / 110 A / 112 A / 115 A...

  • Page 34: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug ts ino the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 35 The result is a pure signal without any noise inter‐ ference. Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding PL 108 A / 110 A / 112 A / 115 A...
  • Page 36 Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground active 2-way speaker...
  • Page 37 Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) RCA connection Drawing and table indicate the pin assignment of an RCA plug. Signal Ground, shielding PL 108 A / 110 A / 112 A / 115 A...
  • Page 38 Plug and connection assignment Speaker Twist chassis connector 1, + Signal 1 (in phase) 1, – Signal 1 (out of phase) 2, + Signal 2 (in phase) 2, – Signal 2 (out of phase) active 2-way speaker...

  • Page 39: Cleaning

    Clean with a dry soft cloth. Stubborn dirt can be removed with a slightly dampened cloth. Never use solvents or alcohol for cleaning. PL 108 A / 110 A / 112 A / 115 A...

  • Page 40: Protecting The Environment

    Protecting the environment Cleaning Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.

This manual is also suitable for:

Pl 110 aPl 112 aPl 115 a
