- Page 1 DUCT CARBON FILTER PREMIUM AUSTRALIAN CHARCOAL USER MANUAL...
- Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www. acinfinity.com and click contact for our contact information.
- Page 4 MANUAL CODE CL2208X1 (Carbon Filter) PRODUCT MODEL UPC-A DUCT CARBON FILTER, 4" AC-DCF4 819137020665 DUCT CARBON FILTER, 6" AC-DCF6 819137020672 DUCT CARBON FILTER, 8" AC-DCF8 819137020689 DUCT CARBON FILTER, 10" AC-DCF10 819137020825 DUCT CARBON FILTER, 12" AC-DCF12 819137021617 DUCT CARBON FILTER XL, 4"...
-
Page 5: Table Of Contents
Page 6 Key Features ................. Page 7 Product Contents ................Page 8 Installation ..................Page 9 Overhead Hanging ................ Page 11 Configuration Set-up ..............Page 15 Maintenance .................. Page 18 Other AC Infinity Products ............. Page 19 Warranty ..................Page 20... -
Page 6: Product Warning
PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Check your local code restrictions for additional safety measures that may be needed for a proper code compliant installation. Check local authority requirements for proper disposal of waste and residues. Read all instructions before installing and using this product. -
Page 7: Key Features
KEY FEATURES ALUMINUM FRAME CLOTH FILTER COVER MAX AIR PASSTHROUGH Features a resilient frame Traps particles from passing Galvanized steel mesh allows that resists corrosion and through the carbon filter. complete passthrough of air can be placed in high suitable for both intake and Rewash every six months to humidity settings. -
Page 8: Product Contents
PRODUCT CONTENTS DUCT PREFILTER FILTER FILTER CLOTH STRAPS (x1) (x2) (x2) -
Page 9: Installation
INSTALLATION STEP 1 Slip the cloth over your filter to block dust and other particles from passing through. Make sure the entire metal mesh is covered by the cloth. STEP 2 Connect your duct tube over your filter. Use duct clamps to secure the connection. - Page 10 INSTALLATION STEP 3 You may also connect your filter directly to your inline duct fan. Use ducting tape to secure them together. STEP 4 If your filter is placed in a humid space, position it at the highest point possible.
-
Page 11: Overhead Hanging
OVERHEAD HANGING STRAPS STEP 1 Loop the strap around a hanging pole. STEP 2 Slip the strap through the inner ladder lock slot from the bottom. - Page 12 OVERHEAD HANGING STRAPS STEP 3 Route the strap into the outer ladder lock slot from the top. Adjust the length of the completed loop as needed. STEP 4 Tuck the loose ends through the center gap of the ladder lock to secure the loop.
- Page 13 OVERHEAD HANGING STRAPS STEP 5 Connect your filter to your ductwork using your preferred method, as shown on pages 9 and 10.
- Page 14 OVERHEAD HANGING ROPE CLIPS* STEP 1 Loop the rope clip hangers around your grow tent's support beams. STEP 2 Hook the carabiners into the steel hooks located on the flanges. * Sold separately...
-
Page 15: Configuration Set-Up
INSTALLATION CONFIGURATION SET-UP INTERIOR HANGING To use this filter in intake applications, place the filter inside your grow space. Make sure your filter is connected to your inline duct fan's intake end before completing the installation. - Page 16 INSTALLATION CONFIGURATION SET-UP EXTERIOR MOUNTING To use this filter in exhaust applications, place the filter outside of your grow space. Make sure your filter is connected to your inline duct fan's exhaust end before completing the installation. Stuff the prefilter inside of the filter to lengthen the carbon bed's lifespan.
- Page 17 INSTALLATION CONFIGURATION SET-UP OVERSIZED GROW SPACE Use a dual fan and filter combination inside your grow space to completely scrub away odor in larger grow rooms and tents. Set the secondary filter on the floor and the inline fan on top of it so that the exhaust end points up.
-
Page 18: Maintenance
MAINTENANCE REVERSING THE FLANGES To extend the filter's lifespan and utilize its entire carbon bed, rotate the flanges from either end. Remove the screws from the flanges to release them from the filter. Replace the flanges on the other ends and screw them back into place. WASHING THE PREFILTER Wash the reusable cloth as needed to clear it of any dust and build-up. -
Page 19: Other Ac Infinity Products
150 lb. weight capacity. Includes a mounting plate to install your AC Infinity controller onto. Inline Fans The CLOUDLINE series is a line of duct fans designed to quietly ventilate AV rooms and closets, as well as various DIY air circulation and exhaust projects. -
Page 20: Warranty
WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues. - Page 21 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
