- Page 1 MAPEHEAT THERMO TOUCH User Guide...
-
Page 2: Table Of Contents
MAPEHEAT THERMO TOUCH User Guide Description ..................4 Certification ..................5 Navigation Principal ..............6 Getting Started ................7 Working Modes ................9 Manual ON/OFF programme ..........9 Timer programme ................9 Event programmes ...............11 Settings ....................12 Installer menu .................12 Setting the clock ................13 Sensor Calibration ..............14 Trouble Shooting................15 Technical Specification ............16... -
Page 3: Description
Description Certification The Mapeheat Thermo Touch thermostat is a programmable thermostat designed for electrical floor heating. The thermostat is designed to control electrical floor heating in order to give the best possible comfort and the lowest possible energy usage. The thermostat can work in 3 different temperature sensing modes: •... -
Page 4: Navigation Principal
Navigation Principal Getting Started The Mapeheat Thermo Touch is a thermostat with a touch display. THE DISPLAY 1. ON/OFF/ Home button Display in manual ON/OFF programme 2. Day The following icons are visible in the Manual ON/OFF: 3. Active sensor display 4. -
Page 5: Working Modes
To switch off the thermostat, touch the “ ” button for 2 seconds. TIMER PROGRAMME The Mapeheat Thermo Touch can be programmed with 4 events per day. Different temperatures can be maintained for each event of the day. The days can be programmed independently or per cluster of days. -
Page 6: Event Programmes
EVENT PROGRAMMES For Event 1 • Touch “ ” or “ ” to change hours of Event 1 • Touch the “ ” button to validate • Touch “ ” or “ ” to change the minutes of Event 1 •... -
Page 7: Settings
Description Range Default Setting Settings Floor sensing mode: OFF Room sensing mode: +5 to Minimum temperature +5°C +15°C set point for the Room Sensor Room sensing mode with INSTALLER MENU +5°C floor temperature limiter: +5 to +15°C Touch the “ ” button for 5 seconds to enter the Installer Menu. Floor sensing mode: OFF Room sensing mode: +40°C... -
Page 8: Sensor Calibration
Sensor Calibration Trouble Shooting In the event of damage or malfunction of one of the temperature sensors, Floor sensor calibration the heating output cuts off (fail safe) and an error code is displayed. The temperature of the floor surface can differ from the temperature measured by the floor sensor due to the floor construction, the floor type and Error Code Description... -
Page 9: Technical Specification
Rated impulse voltage 4kV (75)* Technical Specification Temperature for the ball pressure test +125°C (77)* SELV limits realised 22 VDC (86)* Supply voltage 230VAC 10%, -15%, 50Hz +1°C (Factory settings adjustable Switching hysteresis between 0.5-2.0°C) Power consumption (stand by) 3 VA * According to EN 60730-1 table 1 Method of mounting Wall bracket mounted... - Page 10 TECHNOLOGY FROM MAPEI WORLD LONDON CITY MAPEI UK LTD 6 Great Sutton Street Mapei House Clerkenwell Steel Park Road London Halesowen EC1V 0BX West Midlands. B62 8HD 020 3302 9610 0121 508 6970 clerkenwell@mapei.co.uk info@mapei.co.uk 0121 508 6970 | mapei.co.uk...
