- Page 1 Mapeheat ™ Thermo Touch Operating Manual...
-
Page 3: Table Of Contents
Table of Contents Introduction ............................. 2 System Tests .............................3 Setup Wizard ............................3 GFCI .................................3 Section 1: Home Screen ..................4 Temporary bypass and hold options ..........5 Energy use ......................5 Settings ........................ 6 Section 2: Setup/Preferences ................7 Language ......................7 Date ........................ -
Page 4: Introduction
Introduction Thank you for choosing Mapeheat Thermo Touch thermostat. You have chosen the most advanced thermostat to control your Mapeheat Floor-Heating System. This manual will cover each of the features of the Mapeheat Thermo Touch thermostat. -
Page 5: System Tests
Setup Wizard The Mapeheat Thermo Touch thermostat features a Setup Wizard to guide you through the basic setup process. The Setup Wizard is available the first time the thermostat is connected to power or after a factory reset is initiated. -
Page 6: Section 1: Home Screen
Section 1: Home Screen 1. Change date and time 2. Current temperature 3. Target temperature or setpoint 4. Operating mode: The Auto* mode means that the thermostat is following a program/ schedule. The Manual mode means that the thermostat is not following a program/ schedule and is being controlled manually. -
Page 7: Temporary Bypass And Hold Options
1. Press “Resume Program” to cancel the temporary bypass. 2. Press “Hold Options” to access more options. Hold Options The Mapeheat Thermo Touch thermostat allows you to set the duration you want for the temporary bypass temperature. ↑ ↓... -
Page 8: Settings
Section 1: Home Screen Section 1.3: Settings The following options are available under the “Settings” menu: • “Setup/Preferences” • “Program/Schedule” • “Thermostat Info” • “Factory Reset”... -
Page 9: Section 2: Setup/Preferences
Section 2: Setup/Preferences From the home screen, access the “Setup/Preferences” menu by pressing “Settings > Setup/Preferences”. Press the < or > arrows at the top to view both pages of “Setup/Preferences”. Section 2.1: Language 1. Choose between “English / Français / Español”. 2. -
Page 10: Unit
Section 2: Setup/Preferences Section 2.4: Unit 1. Choose between Fahrenheit or Celsius. 2. Press “Cancel” to ignore the change or press “Save” to confirm. Section 2.5: Operating mode The thermostat has two operating modes: 1. Auto: “Auto” is the default mode, allowing you to program a heating schedule for your thermostat. -
Page 11: Temperature Control
Section 2: Setup/Preferences Section 2.6: Temperature control The thermostat can be configured to control the floor temperature, air/room temperature, or a combination of floor and air/room temperature. Temperature Control Setting Description The thermostat controls the Floor temp. (default) floor temperature. The thermostat controls the air/ room temperature. -
Page 12: Floor Type
Section 2: Setup/Preferences Section 2.8: Floor type 1. Set according to your flooring type. 2. When “Engineered/Laminate/Vinyl” is selected, the floor temperature will be limited to 82°F (28°C). Note that this setting is not available if “Temperature Control” is set to “Air/room temp.” Refer to Section 2.6 on Page 9. 3. -
Page 13: Floor Limit
The floor heating will not turn on if the floor temperature is above the set floor limit. If the floor limit is set too low, your floor- heating system will not turn on. MAPEI suggests leaving the floor limit at the default factory temperature setting. -
Page 14: Section 3: Program/Schedule
Section 3: Program/Schedule From the home screen, access the “Program/Schedule” menu by pressing “Settings > Program/Schedule”. Below is the default schedule of the Mapeheat Thermo Touch thermostat: WEEKDAYS Floor Temperature Period Start Time Tile Wood Wake 6:00 a.m. 88°F (31°C) 82°F (28°C) -
Page 15: Section 4: Thermostat Information
Section 4: Thermostat Information 1. From the home screen, access the “Thermostat Info” items by pressing “Settings > Thermostat Info”. 2. Press the < or > arrows at the top to view both pages of thermostat information: • “Thermostat ID” – The unique serial number assigned to the thermostat during manufacturing. - Page 16 All intellectual property rights and other information contained in this document are the exclusive property of MAPEI (or its parent or related companies), unless otherwise noted. No part of this document may be reproduced or transmitted in any form without the prior...
