- Page 1 MAPEHEAT THERMO TOUCH Installation Guide...
- Page 2 DIMENSIONS Table of content 41.0 Dimensions Installation Description 86.3 Using the Thermostat Installer Menu Warning 86.3 16.5 86.3 79.8 60.0 48.0 49.0...
- Page 3 INSTALLATION = MAX 13A Power supply Floor Heating cable Power supply Floor Power supply Sensor 230 VAC 230 VAC Sensor 230 VAC heating cables Max. 13A L2 L3 1.5 m 1.5 m 10KΩ 10KΩ IP21 ZONE >1 x Power supply Floor Power supply heating cables...
- Page 4 DESCRIPTION The Mapeheat Thermo Touch Thermostat is a Programmable Thermostat designed for Electrical Floor Heating. The Thermostat has 2 programmes to choose from: • Manual ON/OFF (Constant Single temperature) • Timer programme (4 timer events/day) Temperature THERMO TOUCH button Sensor symbol...
- Page 5 INSTALLER MENU Description Sensing mode selection 12 vs 24 hours display Motion sensor. When getting close to the thermostat (5 cm range) the display lights up automatically Offset for floor sensor calibration Room sensor calibration Minimum temperature set point for the Floor Sensor Maximum temperature set point for the Floor Sensor Minimum temperature set point for the Room Sensor Maximum temperature set point for the Room Sensor...
- Page 6 NOTES...
- Page 7 TECHNOLOGY FROM MAPEI WORLD LONDON CITY MAPEI UK LTD 6 Great Sutton Street Mapei House Clerkenwell Steel Park Road London Halesowen EC1V 0BX West Midlands. B62 8HD 020 3302 9610 0121 508 6970 clerkenwell@mapei.co.uk info@mapei.co.uk 0121 508 6970 | mapei.co.uk...
